CRYSTAL CLOCK OSCILLATORS
LVDS HF/UHF CLOCK (XO)
Data Sheet 0631E
Rev.
-
AA-A2D6XXX Series
Description
The
AA-A2D6XXX Series
of quartz crystal oscillators provide ultra high frequency with LVDS
complementary outputs. The outputs can be disabled for test automation or combining multiple clocks. The
device is based on low noise analog harmonic multiplication, and packaged in a miniature, low profile
leadless FR4 based package with gold plated pads, which enhances compatibility with PCB material.
Applications and Features
• Wide frequency range – 150.0MHz to 500.000MHz
• Fiber Channel; 10 GbE; Infiniband; Network Processors; SOHO Routing
• High Reliability - NEL HALT/HASS qualified for crystal oscillator start-up conditions
• Low Phase Noise, Low Jitter
• Ultra High Frequency
• Fast Rise and Fall times
• Tight frequency stability - ±20 ppm overall available
• RoHS Compliant, Lead Free Construction
• Low cost
Creating a Part Number
AA - A 2D6 X X X - FREQ
Package Code
Overall Frequency Stability, ppm
AA 6 pad 7.5x 5.2mm SMD
E ±20
F ±25
Input Voltage
G ±50
A
3.3V±5%
H ±100
B
2.5V±5%
9 Customer specific
Enable Option
H
Enable High
N
N/C
Temperature Range, °C
A 0 to 50
B 0 to 70
C -20 to 70
D -40 to 85
9
Customer specific
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881
Email:
nelsales@nelfc.com
www.nelfc.com
CRYSTAL CLOCK OSCILLATORS
AA-A2D6XXX Series
Continued
LVDS HF/UHF CLOCK (XO)
Data Sheet 0631E
Rev.
-
Absolute Maximum Ratings
Parameter
Operating Temperature Range
Storage Temperature Range
Supply Voltage
Enable/Disable Voltage
Parameter
Nominal Frequency
Supply Voltage
Supply current
Load
Output Levels
Symb
Fo
Vcc
Icc
At receiving end between
the outputs
Differential amplitude
Amplitude error
Offset Voltage
Offset Voltage error
At outputs crossing, room
temperature
20 to 80, 80 to 20 %
Integrated from Phase
Noise, 12 KHz to 20 MHz,
RMS
Random
period,
Accumul.,
pk-to-pk
Deterministic
<400 M
>400 M
212.5 MHz
@ 10 Hz
@100 Hz
@1 KHz
@10KHz
@100KHz
@>1MHz
Overall, including initial
calibration, temperature,
aging 10 years, shock and
vibration
CMOS logic 1 or N/C
CMOS logic 0
90
247
1.125
45/55
Symbol
To
Tst
Vcc
Ven/dis
Conditions, Note
Code A
Code B
Value
-40 to +85
-50 to +90
-0.5 to 4.5
0 to Vcc
MIN
150
3.135
2.375
TYP
3.3
2.5
80
100
330
1.25
50/50
0.35
0.2
MAX
500
3.465
2.625
100
110
454
50
1.375
50
55/45
0.4
Unit
ºC
ºC
V
V
Unit
MHz
V
mA
Ohm
mV
mV
V
mV
%
ns
ps
Electrical Parameters
Vod
Vof
Duty Cycle (Symmetry)
Rise/Fall Time
Jitter
Integrated
Tr/Tf
J
Wavecrest
characterized
2.5
2.5
25
3
6
-50
-45
-65
-95
-125
-140
-145
-148
See “Creating a Part Number”
Not all combinations
available, consult factory
ps
ps
ps
dBc
dBc/Hz
Subharmonics
Phase Noise
£(∆f)
Frequency Stability
∆F/F
ppm
Enable High Option
Pin 2 Enabled
Pin 2 Disabled
0.7 Vcc
0
Vcc
0.3 Vcc
V
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881
Email:
nelsales@nelfc.com
www.nelfc.com
CRYSTAL CLOCK OSCILLATORS
Rev. -
AA-A2D6XXX Series
Continued
LVDS UHF CLOCK (XO)
Electrical Connection
Pin
Connection
1
Enable/Disable or No Connect
2
N.C.
3
V
EE
/Ground
4
Output
5
/Output
6
V
CC
Dimensions are typical in mm
7.5
NEL
2.0
0.5
1
2
3
1.37
5.20
1.37
6
2.540
5
4
Environmental and Mechanical Characteristics
Operating temp.
range
Mechanical Shock
Thermal Shock
Vibration
Hermetic Seal
Soldering conditions
see part # table
Per MIL-STD-202, Method 213, Cond. E
Per MIL-STD-883, Method 1011, Cond. A
Per MIL-STD-883, Method 2007, Cond. A
Leak rate less than 1x10-8 atm.cc/s of helium
See MAX reflow profile below
Maximum Reflow Profile
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881
Email:
nelsales@nelfc.com www.nelfc.com
