Part Number

Search

345718-1

Description
SOCKET, DIP14, IC SOCKET
Categorysocket
File Size115KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

345718-1 Overview

SOCKET, DIP14, IC SOCKET

345718-1 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codeunknown
ECCN codeEAR99
Contact to complete cooperationGOLD (10)
Contact completed and terminatedTIN LEAD OVER NICKEL
Contact materialNOT SPECIFIED
Device slot typeIC SOCKET
Type of equipment usedDIP14
Shell materialTHERMOPLASTIC POLYESTER
JESD-609 codee0
Manufacturer's serial number345718
Number of contacts14
Base Number Matches1
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Socket/C ard Products
>
Product Feature Selector
> Product Details
345718-1 Product Details
Live Product Chat
Product Photo
DIP Sockets
Not EU R oHS or ELV C om plia nt
(
Find R oHS C om plia nt Alte rna te s
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
345718-1
T E I nternal N umber: 3 4 5 7 1 8 - 1
Product Highlights:
l
DIP Socket
l
Number of Positions = 14
l
Row-to-Row Spacing = 7.62 mm
l
Through Hole C ontact Termination Type
l
Mount Style = Vertical
View all Features
Superseded
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= DIP Socket
l
Number of Positions
= 14
l
Profile = Standard
l
Frame Style
= Open
l
Leg Style
= Straight
Electrical Characteristics:
l
Insulation Resistance (M?) = 10,000
l
C ontact Resistance (m?) = 30
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.84 [0.112]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
Row-to-Row Spacing (mm [in])
= 7.62 [0.300]
l
Mount Style
= Vertical
l
C enterline (mm [in])
= 2.54 [0.100]
Contact Related Features:
l
C ontact Termination Type
= Through Hole
l
C ontact Base Material
= Beryllium C opper
l
C ontact Mating Area Plating Material
= Gold (10)
l
C ontact Style
= Screw Machine
l
Mating C ontact Type
= Inner Spring
Housing Related Features:
l
Housing Material = Thermoplastic Polyester
Configuration Related Features:
l
Height Above PC Board (mm [in])
= 2.80 [0.110]
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Conditions for Usage:
l
Temperature Range (?C ) = 105
Packaging Related Features:
l
Packaging Method
= Tube
Other:
l
Brand = AMP
