Part Number:
Status:
Overview:
Description:
0476230001
Active
DisplayPort* and Mini DisplayPort Interconnect System
0.50mm Pitch DisplayPort* Sink Type Midplane Male Receptacle, Right Angle, Surface
Mount, 0.76µm Gold (Au) Plating, 20 Circuits, with extended side-Surface Mount Tabs,
High Temperature version, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-47272-001-001 (PDF)
General
Product Family
Series
Application
Component Type
Overview
Product Name
Type
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Gender
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Ports
Temperature Range - Operating
Termination Interface: Style
Waterproof / Dustproof
Electrical
Current - Maximum per Contact
Grounding to Panel
Shield Type
Shielded
Packaging Specification PK-47623-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
I/O Connectors
47623
Wire-to-Board
Receptacle
DisplayPort* and Mini DisplayPort Interconnect System
DisplayPort*
N/A
883906100810
20
20
Black
Male
Yes
Yes
Copper Alloy
Gold
Tin-Bismuth
High Temperature Thermoplastic
2.270/g
2
Right Angle
No
Yes
1.56mm
Embossed Tape on Reel
Yes
0.50mm
0.50mm
0.762µm
1.016µm
Yes
Yes
1
-20°C to +85°C
Surface Mount
No
0.5A
Yes
Full Shield
Yes
Search Parts in this Series
47623 Series
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
* DisplayPort is a Trademark of VESA
40V AC
003
REFLOW
002
250
PK-47623-001
PS-47272-001-001
SD-47623-001
