PUSH-BUTTON
PENDANT PRODUCTS
WOODHEAD
®
PUSH-BUTTON PENDANT PRODUCTS ARE ERGONOMICALLY
INDUSTRIAL-GRADE PENDANTS AND ENCLOSURES THAT FEATURE COMPACT
WATERTITE
®
NYLON OR DURABLE NEōTEX
®
RUBBER CONSTRUCTION
DESIGNED HAND-HELD CONTROL BOXES, AVAILABLE IN A WIDE RANGE OF
Watertite pendant stations are rugged enough to withstand the most hostile industrial
environments, yet ergonomically designed to fit an operator’s hand. Super-Safeway
®
pushbutton
pendant stations feature NEoTEX rubber construction to protect buttons from industrial
¯
elements . Weather-resistant pushbutton covers transform your F .S ./F .D . box into a pendant
station . Constructed of NEoTEX rubber, the cover includes integral push buttons that can be
¯
wired normally-open or normally-closed .
FEATURES AND
BENEFITS
Ergonomic
design
Available in Watertite and
Super-Safeway constructions
NEoTEX rubber
¯
construction
Increased user comfort and satisfaction
Suitable for a wide range of applications
Optimum resistance to the effects of
heat, cold, abrasion and chemicals
APPLICATIONS
• Automated assembly equipment
• Automatic doors
• Automation controllers
• Automation equipment
• Automotive plants
• Workstations
Pushbuttons
Watertite
®
Pendant Station
Reference Information
UL File No.: E70531
Environmental
Rating: Wet industrial duty
NEMA Enclosure Rating: NEMA 4X, IP56
Temperature Rating: -10 to 150°F
5052
5054
M = Momentary;
N = Maintained
M
N
M
N
5056
5058
Number of Buttons
2
2
2
4
4
4
4
6
6
6
6
8
8
8
8
8
Number of Speeds
1
N/A
N/A
1
1
1
2
1
1
1
2
1
1
1
2
3
Woodhead No.*
5052-1
5052-M
5052-N
5054-1
5054-1M
5054-1N
5054-2
5056-1
5056-1M
5056-1N
5056-2M
5058-1
5058-1M
5058-1N
5058-2M
5058-3M
Order No.
130126-0243
130126-0246
130126-0247
130126-0248
130126-0249
130126-0250
130126-0251
130126-0256
130126-0257
130126-0258
130126-0260
130126-0262
130126-0263
130126-0264
130126-0266
130126-0268
M
N
M
M
N
M
M
* Momentary and Maintained refer to On/Off buttons only in first and second positions. Without an “M” or “N,” no On/Off is present.
Accessory/Replacement Parts
†
Description
2-position selector switch
‡
3-position selector switch—NO In Center
‡
2-button single speed switch—1 NO
2-button single speed switch—2 NO
2-button single speed switch—NO/NC
2-button 2-speed switch—1 NO
2-button switch Momentary On/Off—NO/NC
2-button switch Maintained On/Off—NO/NC
Pilot light, green, shroud mount
Pilot light, red, shroud mount
Pilot light, white, shroud mount
Red mushroom On/Off switch
‡
Button cover, Black high ambient chemical resistance
Button cover legend sheet
†
‡
Dimensions
Woodhead No.
505SS-2
505SS-3NO
505SW-1
505SW-12NO
505SW-1NONC
505SW-2
505SW-M
505SW-N
505PL-GS
505PL-RS
505PL-YS
505B-RM
505BC-C
505BC-L
Order No.
130126-0025
130126-0027
130126-0028
130126-0029
130126-0030
130126-0031
130126-0033
130126-0034
130126-0021
130126-0022
130126-0023
130126-0012
130126-0008
130126-0009
Length with
MAX-LOC
18.8cm
24.9cm
30.7cm
36.8cm
7.4"
9.8"
12.1"
14.5"
Width
Depth
Woodhead Series No.
