74LCX16841 Low Voltage 20-Bit Transparent Latch with 5V Tolerant Inputs and Outputs
October 1995
Revised April 2001
74LCX16841
Low Voltage 20-Bit Transparent Latch
with 5V Tolerant Inputs and Outputs
General Description
The LCX16841 contains twenty non-inverting latches with
3-STATE outputs and is intended for bus oriented applica-
tions. The device is byte controlled. The flip-flops appear
transparent to the data when the Latch Enable (LE) is
HIGH. When LE is LOW, the data that meets the setup time
is latched. Data appears on the bus when the Output
Enable (OE) is LOW. When OE is HIGH, the outputs are in
a high impedance state.
The LCX16841 is designed for low voltage (2.5V or 3.3V)
V
CC
applications with capability of interfacing to a 5V signal
environment.
The LCX16841 is fabricated with an advanced CMOS tech-
nology to achieve high speed operation while maintaining
CMOS low power dissipation.
Features
s
5V tolerant inputs and outputs
s
2.3V–3.6V V
CC
specifications provided
s
5.5 ns t
PD
max (V
CC
=
3.3V), 20
µ
A I
CC
max
s
Power down high impedance inputs and outputs
s
Supports live insertion/withdrawal (Note 1)
s
±
24 mA output drive (V
CC
=
3.0V)
s
Implements patented noise/EMI reduction circuitry
s
Latch-up performance exceeds 500 mA
s
ESD performance:
Human body model
>
2000V
Machine model
>
200V
Note 1:
To ensure the high-impedance state during power up or down, OE
should be tied to V
CC
through a pull-up resistor: the minimum value or the
resistor is determined by the current-sourcing capability of the driver.
Ordering Code:
Order Number
74LCX16841MEA
74LCX16841MTD
Package Number
MS56A
MTD56
Package Description
56-Lead Shrink Small Outline Package (SSOP), JEDEC MO-118, 0.300 Wide
3-STATE standard outputs. The device is byte controlled
with each byte functioning identically, but independent of
the other. Control pins can be shorted together to obtain full
20-bit operation. The following description applies to each
byte. When the Latch Enable (LE
n
) input is HIGH, data on
the D
n
enters the latches. In this condition the latches are
transparent, i.e. a latch output will change states each time
its D input changes. When LE
n
is LOW, the latches store
information that was present on the D inputs a setup time
preceding the HIGH-to-LOW transition of LE
n
. The
3-STATE standard outputs are controlled by the Output
Enable (OE
n
) input. When OE
n
is LOW, the standard out-
puts are in the 2-state mode. When OE
n
is HIGH, the stan-
dard outputs are in the high impedance mode but this does
not interfere with entering new data into the latches.
Logic Diagrams
Please note that this diagram is provided only for the understanding of logic operations and should not be used to estimate propagation delays.
www.fairchildsemi.com
2
74LCX16841
Absolute Maximum Ratings
(Note 2)
Symbol
V
CC
V
I
V
O
I
IK
I
OK
I
O
I
CC
I
GND
T
STG
Parameter
Supply Voltage
DC Input Voltage
DC Output Voltage
DC Input Diode Current
DC Output Diode Current
DC Output Source/Sink Current
DC Supply Current per Supply Pin
DC Ground Current per Ground Pin
Storage Temperature
Value
Conditions
Units
V
V
Output in 3-STATE
Output in HIGH or LOW State (Note 3)
V
I
<
GND
V
O
<
GND
V
O
>
V
CC
V
mA
mA
mA
mA
mA
−
0.5 to
+
7.0
−
0.5 to
+
7.0
−
0.5 to
+
7.0
−
0.5 to V
CC
+
0.5
−
50
−
50
+
50
±
50
±
100
±
100
−
65 to
+
150
°
C
Recommended Operating Conditions
(Note 4)
Symbol
V
CC
V
I
V
O
I
OH
/I
OL
Supply Voltage
Input Voltage
Output Voltage
Output Current
HIGH or LOW State
3-STATE
V
CC
=
3.0V
−
3.6V
V
CC
=
2.7V
−
3.0V
V
CC
=
2.3V
−
2.7V
T
A
Free-Air Operating Temperature
Input Edge Rate, V
IN
=
0.8V
−
2.0V, V
CC
=
3.0V
Parameter
Operating
Data Retention
Min
2.0
1.5
0
0
0
Max
3.6
3.6
5.5
V
CC
5.5
Units
V
V
V
±
24
±
12
±
8
−
40
0
85
10
mA
°
C
ns/V
∆
t/
∆
V
Note 2:
The Absolute Maximum Ratings are those values beyond which the safety of the device cannot be guaranteed. The device should not be operated
at these limits. The parametric values defined in the Electrical Characteristics tables are not guaranteed at the Absolute Maximum Ratings. The “Recom-
mended Operating Conditions” table will define the conditions for actual device operation.
