FSTL, FSTS, FSWL
www.vishay.com
Vishay Huntington
Wirewound Resistor, Industrial Power,
Silicone Coated, Tubular
FEATURES
• High temperature silicone coating
• Complete welded construction
• Excellent for intermittent power and pulsing
application
• Available in non-inductive style (special “NI”)
with Ayrton-Perry winding
• Various lead and terminal options
• Excellent stability in operation (< 3 % change
resistance)
• Material categorization: for definitions of
compliance please see
www.vishay.com/doc?99912
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
FSTL05
FSTS05
FSWL5A
FSTL5A
FSWL05
FSWL08
FSTL08
FSWL1A
FSTL10
FSTS10
FSWL10
FSWL12
FSTL12
FSWL15
FSTL15
FSWL2A
FSTL2A
FSTL20
FSTS20
FSWL20
HISTORICAL
MODEL
FSTL-5
FSTS-5
HLW-05
HLW-05
FSWL-5
HLW-06
HLW-06
HLW-10
FSTL-10
FSTS-10
FSWL-10
HLW-12
HLW-12
HLW-15
HLW-15
HLW-20
HLW-20
FSTL-20
FSTS-20
FSWL-20
POWER RATING
P
25 °C
W
5
5
5.25
5.25
8
8
8
10
12
12
12
12
12
15
15
20
20
20
20
20
RESISTANCE
RANGE
±5%
1.0 to 20.5K
1.0 to 20.5K
1.0 to 15K
1.0 to 15K
1.0 to 20.5K
1.0 to 20.5K
1.0 to 20.5K
1.0 to 29K
1.0 to 58K
1.0 to 58K
1.0 to 58K
1.0 to 58K
1.0 to 58K
1.0 to 60K
1.0 to 60K
1.0 to 95K
1.0 to 95K
1.0 to 95K
1.0 to 95K
1.0 to 95K
RESISTANCE
RANGE
± 10 %
0.1 to 20.5K
0.1 to 20.5K
0.10 to 15K
0.10 to 15K
0.1 to 20.5K
0.10 to 20.5K
0.10 to 20.5K
0.10 to 29K
0.10 to 58K
0.10 to 58K
0.10 to 58K
0.10 to 58K
0.10 to 58K
0.10 to 60K
0.10 to 60K
0.10 to 95K
0.10 to 95K
0.10 to 95K
0.10 to 95K
0.10 to 95K
WEIGHT
(typical)
g
4.60
4.60
2.12
2.12
4.60
4.60
4.60
6.24
6.69
6.69
6.69
6.69
6.69
8.82
8.82
11.36
11.36
12.57
12.57
12.57
TECHNICAL SPECIFICATIONS
PARAMETER
Temperature Coefficient
Short Time Overload
Dielectric Withstanding Voltage
Maximum Working Voltage
Operating Temperature Range
UNIT
ppm/°C
-
V
AC
V
°C
FST RESISTOR CHARACTERISTICS
± 260 for 20
and above, ± 400 for 1
to 20
,
special TC’s available please contact factory
10 x rated power for 5 s
1000, from terminal to mounting hardware
(P x
R)
1/2
-55 to +350
Revision: 02-Sep-16
Document Number: 31839
1
For technical questions, contact:
ww2dresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
FSTL, FSTS, FSWL
www.vishay.com
Vishay Huntington
GLOBAL PART NUMBER INFORMATION
Global Part Numbering example: FSTL05R2E25R00JE
(visit
www.vishay.net
SAP parts manual for all options)
F
S
T
L
0
5
R
2
E
2
5
R
0
0
J
E
SPECIAL
(up to 2 digits)
(dash number)
from
1
to
99
as
applicable
CT
= center tap
NI
= non-inductive
92
= 203 or 209 style
push-in bracket
as applicable
GLOBAL MODEL
(6 digits)
(see Standard
Electrical
Specifications
Global Model
column for
options)
TERMINAL
DESIGNATION
(2 digits)
A1
A2
R1
R2
TERMINAL
FINISH
(1 digit)
E
= lead
(Pb)-free
VALUE
(5 digits)
R
= decimal
K
= thousand
1R500
= 1.5
1K500
= 1.5 k
TOLERANCE
(1 digit)
J
=±5%
K
= ± 10 %
PACKAGING CODE
(1 digit)
E
= lead (Pb)-free
bulk pack
FSTL/FSWL products
to be lead (PB)-free
foam packed.
Historical Part Number example: FSTL-5-25-5 %
FSTL-5
HISTORICAL MODEL
25
RESISTANCE VALUE
5%
TOLERANCE
SPECIAL
DERATING
RATED POWER IN %
120
100
80
60
40
20
0
- 65 - 50
0
25
50
150
250
350
AMBIENT TEMPERATURE IN °C
MATERIAL SPECIFICATIONS
Element:
copper-nickel alloy or nickel-chrome alloy,
depending on resistance value
Core:
ceramic, steatite
Coating:
special high temperature silicone
Standard Terminals:
tinned alloy 42
Terminal Bands:
alloy 42
Part Marking:
HEI, model, wattage, value, tolerance, date
code
NON-INDUCTIVE
Models of equivalent physical and electrical specifications
are available with non-inductive (Ayrton-Perry) winding.
