SMD LAMP
FYLS-1206XX
■
Features:
・3.2mmx1.6mm
SMD, 1.1mm THICKNESS.
・STANDARD
BRIGHTNESS.
・LOW
POWER CONSUMPTION.
・WIDE
VIEWING ANGLE.
・IDEAL
FOR BACKLIGHT AND INDICATOR.
・PACKAGE
: REEL.
■
Part No.:
FYLS-1206Hx
FYLS-1206SRx
FYLS-1206LRx
FYLS-1206URx
FYLS-1206Ex
FYLS-1206Ax
FYLS-1206Yx
FYLS-1206Gx
Note:X = Len Color: C=Water Clear, D=Color Diffused, T=Color Trans
■
Description:
・Color
Code & Chip characteristics: (Test Condition: IF=20mA)
Peak
Wave
Length
(
λ
P
)
700nm
660nm
660nm
660nm
635nm
610nm
585nm
570nm
Spectral
Line
halfwidth(
△
λ1/2
)
90nm
20nm
20nm
20nm
35nm
35nm
35nm
30nm
Forward
Voltage(VF)
Unit:V
Typ
2.25
1.85
1.85
1.85
2.10
2.10
2.10
2.20
Max
2.60
2.20
2.20
2.20
2.50
2.50
2.50
2.50
Luminous
Intensity
(Iv)
Unit:ucd
500
3500
6000
7000
2500
2000
2000
2500
Emitting Color
Dice
Material
GaP/GaP
GaAlAs/GaAs,SH
AlGaAs,DH
GaAlAs/GaAs,DD
H
GaAsP/GaP
GaAsP
GaAsP/GaP
GaP/GaP
H
S
LR
UR
E
A
Y
G
Red
Hi Red
Super Red
Ultra Red
Orange
Amber
Yellow
Green
REV NO: V.1 PAGE: 1 OF 4
APPROVED : Ying Liming CHECKED :Hu Wei DRAWN: Zhan Wenqi
Ningbo Foryard Optoelectronics Co.,Ltd
No.115 Qixin Road Jiangdong District Ningbo 315051,Ningbo,Zhejiang, China
Tel:+86-574-87927870 fax:+86-574-87927917
Website:www.foryard.com
SMD LAMP
FYLS-1206XX
■
Electrical-optical characteristics: (Ta=25℃)
Parameter
Symbol
AlGaAs
GaAsP
AlGaInP
InGaN
120
100
30
Unit
mW
mA
mA
Power
P
ad
60
80
75
Dissipation
Peak Forward
I
pf
150
150
150
Current *
Continuous
I
af
25
30
30
Forward Current
Notes:
・*
Test Condition = Duty 0.1,10KHZ
■
Package configuration & Internal circuit diagram:
Notes:
・All
dimensions are in millimeters (inches)
・Tolerance
is
±0.25(0.01")unless
otherwise noted.
・Specificaions
are subject to change whitout notice.
