Conductive Polymer Hybrid Capacitors
HBW Series
Features
125 , 4,000 hours assured
Low
ESR and High ripple current
RoHS Compliance
HBW
Specifications
Items
Category Temperature Range
Capacitance Tolerance
Leakage Current (at 20
Tan (at 120Hz, 20
)
)
I = 0.01CV or 3 (
Where,
Performance
-55 ~ +125
±20%
A) whichever is greater (after 2 minutes)
V = rated DC working voltage in V
Marking color: Dark Green
(at 120Hz, 20
)
See Standard Ratings
Test Time
Capacitance Change
4,000 Hrs
Within ±30% of initial value
Less than 200% of specified value
Endurance
Shelf Life Test
ESR
Less than 200% of specified value
Leakage Current
Within specified value
* The above specifications shall be satisfied when the capacitors are restored to 20 after the rated voltage applied with rated
ripple current for 4,000 hours at 125 .
* After storage for 1,000 hours at 125
±
2
with no voltage applied and then being stabilized at 20 ,capacitors shall meet the
limits specified in Endurance. (With voltage treatment)
Capacitance Change
ESR
Leakage Current
Within ±10% of initial value
Within specified value
Within specified value
Within specified value
Hybrid
Resistance to Soldering Heat
(Please refer to page 25 for
reflowsoldering conditions)
Ripple Current and
Frequency Multipliers
Frequency (Hz)
Multiplier
120
f < 1k
0.10
1k
f < 10k
0.3
10k
f < 100k
0.6
100k
f < 500k
1.0
Diagram of Dimensions
D
±
0.5
B
±
0.2
Lead Spacing and Diameter
D
6.3
0.4 max
Unit: mm
B
6.6
6.6
8.4
8.4
10.4
10.4
C
7.2
7.2
9.0
9.0
11.0
11.0
W
0.5 ~ 0.8
0.5 ~ 0.8
0.7 ~ 1.1
0.7 ~ 1.1
0.7 ~ 1.3
0.7 ~ 1.3
P ± 0.2
2.0
2.0
3.1
3.1
4.7
4.7
L
5.8 ± 0.3
7.7 ± 0.3
10.0 ± 0.5
12.0 ± 0.5
10.0 ± 0.5
12.5 ± 0.5
A
6.6
6.6
8.4
8.4
10.4
10.4
6.3
8
8
10
10
P
C
±
0.2
Marking
D = 6.3 mm
Negative
polarity
D = 8 ~ 10 mm
Date code
Rated cap.
Rated voltage
& Series code
A5
56
25W
Negative
polarity
A5
HBW
270
35V
Date code
Series name
Rated cap
.
Rated voltage
84
