CMDZ5242B BK datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> CMDZ5242B BK

CMDZ5242B BK: DescriptionDIODE ZENER 12V 250MW SOD323; Categorysemiconductor Discrete semiconductor; File Size437KB，3 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

CMDZ5242B BK Overview

DIODE ZENER 12V 250MW SOD323

CMDZ5242B BK Parametric

Parameter Name	Attribute value
Voltage - Zener (nominal) (Vz)	12V
Tolerance	±5%
Power - Max	250mW
Impedance (max) (Zzt)	30 Ohms
Current at different Vr - Reverse leakage current	1µA @ 9.1V
Voltage at different If - Forward (Vf	900mV @ 10mA
Operating temperature	-65°C ~ 150°C
Installation type	surface mount
Package/casing	SC-76，SOD-323
Supplier device packaging	SOD-323

Preview

Download Datasheet

View All

CMDZ5221B THRU CMDZ5261B

SURFACE MOUNT

SILICON ZENER DIODE

2.4 VOLTS THRU 47 VOLTS

250mW, 5% TOLERANCE

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR CMDZ5221B

Series Silicon Zener Diode is a high quality voltage

regulator, manufactured in a super-mini surface mount

package, designed for use in industrial, commercial,

entertainment and computer applications.

MARKING CODE: SEE MARKING CODES ON

ELECTRICAL CHARACTERISTICS TABLE

SOD-323 CASE

MAXIMUM RATINGS:

(TA=25°C)

Power Dissipation

Operating and Storage Temperature

Thermal Resistance

SYMBOL

TJ, Tstg

UNITS

°C

°C/W

250

-65 to +150

500

ELECTRICAL CHARACTERISTICS:

(TA=25°C), VF=0.9V MAX @ IF=10mA (FOR ALL TYPES)

ZENER

VOLTAGE

VZ @ IZT

MIN

CMDZ5221B

CMDZ5222B

CMDZ5223B

CMDZ5224B

CMDZ5225B

CMDZ5226B

CMDZ5227B

CMDZ5228B

CMDZ5229B

CMDZ5230B

CMDZ5231B

CMDZ5232B

CMDZ5233B

CMDZ5234B

CMDZ5235B

CMDZ5236B

CMDZ5237B

CMDZ5238B

CMDZ5239B

CMDZ5240B

CMDZ5241B

CMDZ5242B

2.280

2.375

2.565

2.660

2.850

3.135

3.420

3.705

4.085

4.465

4.845

5.320

5.700

5.890

6.460

7.125

7.790

8.265

8.645

9.500

10.45

11.40

NOM

2.4

2.5

2.7

2.8

3.0

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.0

6.2

6.8

7.5

8.2

8.7

9.1

MAX

2.520

2.625

2.835

2.940

3.150

3.465

3.780

4.095

4.515

4.935

5.355

5.880

6.300

6.510

7.140

7.875

8.610

9.135

9.555

10.50

11.55

12.60

TEST

CURRENT

MAXIMUM ZENER

IMPEDANCE

ZZT @ IZT

7.0

5.0

6.0

8.0

ZZK @ IZK

1200

1250

1300

1400

1600

1700

1900

2000

1900

1600

1000

750

500

600

0.25

MAXIMUM

REVERSE

CURRENT

IR @ VR

μA

100

5.0

3.0

2.0

1.0

2.0

3.0

3.5

4.0

5.0

6.0

6.5

7.0

8.0

8.4

9.1

MAXIMUM ZENER

VOLTAGE

TEMPERATURE

MARKING

COEFFICIENT

CODE

ΘV

%/°C

-0.085

-0.080

-0.075

-0.070

-0.065

-0.060

±0.055

±0.030

+0.038

+0.045

+0.050

+0.058

+0.062

+0.065

+0.068

+0.075

+0.076

+0.077

TYPE

R4 (8-January 2010)
