184 CPNS
www.vishay.com
Vishay BCcomponents
Conductive Polymer Aluminum Capacitors
SMD (Chip), Low Impedance
FEATURES
• Useful life: up to 2000 h at 105 °C
• Very low ESR and high ripple current
• High voltages up to 100 V
• AEC-Q200 qualified products on request
• SMD-version with base plate, lead (Pb)free reflow
solderable
184 CPNS
longer
lifetime
185 CPNZ
higher
temperature
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
APPLICATIONS
186 CPNT
• Automotive electronics
• Industrial and professional applications
• Telecommunications and IT
Fig. 1
QUICK REFERENCE DATA
DESCRIPTION
Nominal case sizes
(L x W x H in mm)
Rated capacitance range, C
R
Tolerance on C
R
Rated voltage range, U
R
Category temperature range
Endurance test at 105 °C
Useful life at 105 °C
Shelf life at 0 V, 105 °C
Based on sectional
specification
Climatic category IEC 60068
VALUE
4.0 x 4.0 x 5.5
to 10.0 x 10.0 x 12.4
4.7 μF to 3300 μF
± 20 %
2.5 V to 100 V
-55 °C to +105 °C
2000 h
2000 h
1000 h
IEC 60384-25 / CECC 32300
• Portable and mobile equipment
MARKING
• Rated capacitance (in μF)
• Rated voltage (in V)
• Date code, in accordance with IEC 60062
• Black mark or “-” sign indicating the cathode (the anode is
identified by beveled edges)
• Code indicating group number (84)
PACKAGING
55 / 105 / 56
Supplied in blister tape on reel
Revision: 22-Sep-17
Document Number: 28437
1
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
184 CPNS
www.vishay.com
Vishay BCcomponents
SELECTION CHART FOR C
R
, U
R
(2.5 V TO 20 V), AND RELEVANT NOMINAL CASE SIZES
(L x W x H in mm)
C
R
(μF)
U
R
(V)
2.5
4.0
6.3
10
4.0 x 4.0 x 5.5
16
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
10.0 x 10.0 x 12.4
8.0 x 8.0 x 11.7
-
10.0 x 10.0 x 12.4
-
-
-
-
-
20
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
10
22
4.0 x 4.0 x 5.5
33
5.0 x 5.0 x 5.5
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
5.0 x 5.0 x 5.5
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
8.0 x 8.0 x 11.7
6.3 x 6.3 x 7.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
-
10.0 x 10.0 x 12.4
-
10.0 x 10.0 x 12.4
-
-
-
-
47
5.0 x 5.0 x 5.8
5.0 x 5.0 x 5.5
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
-
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
6.3 x 6.3 x 5.8
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
68
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
6.3 x 6.3 x 7.7
8.0 x 8.0 x 11.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
10.0 x 10.0 x 12.4
10.0 x 10.0 x 12.4
-
5.0 x 5.0 x 5.5
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
8.0 x 8.0 x 11.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
10.0 x 10.0 x 12.4
8.0 x 8.0 x 11.7
-
10.0 x 10.0 x 12.4
-
-
100
120
220
6.3 x 6.3 x 5.8
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
330
390
470
560
680
820
1000
1200
1500
2200
2700
3300
6.3 x 6.3 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
10.0 x 10.0 x 12.4
8.0 x 8.0 x 11.7
-
-
10.0 x 10.0 x 12.4
-
-
-
-
-
-
-
Revision: 22-Sep-17
Document Number: 28437
2
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
184 CPNS
www.vishay.com
Vishay BCcomponents
SELECTION CHART FOR C
R
, U
R
(25 V TO 100 V), AND RELEVANT NOMINAL CASE SIZES
(L x W x H in mm)
C
R
(μF)
4.7
5.6
8.2
10
12
15
22
33
47
56
68
100
150
220
270
330
390
470
U
R
(V)
25
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
6.3 x 6.3 x 5.8
8.0 x 8.0 x 11.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
10.0 x 10.0 x 12.4
10.0 x 10.0 x 12.4
10.0 x 10.0 x 12.4
35
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
10.0 x 10.0 x 12.4
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
-
10.0 x 10.0 x 12.4
-
-
50
6.3 x 6.3 x 5.8
8.0 x 8.0 x 11.7
6.3 x 6.3 x 5.8
6.3 x 6.3 x 5.8
8.0 x 8.0 x 11.7
8.0 x 8.0 x 11.7
8.0 x 8.0 x 11.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
-
-
-
-
-
-
63
6.3 x 6.3 x 5.8
6.3 x 6.3 x 5.8
-
8.0 x 8.0 x 11.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
10.0 x 10.0 x 12.4
-
10.0 x 10.0 x 12.4
-
-
-
-
-
-
-
80
-
-
8.0 x 8.0 x 11.7
-
10.0 x 10.0 x 12.4
-
10.0 x 10.0 x 12.4
-
-
-
-
-
-
-
-
-
100
6.3 x 6.3 x 7.7
-
-
8.0 x 8.0 x 11.7
-
-
10.0 x 10.0 x 12.4
-
-
-
-
-
-
-
-
-
-
-
min. 0.4 / max. 1.0 (2 x)
2-pin:
H
MAX.
