Liquid Tight Cordgrips
NO O-RING
REQUIRED!
Heyco -Tite
Liquid Tight Cordgrips
®
Pigtail
™
, PG* Hubs
with Integral Sealing Ring
The Ultimate in Liquid Tight Strain Relief Protection
CABLE DIA. RANGE
Minimum
in.
.065
.115
.065
.105
.069
.230
.095
.170
.180
.260
.250
.250
mm.
1,7
2,9
1,7
2,7
1,8
5,8
2,4
4,3
4,6
6,6
6,4
6,4
Maximum
in.
.210
.250
.230
.315
.250
.290
mm.
5,3
6,4
5,8
8,0
6,6
7,4
PART NO.
Including
Nylon Nut**
No Nut
Black
Gray Black
M3464
M3237
M3466
M3240
M3468
M3243
M4526
M3246
M4528
M3249
M3465
M3238
M3467
M3241
M3469
M3244
M4527
M3247
M4529
M3250
DESCRIPTION
PART DIMENSIONS
A
B
C
E
or Clearance Max. O.A. Thread Wrenching
Hole Dia. Length
Length
Nut Flats
in. mm. in. mm. in. mm. in. mm.
.492 12,5 2.44 62,0 .32
.599 15,2 2.77 70,4 .32
.733 18,6 3.46 87,9 .38
8,1
8,1
9,7
.63 16,0
.82 20,8
.94 23,9
.98 24,9
M4780
Flex RLTCG 7
M4778
Flex LTCG 7
M4784
Flex RLTCG 9
M4782
Flex LTCG 9
M4788
Flex RLTCG 11
M4786
Flex LTCG 11
M4530
Flex RLTCG 13.5
M4790
Flex LTCG 13.5
M4532
Flex RLTCG 16
M4792
Flex LTCG 16
-
-
Flex RLTCG 21 ST
Flex LTCG 21 ST
.400 10,2
.450 11,4
.400 10,2
.545 13,8
.804 20,4 3.89 98,8 .41 10,4
.886 22,5 4.37 111,0 .44 11,2 1.06 26,9
1.115 28,3 4.95 125,7 .43 10,9 1.30 33,0
1.115 28,3 5.04 128,0 .52 13,2 1.30 33,0
.490 12,4
M3478ST M3479ST
.705 17,9
M3245ST M3248ST
.490 12,4
.705 17,9
M3478
M3245
M3479
M3248
.435 11,1
.435 11,1
M4796
Flex RLTCG 21
M4794
Flex LTCG 21
Standard colors black and gray.
*Steel conduit threads per DIN 40430, see page 3-56
**Nylon locknuts shipped unassembled
.43˝ (10,9 mm) Shorty LTCG Thread Length.
For No Nut Part Nos. in gray color please visit our Cordgrip product section at heyco.com
B
D***
C
A
E
SUGGESTED
CLEARANCE HOLE
FOR NONTHREADED
MOUNTING
SEALING NUT WITH
FLEX-PROTECTOR EXTENDER
INTEGRAL SEALING RING
•
Flexible Pigtail extender prevents sharp
bends and extends cable life.
•
Integral Sealing Ring ensures a
superior seal at the clearance or
threaded mounting hole location,
every time.
•
Widest range of approved cable
diameters.
•
IP 68 rated.
•
Approved for
NEMA 4, 4X, 6 and 6P
applications.
•
Ratchet design of sealing nut
assembly provides superior anti-
vibration protection and ensures
a firm grip on the cable.
•
Acme threads on body prevent
skipping and speed installation.
•
All nylon construction with Buna N or
TPE sealing gland resists salt water,
weak acids, gasoline, alcohol, oil,
grease, and common solvents.
(This feature is not assessed by UL.)
•
Multiple sizes for flexible cord
diameters ranging from .065˝ (1,7 mm)
to .705˝ (17,9 mm).
•
We recommend using the fitting with
the smallest maximum diameter that
will fit your application.
•
Unassembled Nylon Locknuts
INCLUDED.
•
For Heyco Liquid Tight Threaded Plugs,
see page 3-49.
•
Consult Heyco for cordgrips molded
in other colors.
***Consult Heyco for Wrenching Nut Thickness “D”
Material
Certifications
Flammability Rating
Temperature Range
IP Rating
Nylon 6/6 w/Buna N or TPE Sealing Gland
Listed under Underwriters’ Laboratories File E51579
Recognized under Components Program of Underwriters’ Laboratories
File E51579
Certified by Canadian Standard Association File 93876C
Approved for NEMA 4, 4X, 6 and 6P Applications
94V-2
Static -40°F (-40°C) to 239°F (115°C)
Dynamic -4°F (-20°C) to 212°F (100°C)
IP 68 (70 PSI, 5 BAR)
Quick
Specs
3-6
