EuroMag Series PCB Mount Pluggable Terminal Blocks
Terminal Blocks:
Single Row
EM2575 Series
EuroMag Terminal Blocks
Header (Mates with EM2565, EM2488,
EM3108 Series); 5.08 Centers
SPECIFICATIONS
Rating:
16A, 300V
Center Spacing:
0.20” (5.08mm)
Consult factory for 0.40” (10.16mm)
Housing Material:
UL rated 94V0 Thermoplastic
Contact Material:
Brass Tin-Plated
Operating Temperature:
105°C (221°F) max., -40°C
(-40°F) min.
Recommended PCB Hole Diameters:
0.055" (1.40mm)
Construction:
Mold-to-Length
Agency Information:
File E62622; CE Certified
EM257512HC
EM257506HO
EuroMag Series
Plug & Header
EM257512VC
Edge Connectors,
One-Sided Boards
Poles
2
3
4
5
6
7
8
9
10
11
12
13
Open
L (mm)
10.16
15.24
20.32
25.40
30.48
35.56
40.64
45.72
50.80
55.88
60.96
66.04
Closed
L (mm)
12.08
17.16
22.24
27.32
32.40
37.48
42.66
47.64
62.72
67.80
62.88
67.96
Poles
14
15
16
17
18
19
20
21
22
23
24
Open
L (mm)
71.12
76.20
81.28
86.36
91.44
96.52
101.60
106.68
111.76
116.84
121.92
Closed
L (mm)
73.04
78.12
83.20
88.28
93.36
98.44
103.52
105.60
113.68
118.76
123.84
EM257506VO
Dimensions - mm (in)
HORIZONTAL -
OPEN
HORIZONTAL -
CLOSED
Compliance
References
4.5+0.3
_
(0.177")
12+0.3
_
(0.472")
8.3+0.3
_
(0.327")
1+0.1
_
(0.039")
L+0.5
_
L+0.5
_
1.8+0.3
_
(0.071")
5.08+0.1
_
(0.200")
1.00+0.1
_
(0.039")
5.08+0.1
_
(0.200")
Ø1.5
(Ø 0.059")
12+0.3
_
(0.472")
1.8+0.3
_
(0.071")
To convert to inches, divide by 25.4
PCB Hole Layout
5.08+0.1
_
(0.200")
VERTICAL -
OPEN
1.00±0.1
[0.039]
VERTICAL -
CLOSED
5.08±0.1
(0.200")
3.8±0.3
(0.150")
1±0.1
(0.039")
12±0.3
(0.472")
8.3±0.3
(0.327")
L±0.5
L±0.5
4.5±0.3
(0.177")
Ø1.5
(Ø 0.059")
PCB Hole Layout
3.8±0.3
(0.150")
Part Numbering System
EM25 75
nnnnnn nn
Series
02
to
24
# of Poles
Orientation
n
n
Side Base
Mating Plugs:
EM2565 pg.
89
EM2488 pg.
90
EM3108 pg.
91
H
- horizontal
V
- vertical
O
- open
C
- closed
8.3±0.3
(0.327")
5.08±0.1
(0.200")
For additional product information, visit
www.eaton.com/connectors
92