5052
5054
5056
5058
8.9cm 3.5"
5.8cm 2.3"
See Strain Relief Grips for wiring device/enclosure boxes for additional support
Requires larger hole in enclosure if done as a retrofit
www.molex.com/woodhead
F-5
Test/Control
Features and Benefits
•
Lightweight, polycarbonate pendant enclosure is double
insulated, UV stabilized and chemically resistant to
provide long life
•
Ergonomic design fits easily in the palm of your hand
for greater comfort and reduced fatigue
•
Single and two-speed button pairs have mechanical
interlocks for improved safety
•
The common circuit is pre-wired to save installation time
•
An elastic, chemically resistant gasket ensures a tight
seal between front and back
•
MAX-LOC
®
strain relief included as standard to provide
maximum cord pull-out resistance
•
Legend sheet included
Physical
Pendant Housing: Polycarbonate
Switches: 3A, 125/250V
Single and Two-Speed Switch Pairs: Mechanically
interlocked
Cover Face Screws: Stainless Steel
Gasket and O-Ring Seal: Rubber
Cord Connection; MAX-LOC nylon strain relief with rubber
grommet
Cord Grip Body Size: F3 ¾"
Cord Diameter: 9.53 to 20.63mm (.375 to .812")
F
Pushbuttons
Watertite
®
Pendant Station
Test/Control
Features and Benefits
•
Lightweight, polycarbonate pendant enclosure is double
insulated, UV stabilized and chemically resistant to
provide long life
•
Ergonomic design fits easily in the palm of your hand
for greater comfort and reduced fatigue
•
Single speed, double-throw, momentary contacts can
be wired either normally-open or normally-closed for
complete application flexibility
•
An elastic, chemically resistant gasket ensures a tight
seal between front and back
•
MAX-LOC
®
strain relief included as standard to provide
maximum cord pull-out resistance
Reference Information
UL File No.: See switch rating
CSA File No.: LR32400
Physical
Pendant Housing: Nylon
Switches: Single-speed, double throw, momentary type,
fine sliver, SPDT-DB
Cover Face Screws: Stainless Steel
Pushbutton Diaphragm Seal: Rubber
Cover Gasket Seal: Neoprene
Cord Connection; MAX-LOC nylon strain relief with rubber
grommet
Nameplate Set: 35 self-adhesive, pre-printed labels on one
acetate sheet
Cord Grip Body Size: F2 ½"
Cord Diameter: 7.92 to 15.88mm (.312 to .625")
Environmental
Rating: Wet industrial duty
NEMA Enclosure Rating: NEMA IP67
FF
Number of Buttons
2
2
Body Color
Yellow
Black
Woodhead No.
4052
4052BLK
Order No.
130126-0231
130126-0232
Switch Characteristics
Dimensions
Contact Arrangement: Single speed SPDT-DB
Continuous
Control
10A @ 125 to 250V AC*
1/2 HP @ 125V AC*
3/4 HP @ 250V AC*
1 HP @ 125V AC or 250V AC
10A 28V DC Inductive
15A 28V DC Resisitive
120VAC 60A Make 6A Break
240VAC 30A Make 3A Break
A-300 Contact rating Per U.L. Std. 508
* UL listed and CSA certified
Replacement Parts
†
Description
Replacement switch—one speed, momentary
Rubber switch diaphragm
Legend kit—labels, function pushbutton station
†
Woodhead No.
42-2190
00-5150
31-5800
Order No.
130186-0318
130180-0468
130228-0721
See Strain Relief Grips for wiring device/enclosure boxes for additional support
Pushbuttons
Swinger Switch
Mini-Change
®
Features and Benefits
•
One-button, momentary contact switch provides quick
and easy on/off actuation
•
Durable weather-resistant rubber housing protects
switch against harmful elements
Reference Information
UL File No.: E70531
CSA File No.: LR44136
Electrical
Voltage: 120V AC/250V AC
Physical
Housing: Nylon
Throw
Sngle
Single
Double
Single
Pole Position
Normally open
Normally closed
Normally open/Normally closed
Normally open
Woodhead No.
55501
55502
55503
55504
Order No.
130023-0001
130023-0002
130023-0003
130023-0004
F-6
www.molex.com/woodhead
Pushbuttons
Super-Safeway
™
Pendant Station
4024
4025ES
Features and Benefits
-
•
Unique, industry-leading, NEoTEX
®
Paracril OZO
rubber pendant stations yield the best performance for
abrasion, chemical exposure and temperature extremes
•
Ergonomic design fits easily in the palm of your hand
for greater comfort and reduced fatigue
•
Housing to cover fitted with tongue and groove design
for best sealing performance
•
Pushbuttons are not exposed beyond enclosure face to
prevent unwanted activation and button protection
•
Single and two-speed buttons can be wired as an
electrical interlock for improved safety
•
An elastic, chemically resistant gasket ensures a tight
seal between front and back
•
MAX-LOC
®
strain relief included as standard to provide
maximum cord pull-out resistance
•
Built-in ground connection saves installation time
•
Legend sheet included
•
All buttons are momentary, except for the E-Stop which
is maintained
Number of Speeds
1
1
2
1
1
2
1
1
2
1
1
2
1
1
2
Emergency Stop
Yes
Reference Information
CSA certified switches: LR32400
Environmental
Rating: 4022—Rain Tight
4024, 4026, 4028—Testing pending
Number of Buttons
2
2
2
3
3
3
4
4
4
6
6
6
8
8
8
Cord Grip Body Size*
F3 ¾"
F3 ¾"
F3 ¾"
F3 ¾"
F3 ¾"
F3 ¾"
F3 ¾"
F3 ¾"
F3 ¾"
F3 ¾"
F4 1"
F3 ¾"
F4 1"
F3 ¾"
F4 1"
Yes
Yes
Yes
Yes
Cord Diameter
12.70–17.45mm (.500–.687")
12.70–17.45mm (.500–.687")
12.70–17.45mm (.500–.687")
12.70–19.05mm (.500–.750")
12.70–19.05mm (.500–.750")
12.70–19.05mm (.500–.750")
12.70–19.05mm (.500–.750")
12.70–19.05mm (.500–.750")
12.70–19.05mm (.500–.750")
14.27–20.63mm (.562–.812")
17.45–23.80mm (.687–.937")
14.27–20.63mm (.562–.812")
17.45–23.80mm (.687–.937")
14.27–20.63mm (.562–.812")
17.45–23.80mm (.687–.937")
Woodhead No.
