F-219 SUPPLEMENT
FSH–120–04–F–RA–SL
FSH–110–04–L–DH–SL
SFMH–130–02–L–D–LC
SFMH–105–02–L–D–LC
FSH–120–04–F–DH
SFMH–120–02–L–D
(1.27 mm) .050"
FSH, SFMH SERIES
HIGH-RELIABLE HORIZONTAL SMT
FSH Mates with:
SFMH
Mates with:
FTSH, FSH
FSH
1
NO. PINS
PER ROW
04
PLATING
OPTION
ROW
OPTION
OPTIONS
SPECIFICATIONS
For complete specifications
see www.samtec.com?FSH or
www.samtec.com?SFMH
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
FSH =
Sn or Au over 50 µ" (1.27 µm) Ni
SFMH =
Au over 50 µ" (1.27 µm) Ni
Current Rating (FSH/SFMH):
2.6 A per pin
(2 pins powered)
Operating Temp Range:
-55 °C to +125 °C
Insertion Depth:
SFMH =
(3.35 mm) .132" to
(4.57 mm) .180"
RoHS Compliant:
Yes
05, 10, 15, 20, 25
(–DH Option)
= Gold flash on
post, Matte Tin
on tail
–F
–L
= Double Row
Horizontal
(Surface Mount)
–DH
–RA
= Solder Locks
– SL
–C
05, 10, 15, 20, 25, 30, 35, 40, 45
(–RA Option)
(Standard sizes)
(No. of positions + 4) x (1.27) .050
= 10 µ" (0.25 µm)
Gold on post,
Matte Tin on tail
= Right-angle
(Through-hole)
= (4.50 mm) .177"
DIA Polyimide
film Pick &
Place Pad
(10 positions
minimum)
not available
with –RA option
= Tape & Reel
(Not available
with –RA)
(6.58)
.259
(0.41) .016 SQ
2 4
(2.51)
.099
–TR
(3.68)
.145
(5.21)
.205
(3.68)
.145
(1.27)
.050
PROCESSING
Lead-Free Solderable:
Yes (FSH)
SMT Lead Coplanarity:
(0.10 mm) .004" max (SFMH)
(0.15 mm) .006" max (FSH)*
*(.004" stencil solution
may be available; contact
IPG@samtec.com)
(3.43)
.135
(1.27) (1.27)
.050 .050
No. of positions + 2 x (1.27) .050
–DH
–RA
13
(3.94)
.155
(1.27)
.050
(2.16)
.085
(0.89)
.035
(0.71)
.028
(2.29)
.090
(1.27)
.050
–RA
(1.27)
.050
–DH
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
FILE NO. E111594
SFMH
1
NO. PINS
PER ROW
02
PLATING
OPTION
D
OPTION
05, 10, 15, 20, 25, 30, 35, 40, 45, 50
(0.64) .025 TYP
= 10 µ" (0.25 µm)
Gold on contact,
Gold flash on tail
–L
= Locking
Clip
(Manual
placement
required)
= Tape & Reel
–LC
(4.57)
.180
(1.65)
.065
(2.03)
.080
No. of Positions x (1.27) .050
+ (2.92) .115
04
02
–TR
APPLICATIONS
SFMH FSH
(0.41) .016
(1.50)
.059
–WT
= Weld Tab
(Not available
with 35, 40, 45,
50 positions)
–WT
(1.65)
(3.43) .065
.135
(1.41)
.056
DIA
HORIZONTAL
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
(1.27)
.050
No. of Positions x
(1.27) .050 + (1.65) .065
03 01
(1.02)
.040
–LC
Due to technical progress, all designs, specifications and components are subject to change without notice.
All parts within this catalog are built to Samtec’s specifications.
Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.
WWW.SAMTEC.COM
