5962D9568802VPX datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> 5962D9568802VPX

Preview

5962D9568802VPX: Description5962D9568802VPX amplifier basic information: 5962D9568802VPX is an OPERATIONAL AMPLIFIER. The commonly used packaging method is DIP, 5962D9568802VPX amplifier core information: The minimum operating temperature of 5962D9568802VPX is -55 °C and the maximum operating temperature is 125 °C. Its maximum average bias current is 0.06 µA The nominal supply voltage of 5962D9568802VPX is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of 5962D9568802VPX is 7000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).) Related dimensions of 5962D9568802VPX: 5962D9568802VPX has 8 terminals. Its terminal position type is: DUAL. Total pins: 8 5962D9568802VPX amplifier additional information: Its temperature grade is: MILITARY. The corresponding JESD-30 code is: R-GDIP-T8. The corresponding JESD-609 code is: e0. The packaging code of 5962D9568802VPX is: DIP. The materials used in the 5962D9568802VPX package are mostly CERAMIC and GLASS-SEALED. The package shape is RECTANGULAR. The 5962D9568802VPX package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE.; CategoryAnalog mixed-signal IC Amplifier circuit; File Size77KB，5 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/; Alternative parts：5962D9568802VPX

Download Datasheet Parametric View All

5962D9568802VPX Overview

5962D9568802VPX amplifier basic information:

5962D9568802VPX is an OPERATIONAL AMPLIFIER. The commonly used packaging method is DIP,

5962D9568802VPX amplifier core information:

The minimum operating temperature of 5962D9568802VPX is -55 °C and the maximum operating temperature is 125 °C. Its maximum average bias current is 0.06 µA

The nominal supply voltage of 5962D9568802VPX is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of 5962D9568802VPX is 7000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of 5962D9568802VPX:

5962D9568802VPX has 8 terminals. Its terminal position type is: DUAL. Total pins: 8

5962D9568802VPX amplifier additional information:

Its temperature grade is: MILITARY. The corresponding JESD-30 code is: R-GDIP-T8. The corresponding JESD-609 code is: e0. The packaging code of 5962D9568802VPX is: DIP. The materials used in the 5962D9568802VPX package are mostly CERAMIC and GLASS-SEALED.

The package shape is RECTANGULAR. The 5962D9568802VPX package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE.

5962D9568802VPX Parametric

Parameter Name	Attribute value
Maker	Renesas Electronics Corporation
Parts packaging code	DIP
package instruction	DIP,
Contacts	8
Reach Compliance Code	unknown
ECCN code	EAR99
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.06 µA
Nominal Common Mode Rejection Ratio	74 dB
Maximum input offset voltage	7000 µV
JESD-30 code	R-GDIP-T8
JESD-609 code	e0
Negative supply voltage upper limit	-20 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	1
Number of terminals	8
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Filter level	MIL-PRF-38535 Class V
Supply voltage upper limit	20 V
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal location	DUAL
total dose	10k Rad(Si) V
Base Number Matches	1

Preview

Download Datasheet

View All

HS-2620RH, HS-2622RH

Data Sheet

August 1999

File Number

4014.1

Radiation Hardened, Very Wideband, High

Input Impedance Uncompensated

Operational Ampliﬁers

HS-2620RH and HS-2622RH are radiation hardened bipolar

operational amplifiers that feature very high input impedance

coupled with wideband AC performance. The high resistance

of the input stage is complemented by low offset voltage (4mV

Max at 25

C for HS-2620RH) and low bias and offset current

(15nA Max at 25

C for HS-2620RH) to facilitate accurate

signal processing. Offset voltage can be reduced further by

means of an external nulling potentiometer. Closed loop gains

greater than 5, the 25V/µs minimum slew rate at 25

C and the

100kV/V minimum open loop gain at 25

C, enables the

HS-2620RH to perform high gain amplification of very fast,

wideband signals. These dynamic characteristics, coupled

with fast settling times, make these amplifiers ideally suited to

pulse amplification designs as well as high frequency or video

applications. The frequency response of the amplifier can be

tailored to exact design requirements by means of an external

bandwidth control capacitor. Other high performance designs

such as high gain, low distortion audio amplifiers, high-Q and

wideband active filters and high speed comparators are

excellent uses of this part.

Speciﬁcations for Rad Hard QML devices are controlled

by the Defense Supply Center in Columbus (DSCC). The

SMD numbers listed here must be used when ordering.

Detailed Electrical Speciﬁcations for these devices are

contained in SMD 5962-95688. A “hot-link” is provided

on our homepage for downloading.

www.intersil.com/spacedefense/space.asp

Features

• Electrically Screened to SMD # 5962-95688

• QML Qualiﬁed per MIL-PRF-38535 Requirements

• High Input Impedance (HS-2620RH) . . . . . . . 65MΩ (Min)

• High Gain (HS-2620RH) . . . . . . . . . . . . . . . . 100kV/V (Min)

150kV/V (Typ)

• High Slew Rate (HS-2620RH) . . . . . . . . . . . . . . 25V/µs (Min)

35V/µs (Typ)

• Low Input Bias Current (HS-2620RH) . . . . . . . 15nA (Max)

5nA (Typ)

• Low Input Offset Voltage (HS-2620RH) . . . . . . 4mV (Max)

• Wide Gain Bandwidth Product (AV

≥

5) . . . . . .100MHz (Typ)

• Output Short Circuit Protection

• Total Dose . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x 10

RAD(Si)

Applications

• Video and RF Ampliﬁers

• Pulse Ampliﬁers

• Audio Ampliﬁers and Filters

• High-Q Active Filters

• High Speed Comparators

Ordering Information

ORDERING NUMBER

5962D9568801VGA

5962D9568801VPA

5962D9568801VPC

5962D9568802VGA

5962D9568802VPA

5962D9568802VPC

INTERNAL

MKT. NUMBER

HS2-2620RH-Q

HS7-2620RH-Q

HS7B-2620RH-Q

HS2-2622RH-Q

HS7-2622RH-Q

HS7B-2622RH-Q

TEMP. RANGE

(

-55 to 125

Pinouts

HS7-2620RH, HS7-2622RH (CERDIP) GDIP1-T8

HS7B-2620RH, HS7B-2622RH (SBDIP) CDIP2-T8

TOP VIEW

BAL

-IN

+IN

V-

COMP

V+

OUT

BAL

IN-

BAL

HS2-2620RH, HS2-2622RH (CAN) MACY1-X8

TOP VIEW

COMP

V+

V-

OUT

IN+

BAL

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
