SMT POWER INDUCTORS
Wirewound - PD0120NL Series
Height:
8.2mm Max
Footprint:
16.2mm x 16.0mm Max
Current Rating:
up to 15.4A
Inductance Range:
1.2µH to 55.4µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +125°C
7
Part Number
5. 7
Inductance
@ Irated
(µH ±10%)
1.2
1.8
2.5
4.5
5.6
7.1
12.0
18.3
22.6
39.9
55.4
Irated
1
(A
DC
)
15.4
14.2
11.4
11.2
10.4
8.6
7.6
6.4
5.3
4
3.4
DCR
(mΩ)
TYP
1.5
2.5
4.0
6.3
8.0
9.5
15.0
21.5
30.5
51.5
75.5
MAX
2.0
3.0
4.2
6.8
8.5
10.0
16.0
25.5
35.5
58.5
82.5
Inductance
@ 0 A
DC
(µH ±10%)
1.2
1.8
2.6
4.6
5.7
7.2
12.2
18.7
23.1
40.7
56.5
Saturation Current
2
(A)
25°C
100°C
29
24.3
20.6
15
13.6
12.6
9
7.6
6.8
5
4.3
24.6
19
17.6
13
11.6
10.6
8
6.6
6
4.6
3.8
Heating
Current
3
(A)
15.4
14.2
11.4
11.2
10.4
8.6
7.6
6.4
5.3
4
3.4
Core Loss
Factor
4
Kc
5556
4444
3704
2778
2469
2222
1709
1389
1235
926
794
PD0120.102NL
PD0120.152NL
PD0120.222NL
PD0120.332NL
PD0120.532NL
PD0120.702NL
PD0120.113NL
PD0120.183NL
PD0120.223NL
PD0120.373NL
PD0120.503NL
NOTE:
To order RoHS compliant part, add the suffix “NL” to the part number (i.e. PD0120.102 becomes PD0120.102
NL).
Mechanical
.323 MAX
8,20
.638 MAX
16,20
.004/0,10
Schematic
1
.453
11,50
.059
1,50
4
.628 MAX
15,95
3
PD0120.XXX
Date Code
Country of
Origin
1
.630
16,00
2
.236
6,00
2
Not actual number of turns;
for reference only
SUGGESTED PAD LAYOUT
Weight
. . . . . . . . . . .4.25 grams
Tape & Reel
. . . . . . . . .250/reel
.650
16,50
.720 1.260
± .012
18,30 32,00
± 0,30
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
TAPE & REEL LAYOUT
.335
8,50
.638
16,20
.945
24,00
USER DIRECTION OF FEED
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
69
SPM2007 (11/07)
SMT POWER INDUCTORS
Wirewound - PD0120NL Series
Notes from Tables
1. The rated current as listed is either the saturation current or the
heating current depending on which value is lower.
2. The saturation current is the current which causes the
inductance to drop by 10% at the stated ambient temperatures
(-40°C, 25°C and 125°C). This current is determined by placing
the component in the specified ambient environment and apply-
ing a short duration pulse current (to eliminate self-heating
effects) to the component.
3. The heating current is the DC current which causes the
temperature of the part to increase by approximately 45°C. This
current is determined by mounting the component on a PCB
with .25" wide, 3 oz. equivalent copper traces, and applying the
current to the device for 30 minutes with no forced air cooling.
4. In high volt*time applications, additional heating in the
component can occur due to losses in the inductor which may
neccessitate derating the current in order to limit the
temperature rise of the component. In order to determine
the approximate total losses (or temperature rise) for a given
application both copper losses and core losses should be taken
into account.
5. Optional Tape & Reel packaging can be ordered by adding a
"T" suffix to the part number (i.e. PD0120.102 becomes
PD0120.102T). Pulse complies to industry standard tape and
reel specification EIA481.
Estimated Temperature Rise:
Trise
= Coreloss (mW) + DCRloss (mW)
.833
(°C)
7.05
Coreloss
= 1.86E-12 *
(
Freq (kHz)
)
1.63
* (K
c
* Vµsec)
2.17
(mW)
DCRloss
= I
rms2
* DCR(m
Ω
) (mW)
I
DC2
+ dI
2
½
(A
rms
)
12
Freq (kHz)
= switching frequency (kHz)
Vµsec
= L (µH) * dI or V * D * 1000/Freq (kHz)
dI
= pk – pk ripple current across the component (A)
V
= Voltage across the component (V)
D
= Duty cycle
I
rms
=
6. The "NL" suffix indicates an RoHS-compliant part number. Non-
NL suffixed parts are not necessarily RoHS compliant, but are
electrically and mechanically equivalent to NL versions. If a part
number does not have the "NL" suffix, but an RoHS compliant
version is required, please contact Pulse for availability.
7. The temperature of the component (ambient plus temperature
rise) must be within the stated operating temperature range.
Inductance vs Current Characteristics
60.0
Open-Circuit Inductance , OCL (µH)
PD0120.503
50.0
PD0120.373
PD0120.223
40.0
PD0120.183
PD0120.113
30.0
PD0120.702
PD0120.532
20.0
PD120.332
PD0120.222
PD0120.152
10.00
PD0120.102
0.0
0
5
10
15
20
25
30
35
40
Normalized I
DC
(Amps)
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
70
SPM2007 (11/07)
