HIGH VOLTAGE POWER SYSTEMS
BT-GP SERIES
General Purpose High Voltage Bench-top Power System
PRELIMINARY DATASHEET
The compact, high-voltage BT-GP Series of general purpose
bench-top high voltage power systems offers adjustable
output voltage, digital voltage reading, highly stable output,
and low ripple. BT-GP Series units are available in AC Input
or DC input, positive or negative polarity, and with the option
of one or two output connectors.
Applications for BT-GP Series high-voltage power systems
include electrostatic, air purification, ATE, test equipment,
process fluid cleaning, hi pot testing, and laboratory
research.
•
•
•
•
•
Available from 0 to 1kV through 0 to 30kV
Up to 30W of output power
3.5 digit red LED output voltage display
Bench-top configuration
Single positive or negative output
17
•
Ruggedized aluminum enclosure
•
Enters constant current mode when fault occurs
•
Highly portable with built in carrying handle (AC model)
•
Protection against overload, short circuit, arc, and reverse
polarity
PARAMETER
INPUT
Voltage Range
CONDITIONS
AC INPUT
Full Power
Nominal Input
Nominal Input, Max Eout
Iout Entire Output Voltage Range
Nominal Input
Nominal Input, Max Eout
Iout Entire Output Voltage Range
Full Load, Max Eout
Max-Min Input, Max Eout, Full Load
MODELS
DC INPUT
22-26 VDC
90-260 VAC
UNITS
-
0 to 6,000
5
0 to 30,000
1.0
VDC
Watts
7.5
0 to 20,000
0 to 30
1.5
<0.3
<0.3%
<0.01%
<0.1%
mA
VDC
Watts
mA
%V p-p
VDC
VDC
VDC
-
OUTPUT
Voltage Range
Power
Current
Voltage Range
Power
Current
Ripple
Line Regulation
Load Regulation
Stability
HV ON/OFF Controls
0 to 1,000
30
0 to 10,000
3.0
AC INPUT
0 to 2,000
0 to 30
15
0 to 20,000
0 to 30
1.5
<0.01
N/A
<0.5%
<0.05%
1.0
3.0
7.5
5
0 to 30,000
30
0 to 10,000
0 to 4,000
0 to 6,000
0 to 1,000
DC INPUT
0 to 2,000
0 to 30
15
0 to 4,000
No Load to Full Load, Max Eout
30 Min. warmup, per 8 hr/ per day
PROGRAMMING & CONTROLS
ENVIRONMENTAL
Coefficient
Storage Temperature
Operating Temperature
Humidity
Over the Specified Temperature
Non-Operating, Case Temp.
Full Load, Max Eout, Case Temp.
All Conditions, Standard Package
ALL TYPES
Front panel switch
AC INPUT
100
-20 to +60
0 to +40
0 to 90% non-condensing
DC INPUT
200
PPM/°C
°C
°C
-
Specifications subject to change without notice.
Making High Voltage Easier!
®
ULTRAVOLT
®
Higher Service, Higher Performance, Higher Reliability
©2011, UltraVolt Inc. All rights reserved.
HIGH VOLTAGE POWER SYSTEMS
BT-GP SERIES
High Voltage Biasing Supply
AC INPUT MODEL
18
General Purpose High Voltage Bench-top Power System
CONSTRUCTION
Folded aluminum enclosure with blue paint finish
SIZE
Dimensions:
AC Input: 12.01 L x 7.99 W x 4.33 H in (305.0 L x 203.0 W x 110.0 H mm)
DC Input: 11.81 L x 6.30 W x 3.94 H in (300.0 L x 160.0 W x 100.0 H mm)
Weight:
AC Input: 6.17lbs (2.8kg)
DC Input: 7.94lbs (3.6kg)
NOTES
For the outline drawing on the DC Input model, or for additional outputs or
power levels, please contact the factory.
ORDERING INFORMATION
Model
Input
Series name
90-264VAC input
24VDC input
0 to 1kVDC output
0 to 2kVDC output
0 to 4kVDC output
0 to 6kVDC output
0 to 10kVDC output
0 to 20kVDC output
0 to 30kVDC output
Positive Output
Negative Output
Watts Output
Mounting bars (AC model)
Mounting bars (DC model)
Remote HV ON/OFF (DC model)
BT-GP
-AC
-24
-1
-2
-4
-6
-10
-20
-30
P
N
30
-MB
Example:
BT-GP-24-10P30-MB
Model
Input
Voltage
Option
Power
Polarity
Voltage
Polarity
Power
Option
(Standard)
-REM
*The BT-GP Series is not available in all territories. Please contact the
factory for details concerning sales in your area.
Rev. B 4/13
Making High Voltage Easier!
®
ULTRAVOLT
®
1800 Ocean Avenue, Ronkonkoma, NY 11779
Phone: 1-631-471-4444 Fax: 1-631-471-4696 www.ultravolt.com
