Ordering number : ENN7671
2SK3738
N-Channel Junction Silicon FET
2SK3738
Impedance Converter Applications
Application
•
•
Package Dimensions
unit : mm
2124
[2SK3738]
0.75
0.6
0.4 0.8 0.4
1.6
Impedance conversion.
Infrared sensor.
Features
•
•
•
Small IGSS.
Small Ciss.
Ultrasmall package permitting applied sets to be
small and slim.
0.3
3
0~0.1
1
2
0.5 0.5
1.6
0.2
0.1
0.1max
1 : Source
2 : Drain
3 : Gate
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Drain-to-Source Voltage
Gate-to-Drain Voltage
Gate Current
Drain Current
Allowable Power Dissipation
Junction Temperature
Storage Temperature
Symbol
VDSS
VGDS
IG
ID
PD
Tj
Tstg
Conditions
SANYO : SMCP
Ratings
40
--40
10
1
100
150
--55 to +150
Unit
V
V
mA
mA
mW
°C
°C
Electrical Characteristics
at Ta=25°C
Parameter
Gate-to-Drain Breakdown Voltage
Gate-to-Source Leakage Current
Cutoff Voltage
Zero-Gate Voltage Drain Current
Forward Transfer Admittance
Input Capacitance
Reverse Transfer Capacitance
Symbol
V(BR)GDS
IGSS
VGS(off)
IDSS
yfs
Ciss
Crss
Conditions
IG=-
-10µA, VDS=0
VGS=--20V, VDS=0
VDS=10V, ID=1µA
VDS=10V, VGS=0
VDS=10V, VGS=0, f=1kHz
VDS=10V, VGS=0, f=1MHz
VDS=10V, VGS=0, f=1MHz
Ratings
min
--40
--500
--1.5
50
0.06
0.13
1.7
0.7
--2.3
130
typ
max
Unit
V
pA
V
µA
mS
pF
pF
Marking : KB
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
42004GB TS IM TA-100829 No.7671-1/3
2SK3738
140
ID -- VDS
140
ID -- VDS
120
120
Drain Current, ID --
µA
100
V GS=0
--0.2V
Drain Current, ID --
µA
100
VGS=0
--0.2V
80
80
60
--0.4V
60
--0.4V
40
--0.6V
--0.8V
--1.0V
--1.2V
--1.4V
0
1
2
3
4
5
ITR00837
80
70
60
--0.6V
40
20
0
20
0
0
4
8
--0.8V
--1.0V
--1.2V
12
--1.4V
16
20
ITR00838
160
140
Drain-to-Source Voltage, VDS -- V
Drain-to-Source Voltage, VDS -- V
ID -- VGS
ID -- VGS
VDS=10V
IDSS=100µA
VDS=10V
IDSS=50µA
Drain Current, ID --
µA
--2
5
50
40
100
80
25
°
C
Ta
=
20
10
0
--1.2
--1.0
--0.8
--0.6
--0.4
--0.2
0
Ta
=
30
75
°
C
0
ITR00840
2
IT06669
5
7
IT06671
75
25
°
C
°
C
60
40
20
0
--2.4
--2.0
--1.6
--1.2
--0.8
--0.4
Gate-to-Source Voltage, VGS -- V
3
ITR00839
3
Gate-to-Source Voltage, VGS -- V
VGS(off) -- IDSS
Forward Transfer Admittance,
y
fs -- mS
y
fs -- IDSS
VDS=10V
ID=1
µ
A
Cutoff Voltage, VGS(off) -- V
VDS=10V
VGS=0
f=1kHz
2
2
--1.0
0.1
7
7
5
3
5
7
100
2
3
IT06668
5
3
5
7
100
Drain Current, IDSS --
µA
120
PD -- Ta
Drain Current, IDSS --
µA
10
7
Ciss -- VDS
Allowable Power Dissipation, PD -- mW
VGS=0
f=1MHz
Input Capacitance, Ciss -- pF
100
5
80
3
2
60
40
1.0
7
5
3
1.0
20
0
0
20
40
60
80
100
120
140
160
2
3
5
7
Ambient Temperature, Ta --
°C
10
2
3
IT06670
Drain-to-Source Voltage, VDS -- V
No.7671-2/3
Drain Current, ID --
µA
120
--2
5
°
C
°
C
2SK3738
5
Crss -- VDS
VGS=0
f=1MHz
Reverse Transfer Capacitance, Crss -- pF
3
2
1.0
7
5
3
2
0.1
1.0
2
3
5
7
10
2
3
5
7
Drain-to-Source Voltage, VDS -- V
IT06672
