B84110-A-A40 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> B84110-A-A40

B84110-A-A40: Description250 V, 50/60 HZ, SINGLE PHASE EMI FILTER; CategoryAnalog mixed-signal IC filter; File Size88KB，5 Pages; ManufacturerEPCOS (TDK); Environmental Compliance; Related ProductsFound19parts with similar functions to B84110-A-A40

Download Datasheet Parametric Compare View All

B84110-A-A40 Overview

250 V, 50/60 HZ, SINGLE PHASE EMI FILTER

B84110-A-A40 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	EPCOS (TDK)
Reach Compliance Code	compli
Other features	INDUCTANCE 2.7 MILLI HENRY
Certification	UL; CSA; ENEC-10
filter type	SINGLE PHASE EMI FILTER
high	23 mm
high potential	2700 V
JESD-609 code	e3
Maximum leakage current	0.5 mA
length	56 mm
Manufacturer's serial number	B84110A
Installation type	THROUGH HOLE MOUNT
working frequency	50/60Hz Hz
physical size	L56.0XB30.0XH23.0 (mm)/L2.205XB1.181XH0.906 (inch)
Rated current	4 A
Rated voltage	250 V
Terminal surface	Tin (Sn)
width	30 mm

Preview

Download Datasheet

View All

2-Line Filters

for General-Purpose Applications

Power line filters for single-phase systems

Rated voltage 250 V~, 50/60 Hz

Rated current 0,5 A to 6 A

Construction

Two-line filter

Plastic case

B84110-A

Features

High insertion loss

For PCB mounting

Cost-effective solution

Applications

Medium-performance switch-mode power supplies

Data systems, gambling machines, small-size equipment

Terminals

Pins fitting standard PCB grid

Marking

Marking on component:

Manufacturer’s logo, ordering code,

rated voltage, rated current,

date code

Minimum marking on packaging:

Manufacturer’s logo, ordering code

Circuit diagram

LINE

LOAD

L’

N’

SSB0187-W

200

03/01

Herausgegeben von EPCOS AG

Marketing Kommunikation, Postfach 80 17 09, 81617 München, DEUTSCHLAND



Verwertung dieser Broschüre und ihres Inhalts ohne ausdrückliche Genehmigung der EPCOS AG

nicht gestattet.

Mit den Angaben in dieser Broschüre werden die Bauelemente spezifiziert, keine Eigenschaften

zugesichert. Bestellungen unterliegen den vom ZVEI empfohlenen Allgemeinen Lieferbedingungen

für Erzeugnisse und Leistungen der Elektroindustrie, soweit nichts anderes vereinbart wird.

Diese Broschüre ersetzt die vorige Ausgabe.

Fragen über Technik, Preise und Liefermöglichkeiten richten Sie bitte an den Ihnen nächstgele-

genen Vertrieb der EPCOS AG oder an unsere Vertriebsgesellschaften im Ausland.

Bauelemente können aufgrund technischer Erfordernisse Gefahrstoffe enthalten. Auskünfte

darüber bitten wir unter Angabe des betreffenden Typs ebenfalls über die zuständige Vertriebsge-

sellschaft einzuholen.

Published by EPCOS AG

Marketing Communications, P.O. Box 80 17 09, 81617 Munich, GERMANY



chure and the information contained therein without EPCOS’ prior express consent is prohibited.

The information contained in this brochure describes the type of component and shall not be con-

sidered as guaranteed characteristics. Purchase orders are subject to the General Conditions for

the Supply of Products and Services of the Electrical and Electronics Industry recommended by the

ZVEI (German Electrical and Electronic Manufacturers’ Association), unless otherwise agreed.

This brochure replaces the previous edition.

For questions on technology, prices and delivery please contact the Sales Offices of EPCOS AG or

the international Representatives.

Due to technical requirements components may contain dangerous substances. For information on

the type in question please also contact one of our Sales Offices.
