THRU-HOLE RADIAL POWER INDUCTORS
AIRH-03, -05, -10, -15 SERIES
FEATURES:
• Ferrite core with UL tube
• Wire wound construction
• High current, low DCR
STANDARD SPECIFICATIONS:
PART NO
AIRH-03-50K
AIRH-03-100K
AIRH-03-270K
AIRH-03-500K
AIRH-03-101K
AIRH-03-151K
AIRH-03-251K
AIRH-05-50K
AIRH-05-100K
AIRH-05-270K
AIRH-05-500K
AIRH-05-680K
AIRH-05-101K
AIRH-05-151K
AIRH-10-50K
AIRH-10-100K
AIRH-10-270K
AIRH-10-500K
AIRH-10-680K
AIRH-10-101K
AIRH-15-50K
AIRH-15-100K
AIRH-15-270K
AIRH-15-500K
L
(µH)
±10%
5
10
27
50
100
150
250
5
10
27
50
68
100
150
5
10
27
50
68
100
5
10
27
50
R
DC
(
Ω
)
Max
0.015
0.018
0.035
0.050
0.065
0.075
0.090
0.012
0.015
0.025
0.030
0.035
0.050
0.060
0.010
0.012
0.018
0.025
0.027
0.030
0.008
0.010
0.015
0.020
I
RATED
(A)
Max
10.0
9.0
7.0
5.6
5.2
5.0
5.0
14.0
12.0
9.0
8.0
7.5
7.5
7.0
19.0
16.0
12.5
11.0
10.0
10.0
24.0
20.0
16.0
15.0
I
DC
(A)
Max
25
19
12
8
6
5
4
25
19
13
10
9
7
5
25
19
12
10
8
7
25
19
14
10
A
Max
0.875/22,26
1.125/28,58
0.875/22,26
0.875/22,26
1.125/28,58
1.375/34,93
1.625/41,26
0.875/22,26
1.125/28,58
0.875/22,26
1.125/28,58
1.125/28,58
1.375/34,93
1.625/41,26
1.125/28,58
1.375/34,93
1.125/28,58
1.375/34,93
1.375/34,93
1.625/41,26
1.375/34,93
1.687/42,85
1.375/34,93
1.625/41,26
B
Max
0.600/15,24
0.625/15,86
0.800/20,32
0.800/20,32
0.800/20,32
0.800/20,32
0.800/20,32
0.625/15,86
0.625/15,86
0.840/21,34
0.840/21,34
0.860/21,84
0.860/21,84
0.860/21,84
0.635/16,13
0.635/16,13
0.935/23.75
0.935/23.75
0.935/23.75
0.935/23.75
0.700/17,78
0.700/17,78
1.000/25,40
1.000/25,40
C
Typical
0.500/12,70
0.687/17/45
0.437/11,10
0.750/19,05
0.937/23,80
1.062/26,98
1.312/33,33
0.750/19,05
1.000/25,40
0.562/14,28
0.750/19,05
0.875/22,26
1.000/25,40
1.250/31,75
0.812/20,63
1.218/30,94
0.687/17,45
0.937/23,80
1.125/28,58
1.312/33,33
0.937/23,80
1.500/38,10
0.937/23,80
1.125/28,58
D
Typical
0.042/1,07
0.042/1,07
0.042/1,07
0.042/1,07
0.042/1,07
0.042/1,07
0.042/1,07
0.053/1,35
0.053/1,35
0.053/1,35
0.053/1,35
0.053/1,35
0.053/1,35
0.053/1,35
0.065/1,65
0.065/1,65
0.065/1,65
0.065/1,65
0.065/1,65
0.065/1,65
0.082/2,08
0.082/2,08
0.082/2,08
0.082/2,08
OPTIONS:
• Bulk Pack is standard
• 10% is standard
• Other tolerance available
APPLICATIONS:
• Electronic Appliance
• Power Supplies
• TRIAC/SCR Control Circuits
| | | | | | | | | | | | | | |
PHYSICAL CHARACTERISTICS:
TECHNICAL INFORMATION:
• UL Polyolefin Shrink Tubing
• Operating Temp: -40°C to 85°C
• Lp measure at 1 KHz 0.1VRMS.
• Tolerance: K=±10%, tighter tolerance available
• Check SCD for detail E&M specification
• I
DC
: Lp drops 10% typical from its initial value
• I
RATE
:
∆T
of 40°C temperature rise max
• Marking: Inductance value and tolerance
Note:
All specifications subject to change
without notice.
A
B
D
C
1.00±0.15
25,4±3,8
Dimension: inch/mm
