SERIES
3090R
3090
ct
du
In
DA
SH
NU
s
or
Micro i
®
Low Profile Chip Inductors
Actual Size
Physical Parameters
Inches
A
0.050 Max.
B
0.100±0.010
C
0.100±0.010
D
0.050 Min.
E
0.015 Min. (Typ.)
F
0.020 Max. (Typ.)
Millimeters
1.27 Max.
2.54±0.254
2.54±0.254
1.27 Min.
0.38 Min. (Typ.)
0.51 Max. (Typ.)
Current Rating at 90°C Ambient
35°C Rise
Operating Temperature Range
–55°C to +125°C
Maximum Power Dissipation at 90°C
0.105 W
Core Material
Powdered iron core for improved
temperature stability.
Mechanical Configuration
Units are epoxy
encapsulated. Contact area for reflow soldering are gold
plated per MIL-G-45204 Type 1 Grade A. Internal
connections are thermal compression bonded.
Termination Finish Options
Standard: Gold over Nickel.
For Tin/Lead over Nickel: Add suffix “S” to part number and
allow an additional .010 inch for maximum height. For
RoHS, order 3090R - XXXKS.
Notes 1)
Designed specifically for reflow soldering and
other high temperature processes with metalized edges to
exhibit solder fillet.
2)
Self Resonant Frequency (SRF)
values 250 MHz and above are calculated and for
reference only.
Packaging
Tape & reel (8mm): 7" reel, 2000 pieces max.;
13" reel, 8000 pieces max.
MIL-PRF-83446 (Reference)
for testing methods only.
Made in the U.S.A.
-100M
-150M
-220M
-330K
-390K
-470K
-560K
-680K
-820K
-101K
-121K
-151K
-181K
-221K
-271K
-331K
-391K
-471K
-561K
-681K
-821K
-102K
-122K
-152K
-182K
-222K
-272K
-332K
-392K
-472K
-562K
-682K
-822K
-103K
0.010
0.015
0.022
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.0
SERIES 3090 IRON CORE
± 20%
42
50.0
1000
± 20%
42
50.0
1000
± 20%
40
50.0
1000
± 10%
40
50.0
900
± 10%
40
50.0
900
± 10%
38
50.0
900
± 10%
35
50.0
800
± 10%
30
50.0
700
± 10%
25
50.0
650
± 10%
32
25.0
510
± 10%
32
25.0
410
± 10%
32
25.0
370
± 10%
32
25.0
330
± 10%
34
25.0
300
± 10%
34
25.0
250
± 10%
34
25.0
220
± 10%
34
25.0
200
± 10%
34
25.0
180
± 10%
34
25.0
160
± 10%
30
25.0
140
± 10%
28
25.0
120
± 10%
24
25.0
100
± 10%
24
7.9
95
± 10%
24
7.9
90
± 10%
24
7.9
85
± 10%
25
7.9
80
± 10%
25
7.9
70
± 10%
25
7.9
65
± 10%
25
7.9
60
± 10%
24
7.9
55
± 10%
22
7.9
53
± 10%
22
7.9
50
± 10%
22
7.9
45
± 10%
20
7.9
40
0.095
0.115
0.140
0.185
0.100
0.110
0.135
0.16
0.19
0.08
0.10
0.12
0.14
0.16
0.20
0.25
0.30
0.36
0.45
0.50
0.60
0.70
1.10
1.20
1.25
1.30
1.50
1.90
2.30
3.00
3.50
4.00
4.50
5.00
890
810
765
640
870
830
750
690
630
970
870
795
765
690
615
550
500
460
410
390
355
330
265
250
245
240
225
200
180
160
145
135
130
120
Optional Tolerances: J = 5% H = 3% G = 2% F = 1%
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com
