Plastic Photodiode Package with Leads
PDB-C142
WWW.LUNAINC.COM
Precision – Control – Results
DESCRIPTION
The
PDB-C142
is a blue enhanced PIN silicon photodiode in a
photoconductive mode packaged in a water clear T1 ¾ plastic package.
FEATURES
•
•
•
•
Large active area
Photoconductive
High Speed
Low cost
RELIABILITY
Contact Luna for recommendations on specific test conditions and
procedures.
APPLICATIONS
•
•
•
•
Smoke detectors
Light pen detectors
TV & VCR remotes
Bar code detectors
ABSOLUTE MAXIMUM RATINGS
SYMBOL
Reverse Voltage
Storage Temperature
Operating Temperature
Soldering Temperature*
* 1/16 inch from case for 3 seconds max.
MIN
-
-40
-40
-
-
-
to
-
MAX
100
+100
+80
+260
UNITS
V
°C
°C
°C
T
a
= 23°C
UNLESS OTHERWISE NOTED
-
-
-
Information in this technical datasheet is believed to
be correct and reliable. However, no responsibility is
assumed for possible inaccuracies or omission.
Specifications are subject to change without notice.
Page 1/2
REV 01-04-16
© 2016 Luna Optoelectronics. All rights reserved.
Luna Optoelectronics, 1240 Avenida Acaso, Camarillo CA 93012 • Phone (805) 987-0146 • Fax (805) 484-9935
Plastic Photodiode Package with Leads
PDB-C142
WWW.LUNAINC.COM
OPTO-ELECTRICAL PARAMETERS
PARAMETER
Short Circuit Current
Dark Current
Shunt Resistance
Junction Capacitance
Spectral Application Range
Breakdown Voltage
Noise Equivalent Power
Response Time**
Precision – Control – Results
T
a
= 23°C
UNLESS NOTED OTHERWISE
TEST CONDITIONS
H=100 fc, 2850 K
V
R
= 10 V
V
R
= 10 mV
V
R
=10V; f = 1 MHz
Spot Scan
I=10
µA
V
R
=10V@
λ
= Peak
RL = 1KΩ,V
R
= 10 V
MIN
100
-
100
-
400
15
-
-
TYP
150
5
500
18
-
25
2x10
50
-14
MAX
-
30
-
25
1100
-
-
-
UNITS
µA
nA
MΩ
pF
nm
V
W/ √
Hz
nS
**Response time of 10% to 90% is specified at 660nm wavelength light.
TYPICAL PERFORMANCE
SPECTRAL RESPONSE
0.60
Responsivity (A/W)
0.50
0.40
0.30
0.20
0.10
0.00
250
300
350
400
450
500
550
600
650
700
750
800
850
900
950
1000
1050
1100
1150
Wavelength (nm)
Information in this technical datasheet is believed to
be correct and reliable. However, no responsibility is
assumed for possible inaccuracies or omission.
Specifications are subject to change without notice.
Page 2/2
REV 01-04-16
© 2016 Luna Optoelectronics. All rights reserved.
Luna Optoelectronics, 1240 Avenida Acaso, Camarillo CA 93012 • Phone (805) 987-0146 • Fax (805) 484-9935