MAX. 0.3
Negative
polarity
VISHAY
47
63V
84H5
D
W
MAX.
B
L1
MAX.
S
L
MAX.
Fig. 2 - Dimensional outline
Revision: 22-Sep-17
Document Number: 28437
3
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
184 CPNS
www.vishay.com
Table 1
Vishay BCcomponents
DIMENSIONS
in millimeters
AND MASS
NOMINAL
CASE SIZE
LxWxH
4.0 x 4.0 x 5.5
5.0 x 5.0 x 5.5
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
CASE
CODE
0406
0505
0506
0606
0608
0812
1012
L
MAX.
4.5
5.5
5.5
6.7
6.7
8.5
10.5
W
MAX.
4.5
5.5
5.5
6.7
6.7
8.5
10.5
H
MAX.
5.8
5.8
6.1
6.1
8.0
12.0
12.7
ØD
4.0
5.0
5.0
6.3
6.3
8.0
10.0
B
MAX.
0.8
0.8
0.8
0.8
0.8
1.1
1.1
S
1.0
1.4
1.4
2.2
2.2
3.1
4.5
L1
MAX.
5.3
6.1
6.1
7.4
7.4
9.2
11.2
MASS
(g)
0.1
0.2
0.2
0.3
0.4
0.8
1.3
Table 2
TAPE AND REEL DIMENSIONS
in millimeters,
PACKAGING QUANTITIES
NOMINAL
CASE SIZE
LxWxH
4.0 x 4.0 x 5.5
5.0 x 5.0 x 5.5
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
CASE
CODE
0406
0505
0506
0606
0608
0812
1012
PITCH
P
1
8
12
12
12
12
16
16
TAPE WIDTH
W
12
12
12
16
16
24
24
TAPE
THICKNESS
T
2
5.7
5.7
6.1
6.2
8.0
13.0
12.9
REEL DIAMETER
380
380
380
380
380
380
380
PACKAGING
QUANTITY
PER REEL
2000
1000
1000
1000
900
400
400
MOUNTING
The capacitors are designed for automatic placement on to
printed-circuit boards.
Optimum dimensions of soldering pads depend amongst
others on soldering method, mounting accuracy, print
layout and / or adjacent components.
For recommended soldering pad dimensions, refer to Fig. 3
and Table 3.
SOLDERING
Soldering conditions are defined by the curve, temperature
versus time, where the temperature is that measured on the
component during processing.
For maximum conditions refer to Fig. 4.
Any temperature versus time curve which does not exceed
the specified maximum curves may be applied.
As a general principle, temperature and duration shall be the
minimum
necessary required to ensure good soldering
connections. However, the specified maximum curves
should never be exceeded.
b
a
c
a
Fig. 3 - Recommended soldering pad dimensions
Revision: 22-Sep-17
Document Number: 28437
4
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
184 CPNS
www.vishay.com
Table 3
Vishay BCcomponents
RECOMMENDED SOLDERING PAD DIMENSIONS
in millimeters
NOMINAL
CASE SIZE
LxWxH
4.0 x 4.0 x 5.5
5.0 x 5.0 x 5.5
5.0 x 5.0 x 5.8
6.3 x 6.3 x 5.8
6.3 x 6.3 x 7.7
8.0 x 8.0 x 11.7
10.0 x 10.0 x 12.4
CASE CODE
0406
0505
0506
0606
0608
0812
1012
a
2.6
3.0
3.0
3.5
3.5
4.2
4.4
b
1.6
1.6
1.6
1.6
1.6
1.9
1.9
c
1.0
1.4
1.4
2.1
2.1
2.8
4.3
SOLDERING PROFILE FOR LEAD (Pb)-FREE REFLOW PROCESS
(°C)
Peak temperature
T
peak
Temperature of the
Surface
/ Terminal
230
t
3
200
t
2
180
Preheat
t
1
Time (s)
Fig. 4 - Maximum temperature load during reflow soldering
Table 4
REFLOW SOLDERING CONDITIONS
for MAL2182xxxxxE3
PROFILE FEATURES
Maximum time between 150 °C to 180 °C (t
1
)
Maximum time above 200 °C (t
2
)
Maximum time above 230 °C (t
3
)
Peak temperature T
Peak
Maximum reflow cycles
Note
• Temperature measuring point on top of the case and on terminals
2.5 V TO 10 V
120 s
90 s
60 s
250 °C
2
16 V TO 25 V
120 s
80 s
50 s
240 °C
2
35 V TO 100 V
120 s
70 s
30 s
240 °C
1
