Toroidal Inductors
Medium Current
CTP4409
CTP4409 is a medium current inductor with the following data and features:
•
Core type:
1.06” o.d., Iron Powder,
perm 75.
•
Power rating:
2.16 watts for temp.
rise 50˚C.
•
Typical applications:
Input and output filters
in Switch Mode Power
Supplies.
Four mounting styles are offered:
1
Flying leads (1.00”), for vertical
or horizontal mounting.
2
4-pin header, for vertical mounting.
3
Threaded center hole, flying leads
(2.00”).
4
2-pin header, for vertical mounting.
MECHANICAL
Style 1
1.25
0.65
Style 2
1.30
0.60
Style 3
1.25
0.72
Thread
#10-32
0.90
1.30
Style 4
1.25
1.30
0.80
1.00
0.80
2.00
0.50
0.50
0.75
ELECTRICAL SPECIFICATION
Ordering Information:
Substitute the style number for the asterisk (*). Example: CTP4409, Style 1, 56uH.
Part No.
Ind.
CTP4409 - (uH)
DCR
Ohms
Rated
Current
Amp. RMS
I (amp.)
@ Lsat.
10%
I (amp.)
@ Lsat.
25%
I (amp.)
@ Lsat.
50%
Part No.
Ind.
CTP4409 - (uH)
DCR
Ohms
Rated
Current
Amp. RMS
Order: CTP4409 - 116
I (amp.)
@ Lsat.
25%
I (amp.)
@ Lsat.
50%
I (amp.)
@ Lsat.
10%
* 01
* 02
* 03
* 04
* 05
* 06
* 07
* 08
* 09
* 10
* 11
* 12
* 13
* 14
* 15
* 16
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
0.004
0.004
0.004
0.005
0.005
0.006
0.006
0.007
0.008
0.008
0.009
0.010
0.011
0.012
0.013
0.015
24.2
23.3
22.3
21.3
20.4
19.5
18.6
17.8
16.8
16.1
15.3
14.6
13.9
13.3
12.7
12.2
11.1
10.2
9.3
8.5
7.7
7.0
6.4
5.8
5.2
4.8
4.3
3.9
3.5
3.2
2.9
2.7
22.2
20.4
18.6
17.0
15.5
14.1
12.8
11.6
10.4
9.5
8.6
7.8
7.0
6.5
5.9
5.4
44.4
40.9
37.2
34.1
30.9
28.2
25.5
23.3
20.8
19.0
17.2
15.5
14.0
12.9
11.8
10.8
* 17
* 18
* 19
* 20
* 21
* 22
* 23
* 24
* 25
* 26
* 27
* 28
68
82
100
120
150
180
220
270
330
390
470
560
0.016
0.022
0.024
0.034
0.047
0.065
0.072
0.102
0.141
0.193
0.268
0.292
11.6
9.9
9.4
8.0
6.7
5.7
5.5
4.6
3.9
3.3
2.8
2.7
2.4
2.2
2.0
1.8
1.6
1.5
1.4
1.2
1.1
1.0
0.9
0.9
4.9
4.5
4.0
3.7
3.3
3.0
2.7
2.5
2.2
2.0
1.9
1.7
9.8
8.9
8.1
7.4
6.6
6.0
5.4
4.9
4.4
4.1
3.7
3.4
