SPD62R
SH
DA
H)
(µ
E
MB
NU
0%
±2
)
Hz
(k
Shielded Surface Mount Inductors
R*
-122M
-242M
-352M
-472M
-682M
-103M
-123M
-153M
-183M
-223M
-273M
-333M
-393M
-473M
-563M
-683M
-823M
-104M
-124M
-154M
-184M
-224M
-274M
-334M
SERIES SPD62 FERRITE CORE & SLEEVE
1.2
100
0.08
2.4
100
0.10
3.5
100
0.12
4.7
100
0.15
6.8
100
0.17
10
100
0.18
12
100
0.20
15
1.0
0.30
18
1.0
0.35
22
1.0
0.40
27
1.0
0.45
33
1.0
0.50
39
1.0
0.70
47
1.0
0.75
56
1.0
0.85
68
1.0
1.20
82
1.0
1.45
100
1.0
1.60
120
1.0
1.70
150
1.0
1.80
180
1.0
2.10
220
1.0
2.20
270
1.0
3.00
330
1.0
3.30
3.50
2.80
2.50
2.00
1.80
1.40
1.30
1.20
1.10
1.00
0.94
0.82
0.78
0.70
0.68
0.56
0.50
0.41
0.39
0.37
0.35
0.32
0.29
0.22
Actual Size
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
Physical Parameters
Inches
A
0.244 ± 0.012
B
0.260 ± .012
C
0.118 Max.
D
0.181 Ref. only
E
0.059 ± 0.007
F
0.050 ± 0.007
G
0.015 Ref. only
Millimeters
6.2 ± 0.3
6.6 ± 0.3
3.0 Max.
4.60 Ref. only
1.5 ± 0.2
1.27 ± 0.2
0.38 Ref. only
Marking
For values lower than 10
μ
H the R indicates a decimal point and
the remaining digits indicate the inductance in
μ
H. For values 10
μ
H and
above, the first two digits indicate the inductance in
μ
H and the third digit
indicates the number of trailing zeros where a zero indicates that there are
no trailing zeros.
Example: SPD62R-122M (1.2
μ
H)
1R2
Example: SPD62R-334M (330
μ
H)
331
Mechanical Configuration
Units designed for surface
mounting; ferrite core and ferrite sleeve
Operating temperature range
–55°C to +125°C
Application Frequency Range
Values 1.2µH to 12µH to 1.0 MHz Min.
Values above 12µH to 300 kHz Min.
Current Rating at 25°C Ambient
The maximum DC
current that will cause a 40°C maximum temperature rise
and where the inductance will not decrease by more than
10% from its zero DC value
Packaging
Tape & reel (16mm):
13" reel, 1500 pieces max.; 7" reel not available
Note:
No vias and traces in restricted area.
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com
6/2014
