AP1346/1347
Two Coil Fan Motor Predriver
Features
- Compatible to a Hall element
- Operating voltage (V
CC
) : 4V to 28V
- Lock shutdown and automatic restart
-
Rotation detection (RD) output name as AP1347
-
Speed indication output (FG) named as AP1346
- Output current I
O
=70mA
(max)
- Operating temperature (T
opr
) : -30ºC to +85ºC
- SOP8 package
- Include Thermal Shutdown circuit
General Description
The AP1346/7 fan motor predriver is suited for
two-coil brush-less DC fan. All functions, including
lock shutdown, automatic restart, speed indication
(FG), have been integrated into one chip. When the
motor is under lock condition, lock shutdown
function turns off the output. When the lock
condition is removed, the IC automatically restarts
and allows DC fan to run. In addition, the FG
function is to indicate the rotation speed and the RD
function is to detect the motor status.
Application
- High voltage, high current brushless DC fan
Pin Assignment
( Top view )
VCC
HS(+)
FG/RD
HS(-)
1
2
AP1346/1347
3
4
SOP-8L
6
5
CT
GND
8
7
OUT1
OUT2
Pin Descriptions
Name
VCC
HS(+)
FG /RD
HS(-)
GND
CT
OUT2
OUT1
Description
Power input
Hall input
Speed
indication
detection
Hall input
Ground
Timing capacitor
Driver output
Driver output
/
Rotation
Ordering Information
AP134X X - X X X
Part Number
6: AP1346
7: AP1347
Wafer Body
Package
Lead
Packing
Blank : Tube
A : Taping
S: SOP-8L L: Lead Free
Blank or
A~Z : if necessary
Blank: Normal
to specify
This datasheet contains new product information. Anachip Corp. reserves the rights to modify the product specification without notice. No liability is assumed as a result of the use of
this product. No rights under any patent accompany the sale of the product.
Rev. 0.0 Jun 9, 2004
1/5
AP1346/1347
Two Coil Fan Motor Predriver
Absolute Maximum Ratings
Parameter
Input voltage
Output current
Allowable power dissipation
Operating temperature
Storage temperature
*note1 : Reduced by 5.5mW for each increase in Ta of 1ºC over 25
ºC
(T
A
=25ºC)
Symbol
V
CC
I
OUT
P
D
T
OPR
T
STG
Rating
30
70
550*(note1)
-30 to +85
-55 to +125
Unit
V
mA
mW
ºC
ºC
Electrical Characteristics
( T =25ºC, V
A
CC
=12V, unless otherwise noted)
Parameter
Input voltage
Hall input voltage (DC+AC)
Supply current
Hall amp input hysteresis (+)
Hall amp input hysteresis (-)
Charge current
Discharge current
Charge/discharge ratio
Clamp voltage
Comparator voltage
Output high level
FG / RD pin output low
FG / RD pin sink current
capacity
Symbol
V
IN
V
BH
I
CC
V
HYS+
V
HYS-
I
CHG
I
DHG
R
CD
V
CL
V
CP
Conditions
Min.
4
1
--
3
-15
7.7
0.19
32
1.6
0.8
10
--
8
Rating
Typ.
Max.
--
28
--
4
--
--
9.6
0.24
40
2.0
1.0
10.5
--
--
V
CC
-0.5
5.5
15
-3
11.5
0.29
48
2.4
1.2
--
0.5
--
Unit
V
V
mA
mV
mV
uA
uA
--
V
V
V
V
mA
Includes the amplitude of signal
The output is off
Delta V when V
BH
=6V
Delta V when V
BH
=6V
V
CT
= 1.5V
V
CT
= 1.5V
I
CHG
/I
DCHG
V
OH
I
O
= 10mA
V
FGL
/ V
RDL
I
FG
= 5mA / I
RD
= 5mA
I
FG
/ I
RD
V
FGL
= 2V / V
RDL
= 2V
Anachip Corp.
www.anachip.com.tw
3/5
Rev 0.0 Jun 9, 2004
AP1346/1347
Two Coil Fan Motor Predriver
Performance Characteristics
Ta (°C)
Pd (mW)
Ta (°C)
Pd (mW)
P d (m W )
600
500
400
300
200
100
0
0
25
50
75
85
100
125
150
T a (。 C )
25
550
95
242
50
440
100
220
60
396
105
198
70
352
110
176
80
308
115
154
85
286
120
132
90
264
125
110
P o w e r D is s ip a tio n C u rve
Note：SOP-8L package.
Marking Information
(Top View)
8
7
6
5
Logo
Part Number
AC
AP1347
YY WW X X
Blank : normal
L : Lead Free Package
Date code
X: internal code
WW: Xth week,01-52
Y: Year, "01"=2001
"02"=2002
4
1
2
3
SOP-8L
Note: For AP1346, part number is marked as AP1346.
Anachip Corp.
www.anachip.com.tw
4/5
~
Rev 0.0 Jun 9, 2004
