Model 83
Hydraulics
316 SS Pressure Sensor
0-100 mV Output
Absolute and Sealed Gage
Temperature Compensated
Medical Instruments
Process Control
Robotics
Refrigeration/Compressors
Pressure Transmitters
DESCRIPTION
The Model 83 is a media compatible, piezoresistive silicon
pressure sensor packaged in a 316 stainless steel housing. The
sensing package utilizes silicone oil to transfer pressure from the
316 stainless steel diaphragm to the sensing element.
The Model 83 is designed for high pressure applications
and is intended to be welded in place. A ceramic compensation
board is included which can be added to the sensor after
installation. The compensation board corrects for temperature
errors, offset and provides a gain set resistor which can be used
to adjust an external differential amplifier and provide span
interchangeability to within ±1%.
For a low pressure, flush sensor, please refer to the Model
154. For a 316 stainless steel sensor with a ¼ NPT fitting please
refer to the Model 87 or 97. An uncompensated version of the
FEATURES
Weldable
±0.5% Pressure Non-linearity
±1.0% Temperature Performance
Compensated or Uncompensated
Versions
1.0% Interchangeable Span
(provided by gain set resistor)
Solid State Reliability
Low Power
Model 83 is also available. Please contact the factory for more
information.
Higher performance sensors are also available. Please refer
to the Models 85, 86 and 87 for flush mount applications and
the Models 96 and 97 for sensors with threaded fittings.
DIMENSIONS
STANDARD RANGES
Range
0 to 300
0 to 500
0 to 1000
0 to 3000
0 to 5000
psia
psis
●
●
●
●
●
●
●
●
●
●
1-60
ISO – Standard
316 SS Pressure Sensor
PERFORMANCE SPECIFICATIONS
Supply Current: 1.5mA
Ambient Temperature: 25°C (Unless otherwise specified)
Models 80 and 83
PARAMETERS
Full Scale Output Span
Zero Pressure Output
Static Accuracy
Input & Output Resistance
Temperature Error – Span
Temperature Error – Zero
Supply Current
Output Load Resistance
Insulation Resistance (50 VDC)
Pressure Overload
Operating Temperature
Storage Temperature
Media
Weight
–20°C to +85°C
–40°C to +125°C
Compatible with 316 Stainless Steel
12 Grams
5
50
3X
1.5
4000
4500
MIN
50
TYP
100
MAX
200
5
0.5
6000
1.0
1.0
2.0
UNITS
mV
mV
±% Span
Ω
±% Span
±% Span
mA
MΩ
MΩ
Rated
Model 83
NOTES
1,2
3
1, 4
1,4
5
6
7
Notes
1. The Model 83 has a thick film ceramic substrate that contains the
specific external resistors, trimmed to the correct value for
compensation, and fits directly over the 6 electrical pins for customer
soldering. Two additional pins can be connected by the user to the
ceramic substrate for use of the gain set resistor.
2.
Measured at vacuum for absolute (A) and one atmosphere for sealed
gage (S).
3.
4.
5.
6.
7.
Includes repeatability, pressure hysteresis, and pressure non-linearity
(best fit straight line).
Temperature range: 0-50°C in reference to 25°C.
Guarantees output/input ratiometricity.
Between case and sensing element.
3X or 7,500 psi maximum, whichever is less.
CONNECTIONS
ORDERING INFORMATION
APPLICATION SCHEMATIC
April 2000
ISO – Standard
1-61
