364-10-111-00-580000: DescriptionBoard Connector, 11 Contact(s), 1 Row(s), Male, Straight, Solder Terminal, ROHS COMPLIANT; CategoryThe connector The connector; File Size677KB，1 Pages; ManufacturerMill-Max; Websitehttps://www.mill-max.com; Environmental Compliance

Download Datasheet Parametric Compare View All

364-10-111-00-580000 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	364-10-111-00-580000	-	-	View	Buy Now

364-10-111-00-580000 Overview

Board Connector, 11 Contact(s), 1 Row(s), Male, Straight, Solder Terminal, ROHS COMPLIANT

364-10-111-00-580000 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compli
Other features	LOW PROFILE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (10) OVER NICKEL (150)
Contact completed and terminated	GOLD (10) OVER NICKEL (150)
Contact point gender	MALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	364
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	11
Base Number Matches	1

Preview

Download Datasheet

View All

INTERCONNECTS

SERIES 335, 364, 435, 464 • 2,54 GRID (0,46 DIA. PINS),

LOW PROFILE • SINGLE AND DOUBLE ROW STRIPS

•

Series 335 and 435 single and double row PCB

2,54

Number of Pins

X 2,54

interconnects offer a 1,78 profile, the lowest

available

0,46 DIA.

3,18

1,78

•

Series 364 and 464 single and double row PCB

1,27

interconnects offer 2,16 profile above board

0,46 DIA.

2,64

•

Series 335 and 435 use MM #3516 pins. See

page 212 for details

2,54

•

Series 364 and 464 use MM #6458 pins. See

page 213 for details

FIG. 1

5,08

2,54

Number of Pins

X 2,54 / 2

•

Insulators are high temperature thermoplastic,

suitable for all soldering operations

ORDERING INFORMATION

Series 335...160

1,27

3,18

1,78

2,64

Single Row 1,78 Profile Pin Header

335-XX-1_ _-00-160000

FIG. 1

Series 435...160

Specify number of pins

0,46 DIA.

2,54

01-32

FIG. 2

2,54

Double Row 1,78 Profile Pin Header

435-XX-2_ _-00-160000

FIG. 2

Series 364...580

1,27

Number of Pins

X 2,54

Specify number of pins

04-72

0,46 DIA.

3,18

2,16

Single Row 2,16 Profile Pin Header

364-10-1_ _-00-580000

FIG. 3

Series 464...580

0,46 DIA.

3,05

Specify number of pins

2,54

01-32

Double Row 2,16 Profile Pin Header

464-10-2_ _-00-580000

FIG. 3

5,08

FIG. 4

Specify number of pins

04-72

PAGE 78 | INTERCONNECTS

2,54

Number of Pins

X 2,54 / 2

3,18

2,16

3,05

1,27

2011/65/EU

2,54

RoHS - 2

XX=Plating Code

See Below

10

0,25μm Au

For

Electrical, Mechanical

& Enviromental Data,

See page 264

0,46 DIA.

FIG. 4

SPECIFY PLATING CODE XX=

Pin Plating

90

5,08μm Sn/Pb

40

5,08μm Sn
