IHLP-3232DZ-8A
www.vishay.com
Vishay Dale
IHLP
®
Automotive Inductors, High Temperature (180 °C) Series
FEATURES
• Shielded construction
• Excellent DC/DC energy storage up to 1 MHz
to 2 MHz. Filter inductor applications up to SRF
(see “Standard Electrical Specifications” table)
• Operating temperature up to 180 °C
• Lowest DCR/μH, in this package size
• Handles high transient current spikes without
saturation
• Ultra low buzz noise, due to composite
construction
• AEC-Q200 qualified
• IHLP design. PATENT(S):
www.vishay.com/patents
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DESIGN SUPPORT TOOLS
click logo to get started
Design Tools
Available
STANDARD ELECTRICAL SPECIFICATIONS
L
0
INDUCTANCE
± 20 %
AT 100 kHz,
0.25 V, 0 A
(μH)
0.22
0.47
0.68
1.0
2.2
3.3
4.7
5.6
10
15
22
33
DCR
TYP.
25 °C
(m)
1.68
2.38
3.30
4.58
DCR
MAX.
25 °C
(m)
1.86
2.55
3.53
4.90
HEAT
SATURATIO
RATING
N
CURRENT CURRENT
SRF
DC TYP.
DC TYP.
TYP.
(A)
(1)
(A)
(2)
(MHz)
36.0
27.0
21.5
19.0
11.5
11.3
7.2
6.9
5.1
4.8
3.7
3.1
32.0
19.0
16.2
16.2
14.0
11.8
9.1
9.0
5.2
3.6
3.8
3.2
117
77
51
45
32
23
18
18
13
10
9
6.1
APPLICATIONS
• Engine and transmission control units
• Diesel injection drivers
• Noise suppression for motors: windshield wipers / power
seats / power mirrors / heating and ventilation blower /
HID lighting
• LED drivers
DIMENSIONS
in inches [millimeters]
0.340 ± 0.01
[8.64 ± 0.254]
11.70 12.50
15.40 16.48
26.60 28.46
29.60 31.67
50.00 53.50
62.00 66.34
103.00 110.21
149.00 159.43
0.322 ± 0.003
[8.18 ± 0.076]
0.322 ± 0.003
[8.18 ± 0.076]
0.158
[4.0]
Max.
0.054 ± 0.015
[1.372 ± 0.318]
0.200 ± 0.003
[5.08 ± 0.076]
Typical Pad Layout
0.380
[9.652]
0.210
[5.334]
0.190
[4.826]
Notes
• All test data is referenced to 25 °C ambient
• Operating temperature range -55 °C to +180 °C
• The part temperature (ambient + temp. rise) should not exceed
180 °C under worst case operating conditions. Circuit design,
component placement, PWB trace size and thickness, airflow
and other cooling provisions all affect the part temperature. Part
temperature should be verified in the end application
• Rated operating voltage (across inductor) = 75 V
(1)
DC current (A) that will cause an approximate
T
of 40 °C
(2)
DC current (A) that will cause L to drop approximately 20 %
0
DESCRIPTION
IHLP-3232DZ-8A
MODEL
10 μH
INDUCTANCE VALUE
± 20 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC
®
LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
H
L
P
3
2
3
SIZE
2
D
Z
E
R
1
0
INDUCTANCE
VALUE
0
M
TOL.
8
A
MODEL
PACKAGE
CODE
SERIES
PATENT(S):
www.vishay.com/patents
This Vishay product is protected by one or more United States and international patents.
Revision: 23-Oct-17
Document Number: 34403
1
For technical questions, contact:
magnetics@vishay.com
