Subrack Systems
ELECTRONICS & TECHNOLOGY, INC.
Rack Accessories
“P” Type Side Panel
Material: 0.080” aluminum with clear irridite finish
Part No.
SW52P89/90
SW52P119/90
SW52P156/90
SW69P119/90
SW69P156/90
SW87P119/90
SW87P156/90
SW104P156/90
SW122P156/90
SW122P202/90
Overall
Height
A
5.23”
5.23”
5.23”
6.98”
6.98”
8.73”
8.73”
10.47”
11.975”
11.975”
Depth
B
9.0”
12.0”
15.75”
12.0”
15.75”
12.0”
15.75”
15.75”
15.75”
20.25”
Vector
Handle
HA12
HA12
HA12
HA13
HA13
HA12
HA12
HA12
HA12
HA12
Accepts Max
Card
Height
4.5”
4.5”
4.5”
6.25”
6.25”
8.0”
8.0”
9.75”
11.5”
17.5”
Rack
Units
(H)
3U
3U
3U
4U
4U
5U
5U
6U
7U
7U
T-Struts
Part Mounting
Hardware
Metal or plastic screw down card guides attach with
SC4-27/25 flat head screw and NT4-7PA square nut.
Square nuts slide into T-strut slots and anchor 4-40
screws for mounting parts. Supplied in quantities of 25
ea.
Modules or
Front Panel
Mounting
Hardware
SC 10-2A Thumb
screws and SC10-
3A jack screws
(supplied with EFP
modules, Cardmount
modules and front
assemblies to T-struts.
SP09-2 spacers are used
as standoffs for mounting
modules to 1” T-struts
(1.79” struts are standard
with module subracks.)
EIA
Subracks
Part No.
BR64#
SP09-2
SC10-2A
Description
Right angle bracket and two mounting screws
Hex spacer for module mounting,
includes hardware
Thumb screw fully threaded for direct
attachment of panels
Jack screw for mounting modules to T-struts
with jacking action
Connector mounting hardware, includes SC4-28
screws, NT4-2# nuts and lockwashers
4-40 nut for connector mounting
4-40 hex head screws, 3/4” long, Lock washer
4-40 hex head screw, 1/2” long for connector
mounting
Pkg Qty
1
12
12
12
42ea.
42ea.
24
Part No.
NT4-7PA
SC4-27/25
Description
Square nut
100
o
flat head screw
Size
4-40
4-40 X 1/4”
Pkg
Qty
25
25
SC10-3A
HD34
HD52
SC4-28
www.vectorelect.com
800-423-5659
51
