Phototransistors
PNZ158
(PN158)
Silicon planar type
For optical control systems
2.9
±0.25
Unit: mm
4.5
±0.3
(φ2.4)
(2.4) (1.5)
Not soldered
■
Features
•
High sensitivity
•
Fast response: t
r
= 4
µs
(typ.)
•
Wide spectral sensitivity characteristics, suited for detecting various
kinds of LEDs
•
Small size, thin side-view type package
3.9
±0.3
(1.2)
(0.9)
1.7
±0.2
(0.8)
12.8 min.
2.8
2-1.2
±0.3
■
Absolute Maximum Ratings
T
a
=
25°C
1
2
2.54
2-0.45
±0.15
0.45
±0.15
Parameter
Collector-emitter voltage (Base open)
Emitter-collector voltage (Base open)
Collector current
Collector power dissipation
Operating ambient temperature
Storage temperature
Symbol
V
CEO
V
ECO
I
C
P
C
T
opr
T
stg
Rating
20
5
20
100
−25
to
+85
−30
to
+100
Unit
V
V
mA
mW
°C
°C
(2-R0.6)
(R1.2)
1: Emitter
2: Collector
LSTLR102-002 Package
■
Electrical-Optical Characteristics
T
a
=
25°C
±
3°C
Parameter
Photocurrent
Dark current
Peak sensitivity wavelength
Half-power angle
Rise time
*2
Fall time
*2
Collector-emitter saturation voltage
*1
*1
Symbol
I
CE(L)
I
CEO
λ
p
θ
t
r
t
f
V
CE(sat)
V
CE
=
10 V
V
CE
=
10 V
Conditions
V
CE
=
10 V, L
=
500 lx
Min
1.0
Typ
4.0
0.01
800
40
4
4
Max
Unit
µA
µA
nm
°
1.00
The angle from which photocurrent
becomes 50%
V
CC
=
10 V, I
CE(L)
=
5 mA, R
L
=
100
Ω
I
CE(L)
=
1 mA, L
=
1 000 lx
10
10
0.5
µs
µs
V
0.2
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *1: Source: Tungsten (color temperature 2 856 K)
*2: Switching time measurement circuit
Sig. in
V
CC
(Input pulse)
Sig. out
R
L
(Output pulse)
t
r
t
f
90%
10%
t
r
: Rise time
t
f
:
Fall time
50
Ω
Note) The part number in the parenthesis shows conventional part number.
Publication date: November 2004
SHE00022CED
1
