MALE PCB
PINS
PRINTED CIRCUIT PINS
3231
3231-X-00-XX-00-00-08-0
Swage mount in .094 hole
3609
Basic Part
Number
Board
Thickness
Length
V
3609-X-07-XX-00-00-08-0
Wire crimp termination. Accepts wire
sizes 16 AWG Max. / 20 AWG Min.
Basic Part
Number
Pin
Length
A
3231-2
3231-3
3231-4
.062
.094
.125
.094
.125
.156
3609-1
3609-2
3609-3
.200
.375
.500
3601
3601-X-07-XX-00-00-08-0
Wire crimp termination. Accepts wire
sizes 20 AWG Max. / 24 AWG Min.
3133/3138/3152
31XX-X-00-XX-00-00-08-0
Specify board thickness
Swage mount in .064 hole
Basic Part
Number
Pin
Length
A
Basic Part
Number
Pin
Length
A
3152-X
3133-X
3138-X
-X-
.094
.219
.282
Length
V
3601-1
3601-2
3601-3
.200
.375
.500
Board
Thickness
1
2
3
4
.031
.062
.094
.125
.063
.094
.125
.156
3144
3144-X-00-XX-00-00-08-0
Swage mount in .067 hole
3233
Basic Part
Number
Board
Thickness
Length
V
3233-2-00-XX-00-00-08-0
Swage mount in .094 hole
For a .062 thick board
0520
0520-0-00-XX-00-00-03-0
Annealed
Wire crimp termination. Accepts wire
sizes 20 AWG Max. / 24 AWG Min.
3144-1
3144-2
3144-3
.031
.062
.094
.053
.084
.115
SPECIFICATIONS:
Pin Material:
Brass Alloy 360, 1/2 Hard
( Except swage pins which are annealed )
Dimensions: Inches
Tolerances On:
Lengths: ± .005
Diameters: ± .002
Angles:
±2°
RoHS - 2
2011/65/EU
ORDER CODE: XXXX - X - 0X -
XX
- 00 - 00 - XX - 0
BASIC PART #
SPECIFY PIN FINISH:
01
200
”
TIN/LEAD OVER NICKEL
80
200
”
TIN OVER NICKEL (RoHS)
15
10
”
GOLD OVER NICKEL (RoHS)
21
20
”
GOLD OVER NICKEL (RoHS)
34
50
”
GOLD OVER NICKEL (RoHS)
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 223 | MALE PCB PINS
