86285-002 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 86285-002

86285-002: DescriptionModular Connectors / Ethernet Connectors 86285-002-LP 6POS PCB MJ; CategoryThe connector; File Size568KB，2 Pages; ManufacturerFCI / Amphenol

Download Datasheet Parametric Compare View All

86285-002 Overview

Modular Connectors / Ethernet Connectors 86285-002-LP 6POS PCB MJ

86285-002 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	FCI / Amphenol
Product Category	Modular Connectors / Ethernet Connectors

Preview

Download Datasheet

View All

INPUT/OUTPUT CONNECTORS

MODULAR JACK CONNECTORS

DESCRIPTION

FCI Modular Jacks include single and

multi-port solutions that are widely used

in Telecom, Data, Networking and Home

Entertainment markets for various

applications.

The product features a simple, flexible

and low profile design for LAN

application, in particular, the Network

Interface Card. Modular Jacks Cat 3

supports the transmission of 16Mbps

signals targeted to phone, modem, POS

terminal machines and Cat 5 supports

the transmission of 100Mbps signals

targeted to switch, router, hub, etc.

The design confirms to US Federal

Regulations Code, Title 47, part 68,

which defines the size and configuration

of all units that are permitted for

connection to the public exchange

facilities.

FEATURES & BENEFITS

Right angle or vertical

Through mount or surface mount (SMT)

Cat3, Cat5 performance category

4, 6, 8 positions, fully or

selectively loaded

Single to stacked multi-ports

Shielded or non-shielded

Flanged or flangless versions

Inverted latch options

Standard or low profile versions

Snap or diamond pegs options

TARGET MARKETS

APPLICATIONS

Networking

• Network servers

• Hubs

• Routers

• Ethernet switches

Computers and Peripherals

• Laptops

• Modems

Telecom

• PBX system

• Fax machines

• Phone line security systems

• Telephone, cellular and

mobile phones

Office and Home Equipment

• ATMs

• Point of sales terminals

• Vending machines

• Security systems

• Set-top boxes

• Medical analysis equipment