Note 3:
I
O
Absolute Maximum Rating must be observed.
Note 4:
Unused inputs must be held HIGH or LOW. They may not float.
DC Electrical Characteristics
Symbol
V
IH
V
IL
V
OH
Parameter
HIGH Level Input Voltage
LOW Level Input Voltage
HIGH Level Output Voltage
I
OH
= −100 µA
I
OH
= −8
mA
I
OH
= −12
mA
I
OH
= −18
mA
I
OH
= −24
mA
V
OL
LOW Level Output Voltage
I
OL
=
100
µA
I
OL
=
8 mA
I
OL
=
12 mA
I
OL
=
16 mA
I
OL
=
24 mA
I
I
I
OZ
I
OFF
Input Leakage Current
3-STATE Output Leakage
Power-Off Leakage Current
0
≤
V
I
≤
5.5V
0
≤
V
O
≤
5.5V
V
I
=
V
IH
or V
IL
V
I
or V
O
=
5.5V
Conditions
V
CC
(V)
2.3
−
2.7
2.7
−
3.6
2.3
−
2.7
2.7
−
3.6
2.3
−
3.6
2.3
2.7
3.0
3.0
2.3
−
3.6
2.3
2.7
3.0
3.0
2.3
−
3.6
2.3
−
3.6
0
V
CC
−
0.2
1.8
2.2
2.4
2.2
0.2
0.6
0.4
0.4
0.55
±5.0
±5.0
10
µA
µA
µA
V
V
T
A
= −40°C
to
+85°C
Min
1.7
2.0
0.7
0.8
Max
Units
V
V
3
www.fairchildsemi.com
74LCX16841
DC Electrical Characteristics
Symbol
I
CC
∆I
CC
Parameter
Quiescent Supply Current
Increase in I
CC
per Input
(Continued)
V
CC
(V)
2.3
−
3.6
2.3
−
3.6
2.3
−
3.6
T
A
= −40°C
to
+85°C
Min
Max
20
±20
500
µA
µA
Conditions
V
I
=
V
CC
or GND
3.6V
≤
V
I
, V
O
≤
5.5V (Note 5)
V
IH
=
V
CC
−0.6V
Units
Note 5:
Outputs disabled or 3-STATE only.
AC Electrical Characteristics
T
A
= −40°C
to
+85°C,
R
L
=
500Ω
Symbol
Parameter
V
CC
=
3.3V
±
0.3V
C
L
=
50 pF
Min
t
PHL
t
PLH
t
PHL
t
PLH
t
PZL
t
PZH
t
PLZ
t
PHZ
t
OSHL
t
OSLH
t
S
t
H
t
W
Setup Time, D
n
to LE
Hold Time, D
n
to LE
LE Pulse Width
2.5
1.5
3.3
Output to Output Skew (Note 6)
Output Disable Time
Propagation Delay
D
n
to O
n
Propagation Delay
LE to O
n
Output Enable Time
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
Max
5.5
5.5
5.5
5.5
6.5
6.5
6.5
6.5
1.0
1.0
2.5
1.5
3.3
3.0
2.0
3.8
V
CC
=
2.7V
C
L
=
50 pF
Min
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
Max
6.0
6.0
6.5
6.5
7.0
7.0
7.0
7.0
V
CC
=
2.5V
±
0.2V
C
L
=
30 pF
Min
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
Max
6.6
6.6
6.6
6.6
8.5
8.5
7.8
7.8
ns
ns
ns
ns
ns
ns
ns
ns
Units
Note 6:
Skew is defined as the absolute value of the difference between the actual propagation delay for any two separate outputs of the same device. The
specification applies to any outputs switching in the same direction, either HIGH-to-LOW (t