They are identified by adding the letters “NI” to the end of
the part number in the special section. For non-inductive
models the maximum resistance values are lower.
Revision: 02-Sep-16
Document Number: 31839
2
For technical questions, contact:
ww2dresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
FSTL, FSTS, FSWL
www.vishay.com
Vishay Huntington
DIMENSIONS
in inches [millimeters]
CORE DIMENSIONS (REF.)
MODEL
A
0.313
[7.94]
0.313
[7.94]
0.250
[6.35]
0.250
[6.35]
0.313
[7.94]
0.313
[7.94]
0.313
[7.94]
0.438
[11.11]
0.313
[7.94]
0.313
[7.94]
0.313
[7.94]
0.313
[7.94]
0.313
[7.94]
0.438
[11.11]
0.438
[11.11]
0.438
[11.11]
0.438
[11.11]
0.438
[11.11]
0.438
[11.11]
0.438
[11.11]
B
0.188
[4.76]
0.188
[4.76]
0.125
[3.18]
0.125
[3.18]
0.188
[4.76]
0.188
[4.76]
0.188
[4.76]
0.313
[7.94]
0.188
[4.76]
0.188
[4.76]
0.188
[4.76]
0.188
[4.76]
0.188
[4.76]
0.313
[7.94]
0.313
[7.94]
0.313
[7.94]
0.313
[7.94]
0.260
[6.604]
0.260
[6.604]
0.260
[6.604]
C
1.000
[25.40]
1.000
[25.40]
0.625
[15.88]
0.625
[15.88]
1.000
[25.40]
1.000
[25.40]
1.000
[25.40]
1.000
[25.40]
1.750
[44.45]
1.750
[44.45]
1.750
[44.45]
1.750
[44.45]
1.750
[44.45]
1.500
[38.10]
1.500
[38.10]
2.000
[50.80]
2.000
[50.80]
2.000
[50.8]
2.000
[50.8]
2.000
[50.8]
D
± 0.005
[± 0.12]
0.188
[4.78]
0.188
[4.78]
0.063
[1.59]
0.063
[1.59]
0.125
[3.175]
0.125
[3.18]
0.125
[3.18]
0.125
[3.18]
0.188
[4.78]
0.188
[4.78]
0.125
[3.175]
0.125
[3.18]
0.125
[3.18]
0.125
[3.18]
0.125
[3.18]
0.125
[3.18]
0.125
[3.18]
0.188
[4.78]
0.188
[4.78]
0.125
[3.175]
E
± 0.015
[± 0.38]
0.406
[10.31]
0.406
[10.31]
0.188
[4.76]
typ.
0.188
[4.76]
typ.
0.188
[4.78]
0.188
[4.76]
typ.
0.188
[4.76]
typ.
0.188
[4.76]
typ.
0.406
[10.31]
0.406
[10.31]
0.188
[4.78]
0.188
[4.76]
typ.
0.188
[4.76]
typ.
0.188
[4.76]
typ.
0.188
[4.76]
typ.
0.188
[4.76]
typ.
0.188
[4.76]
typ.
0.406
[10.32]
0.406
[10.32]
0.188
[4.78]
FSTL05
FSTS05
FSWL5A
FSTL5A
FSWL05
FSWL08
FSTL08
FSWL1A
FSTL10
FSTS10
FSWL10
FSWL12
FSTL12
FSWL15
FSTL15
FSWL2A
FSTL2A
FSTL20
FSTS20
FSWL20
TERMINAL
F
± 0.005
[± 0.12]
0.132
[3.35]
0.132
[3.35]
n/a
n/a
n/a
n/a
n/a
n/a
0.132
[3.35]
0.132
[3.35]
n/a
n/a
n/a
n/a
n/a
n/a
n/a
0.133
[3.37]
0.133
[3.37]
n/a
LEADS
DESIGNATION
R2
R2
A2
R2
A2
A1
R1
A1
R1
R1
A1
A1
R1
A1
R1
A1
R1
R1
R1
A1
G
± 0.002
[± 0.05]
0.032
[0.813]
0.032
[0.813]
0.032
[0.813]
0.032
[0.813]
0.032
[0.813]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
0.040
[1.02]
H
± 0.125
[± 3.18]
2.90
[73.66]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
2.90
[73.66]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.50
[38.10]
1.65
[41.91]
1.50
[38.10]
1.50
[38.10]
203
203
203
209
209
209
209
BRACKET
TYPE
209
209
Revision: 02-Sep-16
Document Number: 31839
3
For technical questions, contact:
ww2dresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
