Features
■
High saturation current - up to 8 A
■
Inductance range: 1.5 to 820 µH
■
Heating current up to 7.2 A
■
AEC-Q200 qualified
■
RoHS compliant* and halogen free**
Applications
■
Automotive systems:
- Driver assistant
- Information
- Entertainment
- Lighting
■
DC/DC converters
■
Power supplies
SDE1006A Series - SMD Power Inductors
Electrical Specifications @ 25 °C
Bourns
Part Number
Inductance
L (µH)
Tol. (%)
Test
Freq./Voltage
SRF
(MHz)
Typ.
DCR
(Ω)
Max.
I rms
(A)
I sat
(A)
General Specifications
Operating Temperature
................................-40 °C to +125 °C
(Temperature rise included)
Storage Temperature
................................-40 °C to +125 °C
Resistance to Soldering Heat
............................. +245 °C for 10 sec.
Temperature Rise
......................40 °C typ. at rated I rms
Inductance Drop .......... 10 % typ. at I sat
Materials
Core ..............................................Ferrite
Wire ............................Enameled copper
Terminal Finish .........................Ag/Ni/Sn
Packaging .................... 800 pcs. per reel
Product Dimensions
10.00 ± 0.4
(.394 ± .016)
SDE1006A-1R5M
SDE1006A-2R2M
SDE1006A-3R3M
SDE1006A-3R9M
SDE1006A-4R7M
SDE1006A-5R6M
SDE1006A-6R8M
SDE1006A-8R2M
SDE1006A-100M
SDE1006A-120M
SDE1006A-150M
SDE1006A-180M
SDE1006A-220M
SDE1006A-270M
SDE1006A-330M
SDE1006A-390M
SDE1006A-470K
SDE1006A-560K
SDE1006A-680K
SDE1006A-820K
SDE1006A-101K
SDE1006A-121K
SDE1006A-151K
SDE1006A-181K
SDE1006A-221K
SDE1006A-271K
SDE1006A-331K
SDE1006A-391K
SDE1006A-471K
SDE1006A-561K
SDE1006A-681K
SDE1006A-821K
1.5
2.2
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 MHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
1 KHz / 1 V
69.6
57.7
48.8
40.6
37.4
35.6
32.1
27.9
25
23
19.8
19.3
16
13.3
12.1
12
11
10.2
9.4
8.8
7.3
6.6
6.6
6.1
5.3
4.3
4.3
3.3
3.3
3.3
2.8
2.2
0.018
0.021
0.024
0.027
0.036
0.04
0.044
0.048
0.06
0.07
0.08
0.09
0.1
0.11
0.12
0.14
0.17
0.19
0.22
0.25
0.35
0.4
0.47
0.63
0.73
0.97
1.15
1.3
1.48
1.9
2.25
2.55
7.2
6.0
5.4
5.2
4.7
4.5
4.2
4.1
3.8
3.6
3.4
2.8
2.6
2.3
2.2
1.9
1.8
1.7
1.6
1.5
1.3
1.2
1.1
1.0
0.85
0.75
0.7
0.65
0.6
0.55
0.5
0.45
8.0
6.6
6.0
5.7
5.2
5.0
4.6
4.3
4.0
3.8
3.6
3.0
2.8
2.5
2.4
2.1
1.95
1.8
1.7
1.6
1.4
1.3
1.2
1.1
1.0
0.85
0.75
0.7
0.65
0.6
0.55
0.5
100
2.70
REF.
(.106)
9.00 ± 0.4
(.354 ± .016)
5.40 ± 0.4
(.241 ± .016)
How to Order
Electrical Schematic
SDE1006A - 100M
Model
Value Code (see table)
Recommended Layout
9.50 ± 0.4
(.374 ± .016)
2.50
(.098)
10.00
(.394)
DIMENSIONS:
MM
(INCHES)
* RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
** Bourns follows the prevailing definition of “halogen free” in the industry. Bourns considers a product to be “halogen free” if (a) the Bromine (Br) content is 900 ppm or less;
(b) the Chlorine (Cl) content is 900 ppm or less; and (c) the total Bromine (Br) and Chlorine (Cl) content is 1500 ppm or less.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
SDE1006A Series - SMD Power Inductors
Soldering Profile
Peak Temperature 245
max.
Max. Peak Temperature -5
30 sec. max.
Max. Time Above 217 : 60~150 sec. max.
Temperature
Rising Area
+4.0 °C/Sec. Max.
Preheat
Area
150~200 °C / 60~120 Sec.
Reflow
Area
+3.0 °C/Sec. Max.
Forced
Cooling Area
-(1.0~5.0) °C/Sec. Max.
250
Peak Temperature: 245 °C
217 °C
Temperature (°C)
200
150
100
50
60~120 Sec.
60~150 Sec.
60 Sec.
Max.
0
50
100
150
200
250
Time (Seconds)
Packaging Specifications
330
(12.99)
DIA.
2.0 ± 0.5
(.079 ± .020)
30.4
(1.20)
21.0
±
0.8
(.827
±
.031)
13.0
±
0.5
(.512
±
.020)
DIA.
50.0 -0
(1.969 - .000)
THICKNESS
0.10
(.004)
MAX.
EMBOSSED
CAVITY
13.0
±
0.5
DIA.
(.512
±
.020)
EMBOSSED
CARRIER
26 +0
(1.02 +.000)
24.0
(.945)
END
12
(.472)
4
(.157)
START
100
100
100
100
100
100
NO COMPONENT
NO COMPONENT
COMPONENTS
350
(13.780)
400
(15.748)
USER DIRECTION OF FEED
QTY: 800 PCS. PER REEL
DIMENSIONS:
MM
(INCHES)
Asia-Pacific:
Tel: +886-2 2562-4117
Fax: +886-2 2562-4116
Europe:
Tel: +41-41 768 5555
Fax: +41-41 768 5510
The Americas:
Tel: +1-951 781-5500
Fax: +1-951 781-5700
www.bourns.com
REV. 09/13
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
