1270 nm ~ 1610 nm DFB LD MODULES
2.5 Gbps CWDM MQW-DFB LD RECEPTACLE
FEATURES
²
²
²
²
²
²
18-wavelength CWDM: from 1270 nm to 1610 nm, each Step 20 nm
High reliability, long operation life
0
ºC
~+70
ºC
operation
Up to 2.5 Gbps Operation
Single frequency operation with high SMSR
Build-in InGaAs monitor
DL-5500S-CXX0
DL-5500S-CXX0 Series
********************************************************************************************************************************************************
*******************************************************************************************************************************************************
APPLICATION
OC-3, OC-12, OC-48, and Gigabit Ethernet Optical communication system
DESCRIPTION
DL-5500S-CXX0 series are MQW-DFB laser diodes that provide a durable, single frequency
oscillation with emission wavelength from 1270 nm to 1610 nm CWDM, each step 20 nm.
ELECTRICAL AND OPTICAL CHARACTERISTICS (T
C
=25
°C)
Symbol
I
th
I
OP
V
OP
P
f
Parameter
Threshold Current
Operating Current
Operating Voltage
CW
CW, I
th
+20mA
CW, I
th
+20mA
1.0
2.0
λ-3
30
Test Conditions
Min.
Typ.
10
35
1.2
-
-
λ
35
150
-
50
10
10
15
-
±1.5
Max.
20
50
1.5
-
-
λ+2
Unit
mA
mA
V
mW
nm
dB
ps
dB
μA
nA
pF
Optical Output Power
CW, I
th
+20mA
Part No: DL-552XS- CXX0
DL-553XS- CXX0
Center Wavelength
Side Mode Suppression Ratio
Rise And Fall Times
CW, I
th
+20mA
CW, I
th
+20mA
I
F
=I
th
, I
th
+20mA,20~ 80%
APC, 0~+70
ºC
CW, I
th
+20mA,V
RD
=1V
V
RD
=5V
V
RD
=5V, f=1MHz
λc
SMSR
t
r
, t
f
ΔP
f
/ P
f
Tracking Error
I
m
I
D
C
t
PD Monitor Current
PD Dark Current
PD Capacitance
Note: Central CWDM wavelength is from 1270 nm to 1610 nm, each step 20 nm.
ABSOLUTE MAXIMUM RATINGS (T
C
=25
ºC)
Symbol
P
o
V
RL
V
RD
I
FD
T
opr
T
stg
Parameter
Optical Output Power (552XS/553XS)
LD Reverse Voltage
PD Reverse Voltage
PD Forward Current
Operating Temperature
Storage Temperature
Ratings
1.5 / 3
2
10
1.0
0~+70
-40~+85
Unit
mW
V
V
mA
ºC
ºC
********************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax:886-3-5979737
e-mail: sales@optoway.com.tw
http: // www.optoway.com.tw
12/1/2003 V1.1
Optoway
MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT
DL-5500S-CXX0
********************************************************************************************************************************************************
ORDER INFORMATION
Part No.: D L
−
5 5
□
Code
2
3
Code
0
5
8
Code
Blank
S
Power
1mW
2mW
PIN Assignment
Type A
Type B
Type C
Speed
1.25 Gbps
2.5 Gbps
□
□
−
C
□
Code
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
61
□
0
−
□
□
□
Code
Blank
S
Isolator
No
Single-Stage
Wavelength
1270 nm
1290 nm
1310 nm
1330 nm
1350 nm
1370 nm
1390 nm
1410 nm
1430 nm
1450 nm
1470 nm
1490 nm
1510 nm
1530 nm
1550 nm
1570 nm
1590 nm
1610 nm
Code
F
FB
T
S
SB
Connector Type
FC/PC
FC/PC (Board Mount)
ST/PC
SC/PC
SC/PC (Board Mount)
********************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax:886-3-5979737
e-mail: sales@optoway.com.tw
http: // www.optoway.com.tw
12/1/2003 V1.1