4022
4022ES
4022-2
4023
4023ES
4023-2
4024
4024ES
4024-2
4026
4026ES
4026-2
4028
4028ES
4028-2
Order No.
130126-0199
130126-0204
130126-0200
130126-0207
130126-0209
130126-0208
130126-0212
130126-0214
130126-0213
130126-0218
130126-0222
130126-0219
130126-0036
130126-0226
130126-0224
* F3 nut is non-metalic. F4 nut is metallic.
Switch Ratings
Single Speed
20A @ 125 to
250V AC
25A @ 24V DC
0.5A @ 250V DC
1 HP @ 125V AC
2 HP @ 250V AC
Two Speed
10A @ 125 or
250V AC
1/3 HP @ 125V
1/2 HP @ 250V
Maintain
16A @ 125V AC
8A @ 250V AC
1 HP @ 125 or
250V AC
Dimensions
Pendant Pushbutton Station
Length
14.9cm (5.88")
19.0cm (7.50")
23.1cm (9.13")
27.3cm (10.75")
40.0cm (15.75")
46.3cm (18.25")
Width
7.6cm (3.00")
7.6cm (3.00")
7.6cm (3.00")
7.6cm (3.00")
7.6cm (3.00")
7.6cm (3.00")
Depth
6.7cm (2.66")
6.7cm (2.66")
6.7cm (2.66")
6.7cm (2.66")
6.7cm (2.66")
6.7cm (2.66")
Woodhead No.
4022
4023
4022ES
4024
4023ES
4026
4024ES
4028
4026ES
4028ES
Order No.
130126-0199
130126-0207
130126-0204
130126-0212
130126-0209
130126-0218
130126-0214
130126-0036
130126-0222
130126-0226
Replacement Gasket Kits
Number of Buttons
2
3
4
6
8
Woodhead No.
4022G
4023G
4024G
4026G
4028G
Order No.
130126-0205
130126-0210
130126-0216
130126-0223
130126-0227
Replacement Switches
Description
Red mushroom on/off switch
4020 replacement switch
4020-2 replacement switch, 2-speed
Legend Kit
Emergency Stop
Yes
Enclosure Rating
NEMA 4X
Number of Speeds
1
2
Woodhead No.
505B-RM
4020
4020-2
71-4220
Order No.
130126-0012
130128-0100
130128-0101
130203-1295
Replacement Covers
Description
Replacement cover 4022
Replacement cover 4023
Replacement cover 4024
Replacement cover 4026
Replacement cover 4028
Number of Buttons
2
3
4
6
8
Woodhead No.
00-3063
00-3823
00-3073
00-3083
00-0463
Order No.
130128-0079
130128-0082
130128-0080
130128-0081
130128-0078
www.molex.com/woodhead
F-7
Test/Control
Physical
-
Pendant Cover and Housing: : NEoTEX Paracril OZO rubber
Messenger Cable Bracket and Cover Screws: Steel Zinc-plated
Gasket and O-Ring Seal: Neoprene
Cord Connection; MAX-LOC nylon strain relief with rubber
grommet
Nameplate Set: 35 self-adhesive, pre-printed labels on one
acetate sheet
F
Pushbuttons
Super-Safeway
™
Pushbutton
Covers for FS/FD Boxes
Features and Benefits
-
•
Unique, industry-leading, NEoTEX
®
Paracril OZO rubber
pendant covers yield the best performance for abrasion,
chemical exposure and temperature extremes
•
Switches can be wired as normally open or normally
closed for flexibility of application
•
The cover has integral pushbuttons which operate
mechanically coupled pushbutton contact blocks for
time-saving installation
•
Switches function as single speed or two speed
momentary contact operation for flexibility of application
•
Single speed function can be wired as electrically
interlocked for improved safety
•
Switches mounted on molded-in steel mounting plate
•
Legend sheet included
Switch Ratings
Single Speed
20A @ 125 to480VAC
5A @ 600VAC
1 HP @ 125VAC
2 HP @ 250VAC
Physical
-
Pendant Cover: NEoTEX Paracril OZO rubber
Nameplate Set: 35 self-adhesive, pre-printed labels on one
acetate sheet
Environmental
Rating: Indoor damp location
FF
Test/Control
Two Speed
10A @ 125 or 250VAC
1/3 HP @ 125V
1/2 HP @ 250V
Covers for FS/FD Boxes*
Color
Yellow
Yellow
Black
Number of Speeds
1
2
1
Woodhead No.
4032
4032-2
4032BLK
Order No.
130126-0228
130126-0229
130126-0230
* For FS/FD boxes, see Power Distribution FS/FD Boxes and Coverplates
F-8
www.molex.com/woodhead
Talking
京公网安备 11010802033920号
EEWORLD
