RVO
VERTICAL CHIP TYPE
ALUMINUM ELECTROLYTIC CAPACITORS FOR AUDIO
Chip Type Audio Use Capacitors
Series RVO (PURECAP)
• Audio grade surface mount product with completely new
components using synthetic mica paper for the separator.
• Both quality sense and sound field that could not be realized
by the surface mount products are reproducible.
For higher grade
RVO
(PURECAP)
RVO
Marking color : Black print (except height : 10mm)
White print on a brown sleeve (ø8x10L, ø10x10L)
Specifications
Item
Category temperature range (˚C)
Tolerance at rated capacitance (%)
Performance
−40
to
+85
±20
Less than 0.01CV or 3 whichever is larger(after 2 minutes) C: Rated capacitance(µF); V: Rated voltage(V)
Rated voltage (V)
tanδ (max.)
6.3
0.28
10
0.24
16
0.20
25
0.14
35
0.12
(20˚C,120Hz)
(20˚C)
50
0.10
(20˚C,120Hz)
Rated voltage (V)
Ζ−25˚C
/
Ζ+20˚C
Impedance ratio (max.)
Ζ−40˚C
/
Ζ+20˚C
6.3
3
8
10
3
5
16
2
4
25
2
3
35
2
3
50
2
3
(120Hz)
Test time
Leakage current
Percentage of capacitance change
Tangent of the loss angle
2000 hours
The initial specified value or less
Within
±20%
of initial value
200% or less of the initial specified value
Leakage current (µA)
Tangent of loss angle
(tanδ)
Characteristics at high
and low temperature
Endurance (85˚C)
(Applied ripple current)
Shelf life (85˚C)
Applicable standards
Test time : 1000 hours; other items are the same as those for the endurance.
Voltage application treatment
JIS C5101-1, -18 1998 (IEC 60384-1 1992, -18 1993)
Outline Drawing
0.3MAX
A±0.2
0.4±0.2
Unit: mm
Coefficient of Frequency for Rated Ripple Current
Frequency(Hz)
Rated voltage(V)
6.3 to 16
25 to 35
50
50
0.80
0.80
0.80
120
1
1
1
1k
1.15
1.25
1.35
10k . 100k
1.25
1.40
1.50
D±0.5
B±0.2
(P)
(C)
Part numbering system (example: 16V470µF)
(C)
L
W
( ): Reference size
Environmental
item
RVO
Series code
—
16
Rated voltage
symbol
V
471
M
H10
Casing
symbol
Additional
symbol
U—
Taping
symbol
Rated capacitance
Capacitance
symbol
tolerance symbol
øD
4
5
6.3
8
8
10
L
5.3±02
5.3±02
5.3±02
6.5±0.3
10±0.5
10±0.5
A
4.3
5.3
6.3
8.4
8.4
10.4
B
4.3
5.3
6.3
8.4
8.4
10.4
C
2.0
2.3
2.7
3.4
3.0
3.3
W
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.7 to 1.1
0.7 to 1.1
P
1.0
1.5
2.0
2.3
3.1
4.7
Casing symbol
D55
E55
F55
G68
G10
H10
Former item
RVO
Series code
—
16
Rated voltage
symbol
V
471
M
H10
Casing
symbol
Additional
symbol
—
Taping
symbol
Rated capacitance
Capacitance
symbol
tolerance symbol
• Soldering conditions and land size are described on page 14. The taping spesifications are described on page 15.
Standard Ratings
Rated voltage(V)
6.3
Case
ø DxL(mm)
—
—
—
—
—
—
—
—
—
4x5.3
5x5.3
5x5.3
6.3x5.3
8x6.5
8x6.5
8x10
10x10
Rated ripple current
10
mArms
—
—
—
—
—
—
—
—
—
31
44
53
90
149
160
251
423
Case
ø DxL(mm)
—
—
—
—
—
—
—
—
4x5.3
5x5.3
5x5.3
6.3x5.3
6.3x5.3
8x6.5
8x10
10x10
—
Rated ripple current
16
mArms
—
—
—
—
—
—
—
—
23
40
49
68
99
149
226
366
—
Case
ø DxL(mm)
—
—
—
—
—
—
—
4x5.3
4x5.3
5x5.3
6.3x5.3
6.3x5.3
8x6.5
8x10
8x10
10x10
—
Rated ripple current
25
mArms
—
—
—
—
—
—
—
18
26
44
63
76
124
200
245
366
—
Case
ø DxL(mm)
—
—
—
—
—
—
—
4x5.3
5x5.3
6.3x5.3
6.3x5.3
8x6.5
8x6.5
8x10
10x10
—
—
Rated ripple current
35
mArms
—
—
—
—
—
—
—
19
32
55
67
124
137
235
366
—
—
Case
ø DxL(mm)
—
—
—
—
—
—
4x5.3
4x5.3
5x5.3
6.3x5.3
8x6.5
8x6.5
8x10
10x10
—
—
—
Rated ripple current
50
mArms
—
—
—
—
—
—
17
20
34
59
124
124
200
366
—
—
—
Case
ø DxL(mm)
4x5.3
4x5.3
4x5.3
4x5.3
4x5.3
4x5.3
4x5.3
5x5.3
6.3x5.3
8x6.5
8x6.5
8x10
10x10
—
—
—
—
Rated ripple current
Rated
capacitance(µF)
Item
0.1
0.22
0.33
0.47
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
mArms
3
5
6
7
10
15
19
26
44
124
124
200
366
—
—
—
—
(Note) Rated ripple current : 85˚C, 120Hz.
