Type WMF Polyester Film Capacitors
Film/Foil, Axial Leads - Commercial, Industrial Applications
Type WMF axial-leaded, polyester film/foil capacitors, available in
a wide range of capacitance and voltage ratings, offer excellent
moisture resistance capability with extended foil, non-inductive
wound sections, epoxy sealed ends and a sealed outer wrapper. Like
the Type DMT, Type WMF is an ideal choice for most applications,
especially those with high peak currents.
Highlights
- Very high dV/dt
- Very high peak current
- Low inductance
Specifications
Capacitance Range
Capacitance Tolerance @ 1 kHz/25 ºC
Rated Voltage
Operating Temperature Range with Ripple
Insulation Resistance
Dissipation Factor
Dielectric Strength
Life Test
.001 to 5 µF
±10% (K) Standard Tolerance, ±5% (J)/±20% (M) (Optional)
50 to 630 Vdc
–55 ºC to 125 ºC*
*Full rated voltage at 85 ºC - derated linearly to 50% rated at 105 ºC
30,000 MΩ x µF, 100,000 MΩ Min.
.75% Max. (25 °C, 1 kHz)
250%
500 Hours at 85 °C at 125% Rated Voltage
RoHS Compliant
Construction Details
Case Material
Resin Material
Terminal Material
UL510 Polyester Tape Wrap
UL94V-0 Epoxy Fill
Tin Plated Copper - Clad Steel
Dimensions
(38.1mm)
Min.
L MAX.
(38.1mm)
Min.
MAX.
D
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830
Type WMF Polyester Film Capacitors
Film/Foil, Axial Leads
Cap.
µF
Catalog
Part Number
D
mm
25.1
25.3
5.0
5.1
5.1
5.1
5.5
5.5
5.8
6.1
6.6
6.9
7.4
7.4
7.4
7.5
8.0
L
mm
50.8
58.7
20.6
20.6
20.6
20.6
20.6
20.6
20.6
20.6
20.6
20.6
20.6
20.6
20.6
23.8
23.8
d
mm
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.6
0.6
0.6
0.6
0.6
0.6
dV/dt
V/μs
1300
1300
9000
9000
9000
9000
9000
9000
9000
9000
9000
9000
9000
9000
9000
5800
5800
Cap.
µF
Catalog
Part Number
D
mm
8.5
9.3
10.0
10.0
10.9
11.7
12.7
12.9
14.7
16.0
17.4
16.9
18.3
20.1
19.0
20.7
22.5
24.2
26.2
29.5
30.1
L
mm
23.8
23.8
25.4
25.4
25.4
25.4
25.4
34.9
34.9
34.9
34.9
41.3
41.3
41.3
50.8
50.8
50.8
50.8
50.8
50.8
65.1
d
mm
0.6
0.6
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
dV/dt
V/μs
5800
5800
5800
5800
5800
5800
5800
3700
3700
3700
3700
3700
3700
3700
1600
1600
1600
1600
1600
1600
1600
1.2500 WMF4W1P25K-F
1.5000 WMF4W1P5K-F
0.0010 WMF6D1K-F
0.0012 WMF6D12K-F
0.0015 WMF6D15K-F
0.0018 WMF6D18K-F
0.0022 WMF6D22K-F
0.0027 WMF6D27K-F
0.0033 WMF6D33K-F
0.0039 WMF6D39K-F
0.0047 WMF6D47K-F
0.0056 WMF6D56K-F
0.0068 WMF6D68K-F
0.0082 WMF6D82K-F
0.0100 WMF6S1K-F
0.0150 WMF6S15K-F
0.0180 WMF6S18K-F
0.0220 WMF6S22K-F
0.0270 WMF6S27K-F
0.0330 WMF6S33K-F
0.0390 WMF6S39K-F
0.0470 WMF6S47K-F
0.0560 WMF6S56K-F
0.0680 WMF6S68K-F
0.0820 WMF6S82K-F
0.1000 WMF6P1K-F
0.1200 WMF6P12K-F
0.1500 WMF6P15K-F
0.1800 WMF6P18K-F
0.2200 WMF6P22K-F
0.2700 WMF6P27K-F
0.3300 WMF6P33K-F
0.3900 WMF6P39K-F
0.4700 WMF6P47K-F
0.5600 WMF6P56K-F
0.6800 WMF6P68K-F
0.8200 WMF6P82K-F
1.0000 WMF6W1K-F
600/630 Vdc
