TVS Diode Arrays
(SPA
®
Diodes)
General Purpose ESD Protection - SP723 Series
Absolute Maximum Ratings
Parameter
Continuous Supply Voltage, (V+) - (V-)
Forward Peak Current, I
IN
to V
CC
, I
IN
to
GND (Refer to Figure 5)
Peak Pulse Current, 8/20µs
Rating
+35
±4, 100µs
±7
Units
V
A
A
Thermal Information
Parameter
Thermal Resistance (Typical, Note 1)
PDIP Package
SOIC Package
Storage Temperature Range
Maximum Junction Temperature (Plastic
Package)
Lead Temperature
(Soldering 20-40s) (SOIC Lead Tips Only)
Rating
θ
JA
160
170
-65 to 150
150
260
Units
o
C/W
o
o
C/W
C/W
o
o
C
C
C
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause
permanent damage to the device. This is a stress only rating and operation of the device
at these or any other conditions above those indicated in the operational sections of this
specification is not implied.
Note:
ESD Ratings and Capability (Figure 1, Table 1)
Load Dump and Reverse Battery (Note 2)
o
1.
θ
JA
is measured with the component mounted on an evaluation PC board in free air.
Electrical Characteristics
Parameter
Operating Voltage Range,
V
SUPPLY
=[(V+)-(V-)]
Forward Voltage Drop
IN to V-
IN to V+
Input Leakage Current
Quiescent Supply Current
Equivalent SCR ON Threshod
Equivalent SCR ON Resistance
Input Capacitance
Input Switching Speed
T
A
= -40
o
C to 105
o
C, V
IN
= 0.5V
CC
, Unless Otherwise Specified
Symbol
V
SUPPLY
Test Conditions
Min
-
Typ
2 to 30
Max
-
Units
V
V
FWDL
V
FWDH
I
IN
I
QUIESCENT
I
IN
=2A(Peak Pulse)
-
-
-20
-
2
2
5
50
1.1
0.5
5
2
-
-
20
200
-
-
-
-
V
V
nA
nA
V
Ω
PF
ns
Note 3
V
FWD
/I
FWD
; Note 3
C
IN
t
ON
-
-
-
-
Notes:
2. In automotive ans battery operated systems, the power supply lines should be externally protected for load dump and reverse battery. When the V+ and V- Pins are connected to the same
supply voltage source as the device or control line under protection, acurrent limiting resistor should be connectied in series between the external supply and the SP723 supply pins to
limit reverse battery current to within the rated maximum limits. Bypass capacitors of typically 0.01µF or larger from the V+ and V- Pins to ground are recommended.
3. Refer to the Figure 3 graph for determine peak current and dessipation under EOS conditions.
Typical Application of the SP723
(Application as an Input Clamp for Over-voltage, Greater than 1V
BE
Above V+ or less than -1V
BE
below V-)
+V
CC
+V
CC
INPUT
DRIVERS
OR
SIGNAL
SOURCES
LINEAR OR
DIGITAL IC
INTERFACE
IN 1 - 3
IN 5 - 7
TO +V
CC
V+
SP723
V-
SP723 INPUT PROTECTION CIRCUIT (1 OF 6 SHO WN)
FIGURE 4. TYPICAL APPLICA TION OF THE SP723 AS AN INPUT CLAMP FOR OVER-VOLTAGE, GREATER THAN 1V
