This document was generated on 02/28/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0462070008
Active
Mini-Fit Jr. Power Connectors
4.20mm Pitch, Mini-Fit Jr. Reflow Solder Capable, Tray Header, Dual Row, Vertical,
8 Circuits, 1.57mm PCB Thickness, with PCB Pegs, LCP Housing, with Tin (Sn) Over
Nickel (Ni) Plating, Glow Wire Capable, Tray
Documents:
3D Model
Drawing (PDF)
Product Specification PS-45750-001-001 (PDF)
Agency Certification
CSA
UL
General
Product Family
Series
Application
Comments
Product Specification PS-5556-001 (PDF)
Packaging Specification PK-46207-001-000 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
LR19980
E29179
PCB Headers
46207
Board-to-Board, Power, Wire-to-Board
Current for wire-to-wire applications = 13.0A max. per
circuit. Current for wire-to-board applications = 9.0A
max. per circuit
Collected FY08-Verified FY08
E-46207-003_B, PK-46207-001_A, PS-45499-002_B,
PS-46207-001_1, SD-46207-001_C
0462060008, 0462111001
Mini-Fit Jr. Power Connectors
Mini-Fit Jr.
800756675770
No
8
8
Black
100
No
94V-0
Yes
No
Yes
Brass
Matte Tin
Matte Tin
High Temperature Thermoplastic
2.986/g
2
Vertical
3.66mm
Yes
Yes
1.57mm
Tray
4.20mm
4.20mm
Yes
Data Load Status
Doc Info - Component
Made From
Overview
Product Name
UPC
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Glow-Wire Capable
Guide to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Search Parts in this Series
46207 Series
Mates With
45750 Terminal, 5557 Mini Fit Jr.
Receptacle
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Temperature Range NonOperating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
Yes
Fully
No
Yes
-40°C to +105°C
-40°C to +105°C
Through Hole
13.0A
600V AC (RMS)/DC
030
SMC&WAVE
003
265
PK-46207-001-000
PS-45750-001-001, PS-5556-001
SD-46207-001-000