■
Absolute maximum ratings (Ta=25℃)
Reverse Voltage
5V
Reverse Current
20µA
Operating Temperature Range
-40℃to+85℃
Storage Temperature Range
-40℃to+85℃
Lead Solder Temperature (1.6mm(1/16”
)from body) 230℃ for 5 Seconds
REV NO: V.1 PAGE: 2 OF 4
APPROVED : Ying Liming CHECKED :Hu Wei DRAWN: Zhan Wenqi
Ningbo Foryard Optoelectronics Co.,Ltd
No.115 Qixin Road Jiangdong District Ningbo 315051,Ningbo,Zhejiang, China
Tel:+86-574-87927870 fax:+86-574-87927917
Website:www.foryard.com
SMD LAMP
FYLS-1206XX
■
Typical electrical-optical characteristics curves:
1.0
(A)
(B)
(C)
(D)
(2)
(3)
(8)
(4)
(1) ( 6 )
(5)
(9)
(10)
0.5
0
350
400
450
500
550
600
650
700
750
800
850
900
950
1000
Wavelength(nm)
RELATIVE INTENSITY Vs WAVELENGTH(
λ
p)
(1) - GaAsP/GaAs 655nm/Red
(2) - GaP 570nm/Yellow Green
(3) - GaAsP/GaP 585nm/Yellow
(4) - GaAsp/GaP 635nm/Orange & Hi-Eff Red
(5) - GaP 700nm/Bright Red
(6) - GaAlAs/GaAs 660nm/Super Red
(8) - GaAsP/GaP 610nm/Super Red
(9) - GaAlAs 880nm
(10) - GaAs/GaAs & GaAlAs/GaAs 940nm
(A) - GaN/SiC 430nm/Blue
(B) - InGaN/SiC 470nm/Blue
(C) - InGaN/SiC 505nm/Ultra Green
(D) - InGaAl/SiC 525nm/Ultra Green
50
F ORWARD CURRENT(mA)
RELATIV E LUMINOUS INTE NSITY
3
2
1
0.5
0.2
0.1
-30
-20
-10
1
8
64 5
2 3
4.0
1
3.0
F ORWARD CURRENT(mA)
R ELATIVE LUMINOUS INTENSIT Y
50
40
30
20
10
0
40
30
20
10
0
1.2
1
6
2,4,8,A
3
5
2.0
5
B
1.0
0
20
40
60
80
100
1.6
2.0
2.4
2.6
3.0
20
40
60
80
100
FORWARD VOLTAGE (Vf)
FORWARD CURRENT VS.
FORWARD VOLTAGE
FORWARD CURRENT (mA)
RELATIVE LUMINOUS
INTENSITY VS. FORWARD
CURRENT
AMBIENT TEMPERATURE Ta(
℃
)
FORWARD CURRENT VS. AMBIENT
TEMPERATURE
1
5
4
2
3
3KHz
300KHz
1KHz
100KHz F-REFRESH RATE
10 10KHz
9
8
7
6
5
Ipeak MAX .
IDC M AX.
4
3
2
0
10
20
30
40
50
60
70
1
AMBIENT TEMPERATURE Ta(
℃
)
1
10
100
1000
10,000
Ipeak M AX.
IDC M AX.
3KHz
300Hz
30KHz
100KHz
10KHz 1KHz
100Hz
10
9
8
7
6
5
4
3
2
1
1
10
100
1000
10,000
tp-PULSE DURATION uS
(1,2,3,4,6,8,B.D.J.K)
tp-PULSE DURATION uS
(5)
NOTE:25
℃
free air temperature unless otherwise specified
REV NO: V.1 PAGE: 3 OF 4
APPROVED : Ying Liming CHECKED :Hu Wei DRAWN: Zhan Wenqi
Ningbo Foryard Optoelectronics Co.,Ltd
No.115 Qixin Road Jiangdong District Ningbo 315051,Ningbo,Zhejiang, China
Tel:+86-574-87927870 fax:+86-574-87927917
Website:www.foryard.com
SMD LAMP
FYLS-1206XX
Tape Specifications
Ｕ½½½：½½
Ｔ½½½½½½½½：±０．１
１．５０＋０．１０／－０
４．００±０．１０
２．００±０．０５
１．７５±０．１０
０．２３±０．０５
８．００±０．２０
Ｃ½½½½½½ ½½½½
３．５０±０．０５
５
３．５±０．１０
４．００±０．１０
１．８８±０．１０
１．００±０．０１
１．２７±０．１０
９
６０＋０．５／－０
１７８±１．０
９．０±０．５
Ｌ½½½½ ½½½½½½½½ ½½½½½½½½
１２．０±０．１５
REV NO: V.1 PAGE: 4 OF 4
APPROVED : Ying Liming CHECKED :Hu Wei DRAWN: Zhan Wenqi
Ningbo Foryard Optoelectronics Co.,Ltd
No.115 Qixin Road Jiangdong District Ningbo 315051,Ningbo,Zhejiang, China
Tel:+86-574-87927870 fax:+86-574-87927917
Website:www.foryard.com
１３．５±０．５
ＰＳ
