SECTION
Y-Y
SCALE
20:1
ROTATED 180°
E
⌀
1.36
SECTION
Z-Z
SCALE
20:1
ROTATED 180°
E
D
D
C
B
EC NO:
DRWN:
CHK'D:
APPR:
A
NOTES:
1. MATERIAL: COPPER ALLOY
2. FINISH:
2.5µm MIN OVERALL ELECTROPLATE MATTE TIN OVER
1.25µm MIN OVERALL ELECTROPLATED MATTE NICKEL
3. PRODUCT SPECIFICATION: 2042200000-PS
4. APPLICATION SPECIFICATION: 2042200000-AS
5. PACKAGING SPECIFICATION: 2043010000-PK
6. THIS CRIMP TERMINAL TO BE USED WITH ASSEMBLY SERIES 204220.
7. THIS CRIMP TERMINAL MATES WITH RECEPTACLE CRIMP TERMINAL SERIES 2042261.
8. THIS PART CONFORMS TO CLASS 'B' REQUIREMENTS OF COSMETIC SPECIFICATION PS-45499-002.
9. WIRE SPECIFICATIONS:
AWG: 22 and 24 awg
INSULATION OD RANGE: 0.95mm - 1.4mm
10. CRIMP TOOLING:
APPLICATOR PART NUMBER: 638083700
HAND TOOL PART NUMBER: 2002180400
RELEASE STATUS
19
C
2018/03/02
2018/03/02
2018/03/02
QUALITY THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
GENERAL
SYMBOLS
TOLERANCES
mm
15:1
=
0
(UNLESS SPECIFIED)
DRWN BY
DATE
=
=
=
=
=
=
0
0
173053
TGREGORI
RHODGE
RHODGE
B
ANGULAR TOL ±
°
4 PLACES
3 PLACES
2 PLACES
1 PLACE
0 PLACES
±
±
±
TGREGORI
CHK'D BY
DATE
2018/01/03
RECEPTACLE CRIMP TERMINAL
SQUBA 1.8
0
0
0
0
0
APPR BY
DATE
±
±
0.2
PRODUCT CUSTOMER DRAWING
2018/01/26
SERIES
MATERIAL NUMBER
CUSTOMER
RHODGE
DRAWING SIZE
THIRD ANGLE PROJECTION
P1
FORMAT: master-tb-prod-D
REVISION: G
DATE: 2017/02/06
RELEASE DATE
18
2018/03/02
17
19:01:24
C
=
A2
REV
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
204301
DOCUMENT NUMBER
2043010001
DOC TYPE
DOC PART
SHEET NUMBER
A
D
5
4
2043010000-SD
3
PSD
2
000
1 OF 1
