Technical specification :
Rated voltage:
IEC 61076-2-104
Current rating:
IEC 61076-2-104
60 V
3 A at 40°
C
n
10,1
21
Insulation resistance:
IEC 60512
Pollution degree:
IEC 60664-1
Degree of protection:
IEC 60529
>=100 M
3/2
IP 67, in mated
condition
-30°C ... +80°
C
>=100
A
22
1,5
Width across
flats 9
n
8
Temperature range:
IEC 60664-1
Mating cycles:
IEC 60512-9a
Materials:
Contact:
Contact plating:
Contact carrier:
Sealing:
Coupling nut:
L
D
CuZn
Nickel, gold plated
TPU GF, UL 94
FPM
GD-Zn, nickel plated
TPU, UL 94, grey
A
4
3
1
Moulding body:
Installation specification:
Recommended
torque:
Conec
installation tool:
0,4 Nm
Torque wrench:
36-000200
Insert across flats 9:
36-000210
Contact assignment:
1
3
4
brown
blue
black
Part no:
42-10016
42-10017
42-10018
42-10019
Description:
SAL - 8 - RKW3 - 2 / A1
SAL - 8 - RKW3 - 3 / A1
SAL - 8 - RKW3 - 5 / A1
SAL - 8 - RKW3 - 10 / A1
SAL - 8 - RKW3 - ... / A1
Length L: Cable:
2m
3m
5m
10m
x
PVC,
grey, 3x0,25mm²
Cable: 781-A12300
D see data sheet cable
DO NOT ALTER CAD DRAWING BY HAND
42-xxxxx
dim. in mm
date
name
Directive 2002/95/EC RoHS compliant
Index: a 16.03.11 VF Ä3945
Coupling nut modified, spanner flats added,
data sheet modified
L <= 4m: L + 40mm
L > 4m: L + 1%
0
0,0
0,00
± 0,50mm
± 0,25mm
± 0,10mm
drawn
02.10.07
appd.
title:
Female connector M8x1 angled
dwg no:
R
tolerance of cable:
Franz
Mankopf
02.10.07
general tolerance:
42K1A005
part no:
THIS DRAWING MAY NOT BE COPIED OR REPRODUCED IN ANY WAY, AND
MAY NOT BE PASSED ON TO A THIRD PARTY WITHOUT WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
see table
