PI3HDMI412-AZHE: Description4-Differential Channel, 2:1 Mux/DeMux, DVI/HDMI Compliant Signal Switch based on TMDS Signaling Standard; Categorylogic logic; File Size359KB，11 Pages; ManufacturerPericom Semiconductor Corporation (Diodes Incorporated); Websitehttps://www.diodes.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

PI3HDMI412-AZHE Overview

4-Differential Channel, 2:1 Mux/DeMux, DVI/HDMI Compliant Signal Switch based on TMDS Signaling Standard

PI3HDMI412-AZHE Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Pericom Semiconductor Corporation (Diodes Incorporated)
Parts packaging code	QFN
package instruction	HVQCCN,
Contacts	42
Reach Compliance Code	compliant
ECCN code	EAR99
series	3HDMI
JESD-30 code	R-XQCC-N42
JESD-609 code	e3
length	9 mm
Logic integrated circuit type	MULTIPLEXER AND DEMUX/DECODER
Humidity sensitivity level	1
Number of functions	1
Number of entries	2
Output times	1
Number of terminals	42
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output characteristics	3-STATE
Output polarity	TRUE
Package body material	UNSPECIFIED
encapsulated code	HVQCCN
Package shape	RECTANGULAR
Package form	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	0.84 mm
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	40
width	3.5 mm
Base Number Matches	1

Preview

Download Datasheet

View All

COMPANY CONFIDENTIAL

PI3HDMI412-A

4-Differential Channel, 2:1 Mux/DeMux, DVI/HDMI Compliant

Signal Switch based on TMDS Signaling Standard

Features

•

4-Differential Channel 2:1 Mux/DeMux

TMDS Signaling

Data Rate: 1.65Gbps

Crosstalk: -25dB@825MHz

Switching speed: 4ns

Isolation: -30dB@825MHz

ESD: Data bits @ 8kV HBM, select bit @ 2 kV HBM

Near-Zero Prop Delay: 250ps max.

Low bit-to-bit skew

Hot insertion capable

Enable/Disable Time: 9ns

Bidirectional

Packaging (Pb-free & Green):

- 42-pin TQFN (ZH)

- 48-pin BQSOP (B)

Description

Pericom Semiconductor’s PI3HDMI series of switch circuits are

targeted for high-resolution video networks that are based on DVI/

HDMI standards, and TMDS signal processing. The PI3HDMI412-A

is a 8- to 4-Channel Mux/DeMux Switch. The device multiplexes

differential signals to one of two corresponding outputs. The switch

is bidirectional and offers little or no attenuation of the high-speed

signals at the outputs. It is designed for low bit-to-bit skew and

high channel-to-channel noise isolation.

The maximum DVI/HDMI data rate of 1.65Gbps provides the

resolution required by the next generation HDTV and PC graphics.

Three differential channels are used for data (video signals for DVI

or audio/video signals for HDMI), and one differential channel is

used for Clock for decoding the TMDS signals at the outputs.

Because of its passive bidirectional feature, this switch can be

used either at the video drivers side or at the receiver side. For PC

graphics applications, the device sits at the drivers side to switch

between multiple display units such as PC LCD monitor, projector,

TV, etc. For consumer video applications, the device sits at the

receiver end to switch between the source components such as

DVD, D-VHS, STB, etc.

Block Diagram

½½

½½½

Pin Descriptions (Top View)

½½

½½½

½½

½½½

½½

½½½

½½

½½½

½½

½½½

½½

½½ ½½ ½½ ½½

½½½

½½

½½½

½½

½½½

C1+

C1-

SEL

C2+

C2-

C3+

C3-

C0+

C0-

½½ ½½ ½½ ½½

½½

½½½

½½

½½½

C0+

C0-

C1+

C1-

C0+

C0-

C1+

C1-

C2+

C2-

C3+

C3-

C2+

C2-

C3+

C3-

42-pin TQFN

48-pin BQSOP

PS8814

02/08/06
