21.05.2018
RAFIX 16 - Standard contact block, silver contacts, with lamp
socket, screw terminals
1.20.122.103/0000
Dimensions
Size not mounted
Mounting depth (with actuator / indicator)
Mechanical design
Mounting
Contact system
Contact materials
Contact arrangement
Contact function
Lamp socket
Terminals
Terminal marking
Operating travel
Robustness
Mechanical characteristics
Robustness
Electrical characteristics
Rated insulation voltage acc. to VDE 0110, AC
Rated insulation voltage acc. to VDE 0110, DC
Ohmic rated current I
R
Rated motor current I
M nenn
Application category acc. to VDE 0660 Teil 200
Application category acc. to VDE 0660 Teil 200
Rated insulation voltage U
I
, AC
Rated insulation voltage U
I
, DC
22 x 25 x 43 mm
51.1 mm
snap on actuator
bridge-contact self cleaning
Ag
2 NC
momentary
W 2 x 4.6d
screw terminals
according to DIN 50013, NC: 11/12 resp. 21/22, NO: 13/14
resp. 23/24, lamp: X1 +, X2 -
3 mm
100 N
acc. to IEC 60947-5-5
250 V
300 V
6A
4A
AC 15B 300
DC 13Q 300
250 V
300 V
Rated voltage U
E
/ rated current I
E
, AC
250 V/1.5 A, 120 V/3.0 A V
Rated voltage U
E
/ rated current I
E
, DC
250 V/0.27 A, 125 V/0.55 A, 60 V/1 A, 24 V/2 A V
Thermic rated current I
the
, AC
5A
Thermic rated current I
the
, DC
2.5 A
Technical data are approximate and intended solely for general orientation in the selection of a product.
Subject to modifications and errors. Images and other graphics may only be similar.
For more information, refer to www.rafi.de chapter Imprint / Data Protection.
21.05.2018
Operating life switching element AC
Operating life switching element DC
Rated power DC
Rated power AC
Contact resistance when new max.
Other specifications
Protection class
Corresponding to EU directive NSR 72/73
Shock resistance acc. to IEC 60068-2-27
Operation temperature min.
Ambient temp. operating max. without lamp /
LED
Ambient temp. operating max. with lamp /LED
Storage temperature min.
Storage temperature max.
Color code
Environmental restistance
Mechanical operating life latching (operations)
Resistance to vibrations acc. to IEC 60068-2-6
Flame class acc. to UL 94
Hot wire ignition acc. to IEC 60695-2-1
ROHS compliant
REACH compliant
100,000 at 6A, 800.000 at 2A
250,000 at 220 V/0.2 A, 1,000,000 at 24 V/2 A
10 x I
E
1.1 x I
E
20 mΩ
II
yes
amplitude < 50g, 11ms, half sinusoidal
-25 °C
+70 °C
+55 °C
-40 °C
+85 °C
grey bottom
acc. to IEC 60068-2-14, -30, -33 and -78
100,000
10 g at 20 ... 500 Hz
V0
yes
yes
yes
Technical data are approximate and intended solely for general orientation in the selection of a product.
Subject to modifications and errors. Images and other graphics may only be similar.
For more information, refer to www.rafi.de chapter Imprint / Data Protection.
21.05.2018
