RH
www.vishay.com
Vishay Sfernice
Heatsink Encased Wirewound Power Resistors
FEATURES
• 5 W to 50 W at 25 °C
• NF C 83-210
• According to CECC 40 203
• High stability < 0.05 % year
• Low temperature coefficient typically ± 15 ppm/°C
• Wide range of values from 0.006
to 130 k
• Termination = Sn/Ag/Cu
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Encased in a compact and light heatsink offering complete environmental protection, great mechanical strength and easy
mounting. Non inductive versions can be supplied under the RHNI designation (please indicate required specifications and
frequency range upon ordering).
NF F 16101, 10/1988 and 16102, 04/1992: Not applicable (our parts contain less than 10 g of combustible materials).
DIMENSIONS
in millimeters
RH
A
D
F
N
M
Ø2
H
J
G
B
ØK
E
Q
ØP
L
SERIES
RH5
RH10
RH25
RH50
A
28.5 ± 1.5
35.5 ± 1.5
49 ± 1.3
70.2 ± 1.4
B±
0.2
12.5
15.9
19.8
21.4
D±
0.2
11.3
14
18.3
39.7
E±
0.5
16.3
19
28
50
F
6.8 ± 1.5
7.9 ± 1.5
11.1 ± 1.5
11 ± 1.2
G±1
8.5
11
14
14
H±
0.7
6.2
7.9
9.9
10.7
J±
0.5
16.4
20.6
27.5
29.4
ØK±
0.1
2.4
2.4
3.2
3.2
L
MAX.
8.9
11
15
15
M±
0.5
4.3
5.6
8
8
N±
0.3
1.6
2
2.4
2.4
ØP
MIN.
2.1
2.1
2.1
2.1
Q
25.3 ± 1.5
30.6 ± 1.5
44.6 ± 1.3
66.5 ± 1.4
WEIGHT
g
4
6.4
16.1
28.6
OHMIC RANGE IN RELATION TO TOLERANCE
RH5
10 %
5%
2%
1%
0.5 %
E24
E24
E48
E96
E96
0.01
to 12 k
0.01
to 12 k
0.01
to 12 k
0.1
to 12 k
0.1
to 12 k
RH10
0.006
to 20 k
0.01
to 20 k
0.01
to 20 k
0.1
to 20 k
0.1
to 20 k
RH25
0.006
to 62 k
0.01
to 62 k
0.01
to 62 k
0.05
to 62 k
0.1
to 62 k
RH50
0.006
to 130 k
0.01
to 130 k
0.01
to 130 k
0.05
to 130 k
0.1
to 130 k
Revision: 06-Jul-15
Document Number: 50013
1
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
RH
www.vishay.com
Vishay Sfernice
RH5
MIL
Limits
Vishay Sfernice
Limits
Vishay Sfernice
Limits
25 °C
70 °C
25 °C
70 °C
25 °C
70 °C
5W
4W
10 W
8W
4W
3.2 W
160 V
1000 V
Vishay Sfernice
E 96
E 96
± 0.1 %
± 0.5 %
±1%
±2%
±5%
± 10 %
0.01
0.01
12 k
1
0.1
0.1
0.01
0.01
0.008
RH10
10 W
8W
12.5 W
10 W
6W
4.8 W
250 V
1500 V
0.006
20 k
RH25
20 W
16 W
25 W
20 W
9W
7.2 W
550 V
2500 V
0.006
62 k
1
0.1
0.05
0.01
0.01
0.006
RH50
30 W
24 W
50 W
40 W
12 W
9.6 W
1285 V
2500 V
0.006
130 k
TECHNICAL SPECIFICATIONS
VISHAY SFERNICE MODEL AND STYLE
POWER RATING
Chassis Mounted Resistors
413 cm
2
for RH5 and RH10
536 cm
2
for RH25 and RH50
Unmounted Resistors
Rated Maximum Voltage (V
RMS
)
Dielectric Strength V
RMS
Minimum Ohmic Values
in Relation to Tolerance
E 96
E 48
E 24
E 12
PERFORMANCE
MIL-R-18546 D
TESTS
Operating Temperature Range
Momentary Overload
Climatic Sequence
Load Life Test at High
Temperature
Humidity (Steady State)
Resistance to Moisture
Temperature Coefficient
Load Life
at Maximum Temperature
1000 h 25 °C
200 °C
NF C 83-210
CONDITIONS
-55 °C +200 °C
5
P
r
/5 s
-55 °C +200 °C
5 cycles
2 h at +275 °C
56 days
Climatic sequences test, with load
and polarisation
5
to 10
> 10
P
n
MIL
30 % of
P
n
Vishay
Sfernice
REQUIREMENTS
-
± (0.25 % + 0.05
)
± (0.25 % + 0.05
)
± (1 % + 0.05
)
Ins. resistance
1 G
± (1 % + 0.05)
Ins. resistance
100 M
± (1 % + 0.05
)
± 50 ppm/°C
± 25 ppm/°C
± (1 % + 0.05
)
Ins. resistance
1 G
TYPICAL DRIFTS
-
± (0.1 % + 0.05
)
± (0.1 % + 0.05
)
± (0.1 % + 0.05
)
± (0.5 % + 0.05
)
± (0.5 % + 0.05
)
± 15 ppm/°C
± (0.1 % + 0.05
)
± (0.5 % + 0.05
)
MOMENTARY OVERLOAD
1. Momentary overload (> 2 s):
See example in table below. In all cases, it should be understood that:
- The 12
P
n
overload applies only to ohmic values 0.1.
- The overload voltage shall not be higher than that used for the dielectric strength test (see Standard Electrical Specifications).
2. Short time overload (< 2 s):
For times shorter than 2 s, higher overloads can be sustained in some cases. Consult Vishay Sfernice.
POWER LOADING
2.5
P
n
5
P
n
12
P
n
DURATION
10 s
5s
2s
Revision: 06-Jul-15
Document Number: 50013
2
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
RH
www.vishay.com
POWER RATING
125
Vishay Sfernice
TEMPERATURE RISE
250
RATED POWER IN %
100
HOT SPOT TEMPERATURE IN °C
200
RH
50
75
150
50
100
10
RH
25
RH
0
0
50
100
150
200
250 275 300
350
0
0
RH
10
25
50
5
20
30
40
50
60
70
AMBIENT TEMPERATURE IN °C
RATED POWER IN W
(Mounted on heatsink chassis)
MARKING
Vishay Sfernice trademark, model, style, nominal resistance
(in
),
tolerance (in %), manufacturing date.
PACKAGING
Bag of 10 units
ORDERING INFORMATION
RH
MODEL
05
STYLE
N
NON INDUCTIVE
WINDING
Optional
18R00
OHMIC VALUE
J
TOLERANCE
S03
PACKAGING
GLOBAL PART NUMBER INFORMATION
R
H
5
0
3
3
0
0
1
J
S
0
3
GLOBAL
MODEL
RH
SIZE
05
10
25
50
OPTION
N
= Non inductive winding
OHMIC VALUE
The first four digits are
significant figures and the
last digit specifies the
number of zeros to follow.
R designates decimal point.
33001
= 33 k
680R0
= 680
20301
= 20.3 k
88R88
= 88.88
...
TOLERANCE
D
= 0.5 %
F
=1%
G
=2%
J
=5%
K
= 10 %
PACKAGING
Standard Packaging:
S03 = Bag, 10 pieces
SPECIAL
As applicable
Ex
= HDX
Revision: 06-Jul-15
Document Number: 50013
3
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
