TISP4290F3DR

Description
Sidacs
CategoryAnalog mixed-signal IC    Trigger device
File Size335KB,13 Pages
ManufacturerBourns
Websitehttp://www.bourns.com
Download Datasheet Parametric Compare View All

TISP4290F3DR Online Shopping

Suppliers Part Number Price MOQ In stock
TISP4290F3DR - - View Buy Now

TISP4290F3DR Overview

Sidacs

TISP4290F3DR Parametric

Parameter NameAttribute value
MakerBourns
Parts packaging codeSOIC
package instructionSMALL OUTLINE, R-PDSO-G8
Contacts8
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresUL RECOGNIZED
Maximum breakover voltage290 V
ConfigurationSINGLE
Maximum off-state DC voltage220 V
JESD-30 codeR-PDSO-G8
On-state non-repetitive peak current4 A
Number of components1
Number of terminals8
Maximum operating temperature150 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Certification statusNot Qualified
surface mountYES
Terminal formGULL WING
Terminal locationDUAL
Trigger device typeSILICON SURGE PROTECTOR
TISP4240F3, TISP4260F3, TISP4290F3, TISP4320F3, TISP4380F3
SYMMETRICAL TRANSIENT
VOLTAGE SUPPRESSORS
Copyright © 1997, Power Innovations Limited, UK
MARCH 1994 - REVISED SEPTEMBER 1997
TELECOMMUNICATION SYSTEM SECONDARY PROTECTION
q
Ion-Implanted Breakdown Region
Precise and Stable Voltage
Low Voltage Overshoot under Surge
DEVICE
‘4240F3
‘4260F3
‘4290F3
‘4320F3
‘4380F3
V
DRM
V
180
200
220
240
270
V
(BO)
V
240
260
290
320
380
D PACKAGE
(TOP VIEW)
T
T
T
T
1
2
3
4
8
7
6
5
R
R
R
R
MDXXAI
Specified ratings require the connection
of pins 1, 2, 3 and 4 for the T terminal.
SL PACKAGE
(TOP VIEW)
q
Planar Passivated Junctions
Low Off-State Current < 10 µA
Rated for International Surge Wave Shapes
WAVE SHAPE
2/10 µs
8/20 µs
10/160 µs
10/560 µs
0.5/700 µs
10/700 µs
10/1000 µs
STANDARD
FCC Part 68
ANSI C62.41
FCC Part 68
FCC Part 68
RLM 88
FTZ R12
VDE 0433
CCITT IX K17/K20
REA PE-60
I
TSP
A
175
120
60
45
38
50
50
50
35
4
T
1
q
R
2
MDXXAH
MD4XAA
device symbol
D PACKAGE
T
3
T
2
T
1
T
1
SL PACKAGE
T
q
Surface Mount and Through-Hole Options
5
PACKAGE
Small-outline
Small-outline taped
and reeled
Single-in-line
PART # SUFFIX
D
DR
SL
Terminals T and R correspond to the
alternative line designators of A and B
R
6
R
7
R
8
R
2
R
SD4XAE
q
UL Recognized, E132482
description
These high voltage symmetrical transient voltage
suppressor devices are designed to protect two
wire telecommunication applications against
transients caused by lightning strikes and a.c.
power lines. Offered in five voltage variants to
meet battery and protection requirements they
are guaranteed to suppress and withstand the
listed international lightning surges in both
polarities.
Transients are initially clipped by breakdown
clamping until the voltage rises to the breakover
level, which causes the device to crowbar. The
high crowbar holding current prevents d.c.
latchup as the current subsides.
These monolithic protection devices are
fabricated in ion-implanted planar structures to
ensure precise and matched breakover control
and are virtually transparent to the system in
normal operation
The small-outline 8-pin assignment has been
carefully chosen for the TISP series to maximise
the inter-pin clearance and creepage distances
which are used by standards (e.g. IEC950) to
establish voltage withstand ratings.
PRODUCT
INFORMATION
Information is current as of publication date. Products conform to specifications in accordance
with the terms of Power Innovations standard warranty. Production processing does not
necessarily include testing of all parameters.
1

TISP4290F3DR Related Products

TISP4290F3DR TISP4260F3DR-S TISP4290F3DR-S TISP4380F3DR-S TISP4260F3DR
Description Sidacs Sidacs Sidacs PROTECTOR - SINGLE BIDIRECTIONAL Sidacs PROTECTOR - SINGLE BIDIRECTIONAL Sidacs
Maker Bourns Bourns Bourns Bourns Bourns
Parts packaging code SOIC SOIC SOIC SOIC SOIC
package instruction SMALL OUTLINE, R-PDSO-G8 SMALL OUTLINE, R-PDSO-G8 PLASTIC, SO-8 PLASTIC, SO-8 SMALL OUTLINE, R-PDSO-G8
Contacts 8 8 8 8 8
Reach Compliance Code unknown compliant compliant unknown unknown
ECCN code EAR99 EAR99 EAR99 EAR99 EAR99
Other features UL RECOGNIZED UL RECOGNIZED UL RECOGNIZED UL RECOGNIZED UL RECOGNIZED
Maximum breakover voltage 290 V 260 V 290 V 380 V 260 V
Configuration SINGLE SINGLE SINGLE SINGLE SINGLE
Maximum off-state DC voltage 220 V 200 V 220 V 270 V 200 V
JESD-30 code R-PDSO-G8 R-PDSO-G8 R-PDSO-G8 R-PDSO-G8 R-PDSO-G8
On-state non-repetitive peak current 4 A 4 A 4 A 4 A 4 A
Number of components 1 1 1 1 1
Number of terminals 8 8 8 8 8
Maximum operating temperature 150 °C 150 °C 150 °C 150 °C 150 °C
Minimum operating temperature -40 °C -40 °C -40 °C -40 °C -40 °C
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form SMALL OUTLINE SMALL OUTLINE SMALL OUTLINE SMALL OUTLINE SMALL OUTLINE
Certification status Not Qualified Not Qualified Not Qualified Not Qualified Not Qualified
surface mount YES YES YES YES YES
Terminal form GULL WING GULL WING GULL WING GULL WING GULL WING
Terminal location DUAL DUAL DUAL DUAL DUAL
Trigger device type SILICON SURGE PROTECTOR SILICON SURGE PROTECTOR SILICON SURGE PROTECTOR SILICON SURGE PROTECTOR SILICON SURGE PROTECTOR
Is it lead-free? - Lead free Lead free Lead free -
