ICL7137C/D+ datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > semiconductor> Other integrated circuit (IC)> ICL7137C/D+

Preview

ICL7137C/D+: DescriptionDisplay Drivers & Controllers; Categorysemiconductor Other integrated circuit (IC); File Size166KB，4 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html

Download Datasheet Parametric Compare View All

ICL7137C/D+ Overview

Display Drivers & Controllers

ICL7137C/D+ Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Maxim
Product Category	Display Drivers & Controllers

Preview

Download Datasheet

View All

ICL7137C/D+ Related Products

	ICL7137C/D+	ICL7137C/D	ICL7137CPL+	ICL7137CMH+D	ICL7137CQH+D
Description	Display Drivers & Controllers	Display Drivers & Controllers Low Power, 3 1/2 Digit ADC with Direct LED Drivers	LED Display Drivers Low-Pwr 3 1/2 Digit ADC w/Direct LCD Dvr	Display Drivers & Controllers Low-Power, 3 1/2 Digit A/D Converter	LED Display Drivers Low-Pwr 3 1/2 Digit ADC w/Direct LCD Dvr
Is it lead-free?	-	Contains lead	Lead free	Lead free	Lead free
Is it Rohs certified?	-	incompatible	conform to	conform to	conform to
Maker	-	Maxim	Maxim	Maxim	Maxim
Parts packaging code	-	DIE	DIP	QFP	LPCC
package instruction	-	DIE-24	DIP, DIP40,.6	QFP,	QCCJ, LDCC44,.7SQ
Contacts	-	24	40	44	44
Reach Compliance Code	-	not_compliant	compliant	compliant	compliant
ECCN code	-	EAR99	EAR99	EAR99	EAR99
Maximum analog input voltage	-	3.2 V	3.2 V	3.2 V	3.2 V
Minimum analog input voltage	-	2.6 V	2.6 V	2.6 V	2.6 V
Converter type	-	ADC, DUAL-SLOPE	ADC, DUAL-SLOPE	ADC, DUAL-SLOPE	ADC, DUAL-SLOPE
JESD-30 code	-	X-XUUC-N24	R-PDIP-T40	S-PQFP-G44	S-PQCC-J44
JESD-609 code	-	e0	e3	e3	e3
Nominal negative supply voltage	-	-5 V	-5 V	-	-5 V
Number of analog input channels	-	1	1	1	1
Number of digits	-	23	23	23	23
Number of functions	-	1	1	1	1
Number of terminals	-	24	40	44	44
Maximum operating temperature	-	70 °C	70 °C	70 °C	70 °C
Output bit code	-	BINARY	BINARY	BINARY	BINARY
Output format	-	PARALLEL, WORD	PARALLEL, WORD	PARALLEL, WORD	PARALLEL, WORD
Package body material	-	UNSPECIFIED	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	-	DIE	DIP	QFP	QCCJ
Encapsulate equivalent code	-	DIE OR CHIP	DIP40,.6	-	LDCC44,.7SQ
Package shape	-	UNSPECIFIED	RECTANGULAR	SQUARE	SQUARE
Package form	-	UNCASED CHIP	IN-LINE	FLATPACK	CHIP CARRIER
Peak Reflow Temperature (Celsius)	-	240	260	260	260
power supply	-	+-5 V	+-5 V	-	+-5 V
Certification status	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Nominal supply voltage	-	9 V	9 V	9 V	9 V
surface mount	-	YES	NO	YES	YES
technology	-	CMOS	CMOS	CMOS	CMOS
Temperature level	-	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal surface	-	TIN LEAD	Matte Tin (Sn)	MATTE TIN	Matte Tin (Sn)
Terminal form	-	NO LEAD	THROUGH-HOLE	GULL WING	J BEND
Terminal location	-	UPPER	DUAL	QUAD	QUAD
Maximum time at peak reflow temperature	-	NOT SPECIFIED	30	NOT SPECIFIED	NOT SPECIFIED
Factory Lead Time	-	-	6 weeks	7 weeks	8 weeks
length	-	-	52.07 mm	10 mm	16.585 mm
Humidity sensitivity level	-	-	1	3	3
Maximum seat height	-	-	5.08 mm	2.45 mm	4.57 mm
Terminal pitch	-	-	2.54 mm	0.8 mm	1.27 mm
width	-	-	15.24 mm	10 mm	16.585 mm
Base Number Matches	-	-	1	1	1
