SLIDE SWITCHES (1 mm PITCH)
CVS
INTERNAL STRUCTURE
③
①
②
RoHS compliant
⑦
⑤
⑥
Part name
Material
Stainless steel, Gold-plated
Polyamide
Polyphenylenesulphide
Stainless steel, Gold-plated
Copper alloy, Gold-plated
Stainless steel, Gold-plated
—
④
Flammability
■
FEATURES
●
RoHS compliant
●
Lowest profile design of 1.45 mm
●
Fine pitch of 1 mm
●
Easy motion with knob height of 0.2 mm
①
②
③
④
⑤
⑥
⑦
Cover
Slider
Housing
Slider contact
Fixed contact
Terminal pin
Earth terminal
—
UL94V-0
■
PART NUMBER DESIGNATION
C V S - 0 4 T B - 1
Series name
No. of bits
01
：
1 bit
02
：
2 bits
03
：
3 bits
04
：
4 bits
08
：
8 bits
Taping
1
：
500 pcs./reel
Blank
：
2000 pcs./reel
Shape of terminal
B
：
Gull wing
C
：
Through hole
Form of packaging
T
：
Taping (Reel)
Blank : Bulk in plastic bag (01C : Plastic bag only)
■
LIST OF PART NUMBERS
No. of bits Form of packaging Shape of terminals
Taping
(Gull wing)
(Through hole) Pieces in package
500 pcs./reel
2000 pcs./reel
100 pcs./pack
500 pcs./reel
2000 pcs./reel
100 pcs./pack
500 pcs./reel
2000 pcs./reel
100 pcs./pack
No. of bits Form of packaging Shape of terminals
Taping
(Gull wing)
(Through hole) Pieces in package
500 pcs./reel
2000 pcs./reel
100 pcs./pack
500 pcs./reel
2000 pcs./reel
100 pcs./pack
1
Taping
Plastic bag
Taping
2
Taping
Plastic bag
Taping
3
Taping
Plastic bag
CVS-01TB-1
CVS-01TB
CVS-01B
CVS-01C
CVS-02TB-1
CVS-02TB
CVS-02B
CVS-03TB-1
CVS-03TB
CVS-03B
4
Taping
Plastic bag
Taping
8
Taping
Plastic bag
CVS-04TB-1
CVS-04TB
CVS-04B
CVS-08TB-1
CVS-08TB
CVS-08B
CVS
SLIDE SWITCHES (1 mm PITCH)
■
STANDARD SPECIFICATIONS
Operating temp. range
−
40 ~ 85 °C
Storage temp. range
Sealing
Non-washable
Approx. 0.028g (CVS-01B)
Approx. 0.031g (CVS-01C)
Approx. 0.041g (CVS-02B)
Approx. 0.054g (CVS-03B)
Approx. 0.067g (CVS-04B)
Approx. 0.13 g (CVS-08B)
■
ELECTRICAL CHARACTERISTICS
Contact rating
Non-switching
Switching
Minimum
Contact resistance
Insulation resistance
Dielectric strength
DC50 V 100 mA
DC6 V, 100 mA DC24 V, 25 mA
DC20 mV 1
μA
200 mΩ maximum
100 MΩ (DC100 V) minimum
AC250 V, 60 s
Net weight
■
MECHANICAL CHARACTERISTICS
Operating force
Stop strength
Solderability
3 N {0.306 kgf} maximum
6 N {0.61 kgf}, 60 s
■
ENVIRONMENTAL CHARACTERISTICS
Vibration
Shock
(Amplitude) 1.5 mm or
(Acceleration) 98 m/s
2
,
10-500 Hz, 3 directions for 10 cycles each
245
±
3 °C, 2 ~ 3 s
Reflow：255 °C (Peak temperature)
（Please
refer to the profile below）
490 m/s
2
, 11 ms
6 directions for 3 times each
Continuous load 1000 cycles,
DC6
±
0.5 V, 100
±
10 mA
−10
~ 65 °C,
Relative humidty 0 ~ 96 %,
24 h for 10 cycles
85 °C, 96 h
−
40 °C, 96 h
−
40 (0.5 h) ~ 85 °C (0.5 h), 5 cycles
Load life
Humidity
High temp. exposure
Low temp. exposure
Thermal shock
Soldering heat
Manual soldering：350
±
10 °C, 3 ~ 4 s
Shear (Adhesion)
Substrate bending
Pull-off strength
5 N {0.51 kgf} 10 s
Width 90 mm, bend 3 mm, 5 s, 1 time
5 N {0.51 kgf} 10 s
{ } : Reference only
Reflow profile for soldering heat evaluation
〉
(℃)
250
Temperature
200
150
100
50
180
℃
150
℃
+5
0
Peak : 250
℃
Over 230
℃
Pre Heating Zone
90
±
30 s
30
±
10 s
Heating time
Reflow : two times maximum
Soldering Zone
SLIDE SWITCHES (1 mm PITCH)
CVS
■
OUTLINE DIMENSIONS
●
CVS-01B
0.3 min.
