GPAS1001 - GPAS1007
Taiwan Semiconductor
CREAT BY ART
10A, 50V - 1000V Glass Passivated Rectifiers
FEATURES
- Glass passivated chip junction
- High efficiency, Low VF
- High current capability
- High surge current capability
- Low power loss
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21
TO-263AB (D PAK)
MECHANICAL DATA
Case:
TO-263AB (D
2
PAK)
Molding compound, UL flammability classification rating 94V-0
Moisture sensitivity level: level 1, per J-STD-020
Packing code with suffix "G" means green compound (halogen-free)
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 1A whisker test
Polarity:
As marked
Weight:
1.7 g (approximately)
2
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage (Note 1)
I
F
= 10 A
Maximum reverse current @ rated V
R
Typical junction capacitance (Note 3)
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
Note 2: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
T
J
=25°C
T
J
=125°C
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
C
J
R
θJC
T
J
T
STG
GPAS GPAS GPAS GPAS GPAS GPAS GPAS
1001
50
35
50
1002
100
70
100
1003
200
140
200
1004
400
280
400
10
150
1.1
5
100
50
4
- 55 to +150
- 55 to +150
1005
600
420
600
1006
800
560
800
1007
1000
700
1000
UNIT
V
V
V
A
A
V
μA
pF
°C/W
°C
°C
Document Number: DS_D0000118
Version: B15
GPAS1001 - GPAS1007
Taiwan Semiconductor
ORDERING INFORMATION
PART NO.
GPAS100x
(Note 1)
*: Optional available
PACKING CODE
RN
MN
PACKING CODE
SUFFIX
G
(*)
PACKAGE
D
2
PAK
D
2
PAK
PACKING
800 / 13" Paper reel
800 / 13" Plastic reel
Note 1: "x" defines voltage from 50V (GPAS1001) to 1000V (GPAS1007)
EXAMPLE
PREFERRED
PART NO.
GPAS1007 RNG
PART NO.
GPAS1007
PACKING CODE
RN
PACKING CODE
SUFFIX
G
DESCRIPTION
Green compound
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25°C unless otherwise noted)
FIG.1 MAXMUM FORWARD CURRENT
DERATING CURVE
INSTANTANEOUS REVERSE CURRENT (μA)
12
AVERAGE FORWARD CURRENT(A)
10
8
6
4
2
0
0
50
100
150
RESISTIVE OF
INDUCTIVE LOAD
FIG. 2 TYPICAL REVERSE CHARACTERISTICS
100
10
T
J
=125°C
1
T
J
=25°C
0.1
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
CASE TEMPERATURE(
°
C)
FIG. 3 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
100
FIG. 4 TYPICAL INSTANTANEOUS
FORWARD CHARACTERISTICS
175
150
125
100
75
50
25
0
1
10
NUMBER OF CYCLES AT 60 Hz
100
8.3ms Single Half Sine Wave
INSTANTANEOUS FORWARD CURRENT (A)
PEAK FORWARD SURGE CURRENT(A)
10
1
Pulse Width=300us
1% Duty Cycle
0.1
0.6
0.8
1
1.2
1.4
1.6
FORWARD VOLTAGE (V)
1.8
2
Document Number: DS_D0000118
Version: B15
GPAS1001 - GPAS1007
Taiwan Semiconductor
FIG. 5 TYPICAL JUNCTION CAPACITANCE
120
JUNCTION CAPACITANCE (pF)
100
80
60
40
20
0
0.1
1
10
100
f=1.0MHz
Vslg=50mVp-p
REVERSE VOLTAGE (V)
PACKAGE OUTLINE DIMENSIONS
TO-263AB (D PAK)
DIM.
A
B
C
D
E
F
G
H
I
J
K
Unit (mm)
Min
-
14.60
2.41
0.68
2.29
4.44
1.14
1.14
8.25
0.36
2.03
Max
10.5
15.88
2.67
0.94
2.79
4.70
1.40
1.40
9.25
0.53
2.79
Unit (inch)
Min
-
0.575
0.095
0.027
0.090
0.175
0.045
0.045
0.325
0.014
0.080
Max
0.413
0.625
0.105
0.037
0.110
0.185
0.055
0.055
0.364
0.021
0.110
2
SUGGESTED PAD LAYOUT
Symbol
A
B
C
D
E
F
G
Unit (mm)
10.8
8.3
1.1
3.5
16.9
9.5
2.5
Unit (inch)
0.425
0.327
0.043
0.138
0.665
0.374
0.098
MARKING DIAGRAM
P/N
G
YWW
F
Document Number: DS_D0000118
= Specific Device Code
= Green Compound
= Date Code
= Factory Code
Version: B15
GPAS1001 - GPAS1007
Taiwan Semiconductor
CREAT BY ART
Notice
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf,
assumes no responsibility or liability for any errors or inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied, to
any intellectual property rights is granted by this document. Except as provided in TSC's terms and conditions of
sale for such products, TSC assumes no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of TSC products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or selling these products for use in such applications do so at their own risk and agree to fully
indemnify TSC for any damages resulting from such improper use or sale.
Document Number: DS_D0000118
Version: B15
