KSC2518
KSC2518
High Speed, High Voltage Switching
• Low Collector Saturation Voltage
• Specified of Reverse Biased SOA With Inductive Load
1
TO-220
2.Collector
3.Emitter
NPN Epitaxial Silicon Transistor
Absolute Maximum Ratings
T
C
=25°C unless otherwise noted
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
I
B
P
C
T
J
T
STG
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current (DC)
*Collector Current (Pulse)
Base Current (DC)
Collector Dissipation (T
C
=25°C)
Junction Temperature
Storage Temperature
Parameter
1.Base
Value
500
400
7
4
8
1
40
150
- 55 ~ 150
Units
V
V
V
A
A
A
W
°C
°C
* PW≤350µs, Duty Cycle≤10%
Electrical Characteristics
T
C
=25°C unless otherwise noted
Symbol
V
CEO
(sus)
V
CEX
(sus)1
V
CEX
(sus)2
I
CBO
I
CER
I
CEX1
I
CEX2
I
EBO
h
FE1
h
FE2
V
CE
(sat)
V
BE
(sat)
t
ON
t
STG
t
F
Parameter
Collector-Emitter Sustaining Voltage
Collector-Emitter Sustaining Voltage
Collector-Emitter Sustaining Voltage
Collector Cut-off Current
Collector Cut-off Current
Collector Cut-off Current
Test Condition
I
C
= 2A, I
B1
= 0.4A, L = 1mH
I
C
= 2A, I
B1
= -I
B2
= 0.4A
T
a
= 125°C, L = 180µH, Clamped
I
C
= 4A, I
B1
= 0.8A, -I
B2
= 0.4A
T
a
= 125°C, L = 180µH, Clamped
V
CB
= 400V, I
E
= 0
V
CE
= 400V, R
BE
= 51Ω @ T
C
= 125°C
V
CE
= 400V, V
BE
(off) = -1.5V
V
CE
= 400V, V
BE
(off) = -1.5V @
T
C
= 125°C
V
EB
= 5V, I
C
= 0
V
CE
= 5V, I
C
= 0.3A
V
CE
= 5V, I
C
= 1.5A
I
C
= 1.5A, I
B
= 0.3A
I
C
= 1.5A, I
B
= 0.3A
V
CC
= 150V, I
C
= 2A
I
B1
= - I
B2
= 0.4A
R
L
= 75Ω
20
10
Min.
400
450
400
10
1
10
1
10
80
1
1.5
1
2.5
0.7
V
V
µs
µs
µs
Max.
Units
V
V
V
µA
mA
µA
mA
µA
Emitter Cut-off Current
* DC Current Gain
* Collector-Emitter Saturation Voltage
* Base-Emitter Saturation Voltage
Turn ON Time
Storage Time
Fall Time
* Pulse Test: PW≤350µs, Duty Cycle≤2% Pulsed
h
FE
Classification
Classification
h
FE1
©2000 Fairchild Semiconductor International
R
20 ~ 40
O
30 ~ 60
Y
40 ~ 80
Rev. A, February 2000
KSC2518
Typical Characteristics
5
1000
V
CE
= 5V
Pulsed
I
C
[A], COLLECTOR CURRENT
4
3
I
B
=0.4A
I
B
=0.3A
I
B
=0.2A
h
FE
, DC CURRENT GAIN
I
B
=0.5A
100
2
I
B
=0.1A
I
B
=0.05A
10
1
0
0
2
4
6
8
10
1
0.01
0.1
1
10
V
CE
[V], COLLECTOR-EMITTER VOLTAGE
I
C
[A], COLLECTOR CURRENT
Figure 1. Static Characteristic
Figure 2. DC current Gain
V
BE
(sat), V
CE
(sat)[V], SATURATION VOLTAGE
10
100
I
C
=5I
B
Plsed
I
C
=5I
B
1=-5I
B
2
Pulsed, V
CC
=150V
V
BE
(sat)
t
on
[uS], TURN ON TIME
t
stg
[uS], STORAGE TIME
t
f
[uS], FALL TIME
1
10
t
stg
1
0.1
V
CE
(sat)
t
f
t
on
0.1
0.1
0.01
0.01
0.1
1
10
1
10
I
C
[A], COLLECTOR CURRENT
I
C
[A], COLLECTOR CURRENT
Figure 3. Base-Emitter Saturation Voltage
Collector-Emitter Saturation Voltage
Figure 4. Turn On, Storage and Fall Time
vs Collector Current
100
5
I
C
[A], COLLECTOR CURRENT
10
PW
Dissipation Limited
1
DC
1m
10
0u
s
s
=1
0u
s
I
C
[A], COLLECTOR CURRENT
4
3
m
10
s
ite
d
b
S/
m
Li
2
V
CEX
(SUS)
V
CEO
(SUS)
0.1
1
0.01
1
10
100
1000
0
0
100
200
300
400
500
V
CE
[V], COLLECTOR-EMITTER VOLTAGE
V
CE
(s), COLLECTOR-EMITTER VOLTAGE
Figure 5. Forward Bias Safe Operating Area
Figure 6. Reverse Bias Safe Operating Area
©2000 Fairchild Semiconductor International
Rev. A, February 2000
KSC2518
Typical Characteristics
(Continued)
160
140
20
P
D
[W], POWER DISSIPATION
150
200
120
15
dT[%], I
C
DERATION
100
80
60
40
20
0
0
50
o
S/b
DI
LIM
SS
ITE
IP
D
AT
IO
N
LI
M
UT
ED
10
5
0
100
0
50
o
100
150
T
C
[ C], CASE TEMPERATURE
T
C
[ C], CASE TEMPERATURE
Figure 7. Derating Curve of Safe Operating Areas
Figure 8. Power Derating
©2000 Fairchild Semiconductor International
Rev. A, February 2000
KSC2518
Package Demensions
TO-220
9.90
±0.20
1.30
±0.10
2.80
±0.10
4.50
±0.20
(8.70)
ø3.60
±0.10
(1.70)
1.30
–0.05
+0.10
9.20
±0.20
(1.46)
13.08
±0.20
(1.00)
(3.00)
15.90
±0.20
1.27
±0.10
1.52
±0.10
0.80
±0.10
2.54TYP
[2.54
±0.20
]
2.54TYP
[2.54
±0.20
]
10.08
±0.30
18.95MAX.
(3.70)
)
(45
°
0.50
–0.05
+0.10
2.40
±0.20
10.00
±0.20
Dimensions in Millimeters
©2000 Fairchild Semiconductor International
Rev. A, February 2000
