MIC5387-SGFYMT-TR

Description
LDO Regulator Pos 3.3V1.8V1.5V 0.15A/0.15A/0.15A 6-Pin TDFN EP T/R
File Size554KB，12 Pages
ManufacturerMicrochip
Websitehttps://www.microchip.com
Environmental Compliance
Download Datasheet Parametric Compare View All

MIC5387-SGFYMT-TR Online Shopping

Suppliers Part Number Price MOQ In stock
MIC5387-SGFYMT-TR - - View Buy Now

MIC5387-SGFYMT-TR Overview

LDO Regulator Pos 3.3V1.8V1.5V 0.15A/0.15A/0.15A 6-Pin TDFN EP T/R

MIC5387-SGFYMT-TR Parametric

Parameter NameAttribute value
EU restricts the use of certain hazardous substancesCompliant
ECCN (US)EAR99
Part StatusActive
TypeLDO
Number of Outputs3
PolarityPositive
Accuracy (%)±2
Output TypeFixed
Output Voltage (V)3.3|1.8|1.5
Maximum Output Current (A)0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15|0.15
Minimum Input Voltage (V)2.5
Maximum Input Voltage (V)5.5
Maximum Dropout Voltage @ Current (V)0.11@50mA|0.31@150mA|0.135@50mA|0.38@150mA
Line Regulation0.02%(Typ)
Load Regulation0.65%(Typ)
Maximum Quiescent Current (mA)0.12
Junction to Ambient92.4°C/W
Special FeaturesCurrent Limit|Excellent Line and Load Transient Response|Thermal Shutdown Protection
Minimum Operating Temperature (°C)-40
Maximum Operating Temperature (°C)125
PackagingTape and Reel
Supplier PackageTDFN EP
Pin Count6
MountingSurface Mount
Package Height0.55(Max)
Package Length1.6
Package Width1.6
PCB changed6

Preview

Download Datasheet
MIC5387
Ultra-Small Triple 150mA Output LDO
General Description
The MIC5387 is an advanced, general-purpose, triple
linear regulator offering high power supply rejection
(PSRR) in an ultra-small, 6-pin, 1.6mm x 1.6mm Thin
MLF
®
package. The MIC5387 is capable of 150mA from
each output and offers high PSRR, making it an ideal
solution for any portable electronic application.
Ideal for battery powered applications, the MIC5387 offers
2% initial accuracy, low dropout voltage (180mV @
150mA), and low ground current (typically 32µA per
output).
The MIC5387 is available in a lead-free (RoHS compliant)
1.6mm x 1.6mm 6-pin Thin MLF
®
occupying only 2.56mm
2
of PCB area, a 36% reduction in board area compared to a
2mm x 2mm Thin MLF
®
package.
The MIC5387 has an operating junction temperature range
of
−40°C
to
+125°C.
Datasheets and support documentation can be found on
Micrel’s web site at: www.micrel.com.
Features
•
•
•
•
•
•
•
•
Input voltage range: 2.5V to 5.5V
150mA guaranteed output current for each output
Stable with ceramic output capacitors
Low dropout voltage: 180mV @ 150mA
Excellent Load/Line Transient Response
Low quiescent current: 32µA per LDO
High PSRR: 70dB
High output accuracy
– ±2% initial accuracy
•
Thermal-shutdown and current-limit protection
•
Available in a tiny 6-pin 1.6mm x 1.6mm Thin MLF
®
Applications
•
•
•
•
Mobile phones
Digital cameras
GPS, PDAs, PMP
Portable electronics
___________________________________________________________________________________________________________
Typical Application
MLF and
MicroLeadFrame
are registered trademarks of Amkor Technology, Inc.
Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1 (408) 944-0800 • fax + 1 (408) 474-1000 • http://www.micrel.com
April 2010
M9999-041610-A