Stroke 0.6
Unless otherwise specified, tolerance :
±
0.3 (Unit : mm)
●
CVS-01C
Stroke 0.6
0.15
+0.1
–0.05
Production date code
4.7
6.5
1.2
Schematic
2
2 1.35
Schematic
0.5
+0.1
–0.05
Production date code
0.3 min.
Production date code
6.1
4.7
2
1.45
0.15
+0.1
–0.05
●
CVS- □□ B
Part number
CVS-02
CVS-03
CVS-04
L
1.45
0.15
+0.1
–0.05
0.3 min.
6.1
4.7
0
0.1
–0.1
0.5
+0.1
–0.05
0.3 min.
Schematic
No. of bits. L dimension
2
3
4
8
3
4
5
9
Stroke 0.6
CVS-08
■
RECOMMENDED P.C.B. PAD OUTLINE DIMENSIONS
●
CVS-01B
0.7
0.7
1.2
0.1
0.35
+0.1
–0.05
1
0
–0.1
0.15
1
0.15
(Unit : mm)
●
CVS-02B
1
0.5
0.7
1.2
●
CVS-03B
1
1
0.5
1.2
0.7
●
CVS-04B
1N (N=1~3) = 3
0.7
0.7
0.7
4.2
0.7
3.6
0.5
1.2
4.7
3.6
0
3.6
4.7
4.7
3.6
1.2
1.2
0.7
1.2
0.7
0.7
1.4
0.7
0.7
2.2
0.7
0.7
3.2
0.7
●
CVS-08B
1N (N=1~7) = 7
0.5
■
SIZE OF P.C.B. PROCESSING
0.7
0.7
1.2
4.7
0
0
0
(Unit : mm)
●
CVS-01C
1.2
4.7
3.6
0
1.2
0.7
6.5
0.7
8.2
0.7
2 –
φ
0.7 hole
CVS
SLIDE SWITCHES (1 mm PITCH)
■
PACKAGING SPECIFICATIONS
<Taping packaging specifications>
●
Taping version is packaged in 2000 pcs. or 500 pcs. per reel. Orders
will be accepted for units of 2000 pcs., i.e., 2000, 4000, 6000 pcs.,
etc. or for units of 500 pcs., i.e., 500, 1000, 1500 pcs., etc.
●
Taping version is boxed with two reels.
Maximum number of consecutive missing pieces = 2
Leader length and reel dimension are shown in the
diagrams below:
●Embossed
tape dimensions
●
Reel dimensions
(Conforms to JIS C 0806-3)
(In accordance with EIAJ ET-7200A)
17.4±1
(Unit: mm)
Empty
End
Filled
Empty
Head
φ
21±0.8
2±0.5
40 mm min.
Direction of feed
20 pitches min.
Leader
400 mm min.
φ
13±0.2
φ
254±2 (2000pcs./reel)
φ
182±1 (500pcs./reel)
21.4±1 (2000pcs./reel)
20.4±1 (500pcs./reel)
●
1 bit
φ
1.5
+0.1
0
2
±
0.1
1.75
±
0.1
8
±
0.1
4
±
0.1
0.3
±
0.1 Installation
example
(CVS-01B)
●
2 bits
1.75
±
0.1
8
±
0.1
●
3 bits
4
±
0.1
2
±
0.1
0.3
±
0.1 Installation
example
(CVS-02B)
1.75
±
0.1
8
±
0.1
φ
50 min. (2000 pcs/reel)
φ
80±1 (500 pcs/reel)
4
±
0.1
2
±
0.1
0.3
±
0.1 Installation
example
(CVS-03B)
7.5
±
0.1
Direction of feed
16
φ
1.5
+0.1
0
φ
1.5
+0.1
0
7.5
±
0.1
7.5
±
0.1
Direction of feed
16
16
Direction of feed
2
2
2
●
4 bits
1.75
±
0.1
8
±
0.1
●
8 bits
4
±
0.1
2
±
0.1
0.3
±
0.1
（CVS-04B）
Installation example
1
2
N
3
4
5
6
7
8
O
φ
1.5
+0.1
0
φ
1.5
+0.1
0
4
±
0.1
2
±
0.1
1.75
±
0.1
8
±
0.1
0.3
±
0.1
（CVS-08B）
Installation example
7.5
±
0.1
16
3
4
Direction of feed
2
16
1
2
O
N
7.5
±
0.1
Direction of feed
2
<Bulk pack specifications>
●
The smallest unit of bulk pack in a plastic bag is
10
pcs.
per pack.
Orders will be accepted for unit of minimum
10
pcs., i.e.,
10
,
20
,
30
pcs., etc.
●
Boxing of bulk in a plastic bag is performed with
100
pcs. (standard
500
pcs.) per box.
