Conductive Polymer Tantalum Solid Capacitors
Surface Mount Type
Series :
TH
Features
●
Guaranteed
at 125 °C, 1000h
●
RoHS compliance, Halogen free
Specifications
Size code
D2E
D2
D3L
Category temperature range
–55 °C to +125 °C
Rated voltage range
2.5 V.DC to 6.3 V.DC
2.5 V.DC to 10 V.DC
4 V.DC to 6.3 V.DC
Category voltage range 1.6 V.DC to 4.0 V.DC 1.6 V.DC to 6.3 V.DC 2.5 V.DC to 4.0 V.DC
Rated capacitance range
150 µF to 330 µF
68 µF to 220 µF
220 µF to 330 µF
Capacitance tolerance
±20 % (120 Hz / + 20 °C)
Leakage current
Please see the attached characteristics list
Dissipation factor (tan
d)
Please see the attached characteristics list
Surge voltage (V.DC)
Rated voltage
×
1.15
+125 °C 1000h, category voltage appled
Capacitance change Within ±20 % of the initial value
Endurance
tan
d
<
2 times of the initial limit
DC leakage current
<
2 times of the initial limit
+60 °C, 90 % to 95 %, 500 h, No-applied voltage
Capacitance change Within +40 %, −20 % of the initial value
Damp heat
(Steady State)
tan
d
<
1.5 times of the initial limit
DC leakage current
<
3 times of the initial limit
D4
6.3 V.DC to 10 V.DC
4.0 V.DC to 6.3 V.DC
220 µF to 470 µF
Marking
D2E, D3L Size
Polarity marking(+) R.Cap. code
Dimensions (not to scale)
L
D2, D4 Size
Polarity marking(+)
R.Cap. code
H
S
S
W
W1
½2
R. Voltage code
Lot. No.
R. Voltage code
Lot. No.
Unit : mm
Size code
L±0.3
½1
R. Voltage (V.DC)
Code
2.5
e
4.0
g
6.3
j
10
A
D2E
D2
D3L
D4
7.3
7.3
7.3
7.3
W±0.2 H±0.1
4.3
1.8
4.3
1.9
4.3
2.8
4.3
3.8
S±0.2
1.3
1.3
1.3
1.3
W1±0.1
2.4
2.4
2.4
2.4
½
Externals of figure are the reference.
½
1 ±0.2 : D2
½
2 ±0.2 :D3L, D4
Characteristics list
Rated Rated Category Category Rated
Series voltage temp. voltage temp. capacitance
(V.DC) (°C) (V.DC) (°C) (µF)
4.0
THB
6.3
10
THC
2.5
6.3
10
2.5
THE
4.0
6.3
105
105
105
105
105
105
105
105
105
105
105
105
105
105
105
105
105
2.5
4.0
4.0
4.0
6.3
6.3
1.6
4.0
6.3
1.6
1.6
1.6
2.5
2.5
2.5
4.0
4.0
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
330
220
330
470
220
330
220
150
68
330
220
150
Case size (mm)
L
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
7.3
W
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
4.3
H
2.8
2.8
3.8
3.8
3.8
3.8
1.9
1.9
1.9
1.8
1.8
1.8
1.8
1.8
1.8
1.8
1.8
Specifications
Size Ripple
½1
ESR
½2
code current
tan
d
½3
(mΩ max.)
(mAr.m.s.)
D3L
D4
2000
2000
3000
3000
3000
3000
1700
1900
1700
3100
2800
2400
3100
2800
2400
2800
2400
40
40
40
35
40
35
45
40
45
15
18
25
15
18
25
18
25
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
Standard
LC
½4
(µA)
132.0
138.6
207.9
296.1
220.0
330.0
55.0
94.5
68.0
82.5
82.5
82.5
88.0
88.0
88.0
94.5
94.5
Part number
4THB330ML
6THB220ML
6THB330M
6THB470M
10THB220M
10THB330M
2R5THC220M
6THC150M
10THC68M
2R5THE330MF
2R5THE330MI
2R5THE330M
4THE220MF
4THE220MI
4THE220M
6THE150MI
6THE150M
Min.
Packaging Q'ty
(pcs)
2500
2500
2000
2000
2000
2000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
3000
D2
D2E
½1
Ripple current (100 kHz/ +45 °C ),
½2
ESR (100 kHz/+20 °C)
½3
tan
d
(120 Hz/+20 °C)
½4
After 5 minutes
◆
Please refer to each page in this catarog for “Reflow conditions” and “Taping specifications”.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
01 Nov. 2015
Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Panasonic
:
6THB220ML 6THB330M 10THB220M 10THB330M 6THB470M 2R5THC220M 2R5THE330MI 4THB330ML
4THE220MI 4THE220M 2R5THE330M 6THC150M 4THE220MF 10THC68M 2R5THE330MF 6THE150MI
6THE150M
