KITXMC14BOOT001TOBO1 datasheet, PDF

Datasheet> All Categories > Development board/suite/development tools> KITXMC14BOOT001TOBO1

KITXMC14BOOT001TOBO1: DescriptionDevelopment Boards & Kits - ARM; CategoryDevelopment board/suite/development tools; File Size2MB，19 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/; Environmental Compliance

Download Datasheet Parametric View All

KITXMC14BOOT001TOBO1 Overview

Development Boards & Kits - ARM

KITXMC14BOOT001TOBO1 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Infineon
Product Category	Development Boards & Kits - ARM
RoHS	Details
Product	Demonstration Kits
Core	ARM Cortex M0
Tool Is For Evaluation Of	XMC1400
Description/Function	XMC1400 boot kit
Interface Type	UART, USB
Data Bus Width	32 bit
Operating Supply Voltage	3.3 V, 5 V

Preview

Download Datasheet

View All

UG_201512_PL30_005

XMC1400 Boot Kit

For XMC1000 Family

About this document

Scope and purpose

This document provides the schematic and hardware description of XMC1400 Boot Kit, so that user is able to

make use of this board for their application code development on XMC1404-Q064X0200 device.

Intended audience

For people who are interested to explore the functionality of XMC1404 device.
